DeLonghi BCO255 Manuel utilisateur

instructions

Coffee Maker

BCO255

Coffee Maker 2

Thank you for choosing this coffee machine. To get the very

best out of your new coffee machine it is advisable to read

these instructions before using the appliance. This is the only

way to ensure optimum results and maximum safety.

Using for the first time

Before using the machine for the first time, wash all the acces-

sories in warm soapy water and rinse. For the best tasting coffee

the internal circuits must be flushed through at least five times.To

flush through the espresso function follow the instructions in the

paragraph “How to prepare espresso coffee” using just water.

The filter function must be flushed through, at least twice follow

the instructions in the paragraph “How to prepare filter coffee”

using just water.

Installation

• Place the coffee maker on a flat work surface at a safe distance

from taps and sinks.

• Check that the voltage corresponds to that indicated on the

appliance rating plate.The appliance must always be connected

to a well-earthed socket rated at 10A minimum.The manufac-

turer is not liable for damage caused by inadequate earthing of

the appliance.

• In the event of incompatibility between the plug on the appli-

ance and the socket, have the plug replaced by a qualified pro-

fessional.

If the cable is damaged or requires replacing, contact a service

centre authorised by the manufacturer only.

• Never install the machine in an environment that can reach a

temperature less than or equal to 0°C (if the water in it

freezes, the coffee maker may be damaged).

Coffee Maker

How to prepare filter coffee

Preparing the filter coffee

• Lift the lid and fFill the tank with fresh, clean water (Fig. 1) up to

the level marker corresponding to the number of cups of coffee

being prepared, making sure not to exceed the MAX mark.

• Open the filter holder door by turning it to the right (Fig. 2).

• Place the paper filter in the filter holder (Fig. 3).The use of size

“4” paper filters is recommended.

• Place the ground coffee in the filter using the measuring spoon

supplied, level evenly (Fig. 4).

As a general rule, use a level measure of coffee (about 7

grams) for each cup required (for example, 10 meas-

ures for 10 cups).

• Close the filter holder door and place the carafe, with the lid

on, on the hot plate.

• Select the desired flavour as described in the paragraph “How

to choose the flavour of the filter coffee”

Note: the coffee maker features the Flavour Saver device inside the

filter holder for filter coffee; this increases the coffee brewing time

and improves extraction, giving the coffee a full and intense flavour.

•Press the FILTER COFFEE ON/OFF switch (Fig. 5).The FILTER

COFFEE ON light above the switch will come on to indicate

that the filter coffee maker is working.

• The coffee will start to come out after a few seconds.

It is completely normal for the appliance to release a little

steam while the coffee is filtering.

To k eep the coffee hot after filtering, place the carafe on the hot

plate and leave the machine on (filter coffee light on): the coffee in

the carafe will be kept at the right temperature.

• To switch the machine off, press the FILTER COFFEE ON/OFF

switch.

How to prepare espresso coffee

Filling the water tank

Lift the lid and remove the water tank (Fig. 6) by pulling it upwards.

Fill the tank with fresh water making sure not to exceed the MAX

mark.

Coffee Maker 4

fig. 1

fig. 2

fig. 3

fig. 4

fig. 5 fig. 6

Replace the tank by connecting the valve at the bottom of the tank

with the hole in the base on the machine.

The tank may also be filled without it being removed by filling with

water from a carafe.

NB: Never use the appliance without water in the tank and always

remember to top up when the level drops to a couple of centimetres from

the bottom (fig. 7).

PREHEATING THE COFFEE UNIT

To obtain espresso coffee at the right temperature, the coffee machi-

ne must be preheated.You are therefore recommended to press the

ON/OFF button (fig. 8) at least 15 minutes before preparing the cof-

fee, making sure the filter holder is attached to the applian-

ce (check that the steam knob is closed).

To attach the filter holder, position it under the boiler outlet with

the handle towards the left (see fig. 9), push it upwards and at the

same time rotate the handle firmly towards the right.Wait for 15

minutes, then make the coffee as described in the following chapter.

Alternatively, you can preheat more rapidly by proceeding as follows:

1. Turn the appliance on by pressing the ON/OFF button (fig. 8) and

attach the filter holder to the appliance without adding ground

coffee.

2. Place a cup under the filter holder. Use the same cup as will be

used to prepare the coffee in order to preheat it.

3. Wait for the temperature OK indicator light to come on (fig. 10),

then immediately press the coffee knob (fig. 11). Run the water off

until the temperature OK indicator light goes out, then interrupt

delivery by pressing the coffee button again.

4. Empty the cup. Wait until the temperature OK indicator light

comes on again then repeat the same operation.

(It is normal for a small and harmless puff of steam to be given off

when removing the filter holder).

fig. 7

fig. 8

fig. 9

fig. 10

Coffee Maker

fig. 11

How to prepare espresso coffee using the filter

holder for ground coffee

1. After preheating the appliance as described in the previous para-

graph, place the ground coffee filter in the filter holder Fig. 12.

Note: Use good quality, finely-ground coffee for espresso coffee machines.

IMPORTANT: for correct operation, before adding the

ground coffee to the filter holder, make sure the filter is

free from ground coffee from the previous infusion.

2. To make one coffee only, place one level measure (about 7 g) of

ground coffee in the filter (fig. 13).To prepare two coffees, place

two loosely filled measures (about 6+6 g) of ground coffee in the

filter. Fill the filter a little at a time to prevent the ground coffee

from overflowing. Distribute the ground coffee evenly and press

lightly with the presser (fig. 14).

NOTE:Pressing the coffee is very important in order to prepare

a good coffee. However if you press too hard, coffee will come

out slowly and crema will be of a dark colour. If you press too

light, coffee will come out too fast and crema will be a very light

colour.

3. Remove any excess coffee from the rim of the filter holder and

attach to the appliance. Rotate firmly (fig. 9) to avoid water

leaking out.

4. Place the cup or cups (ideally preheated by rinsing with a little

hot water) under the filter holder spouts (fig. 15).You are rec-

ommended to heat the cups before making the coffee by rinsing

them with a little hot water or placing them to warm on the

top plate for at least 15-20 minutes (fig. 16).

5. Make sure the temperature OK indicator light (fig. 10) is on (if

off, wait until it comes on), then press the coffee run-off button

(fig. 11) until the required quantity is obtained.To stop run-off,

press the coffee run-off button again.

6. To detach the filter holder, turn the handle from right to left.

To avoid any splashing, do not detach the filter holder

while the machine is dispensing coffee.

7. To eliminate the used coffee grounds, hold the filter holder

upside down and tap (fig. 17).

fig. 12

fig. 13

fig. 14

fig. 15

Coffee Maker 6

fig. 16

8. To turn the coffee machine

off, press the espresso coffee

ON/OFF button.

fig. 17

Coffee Maker

How to make cappuccino

1. Prepare espresso coffee, using cups that are large enough for cap-

puccinos

2. Press the steam ON/OFF button (fig. 18).The steam light comes

on (fig. 18).

3.Wait until the temperature OK indicator light comes on (fig. 19)

indicating that the boiler has reached the ideal temperature for

steam production.

In the meantime, fill a recipient with about 100 grams of milk for

each cappuccino to be prepared.The milk must be at refrigerator

temperature (not hot!). In choosing the size of the recipient, bear

in mind that the milk doubles or triples in volume.

NB: YOU ARE RECOMMENDED TO USE SEMI-SKIMMED MILK AT

REFRIGERATOR TEMPERATURE.

4. Place the container with the milk under the cappuccino maker.

5. Move the cappuccino maker outwards by rotating to the left (fig.

20). During this operation, avoid touching the boiler outlet as it is

hot. Place the recipient containing the milk under the cappuccino

maker.

6. Immerse the cappuccino maker in the milk for about 2 cm and rotate

the steam knob anticlockwise (fig. 21) (rotating the knob more or less

varies the quantity of steam delivered by the cappuccino maker).The

milk now starts to increase in volume and take on a creamy appearan-

ce.

7. When the required temperature is reached, interrupt steam delivery

by rotating the steam knob clockwise.

8. Pour the frothed milk into the cups containing the espresso

coffee.Your cappuccino is now ready. If desired, add sugar and

sprinkle a little powdered chocolate or cinnamon on top of the

froth.

Note: to prepare more than one cappuccino, first make all the cof-

fees then at the end prepare the frothed milk for all the cappuccinos.

IMPORTANT: to ensure hygiene, you are recommended to

follow this procedure each time you make cappuccino to avoid

milk stagnating in the milk circuit.

1. Discharge a little steam for a few seconds by rotating the steam

knob (fig. 21).This empties any milk left inside the steam tube.

2. With one hand, hold the top part stationary (taking care to avoid

burns) and with the other remove the cappuccino maker and

extract it from the nozzle(fig. 22).

3. Wash the cappuccino maker and steam nozzle thoroughly with

warm water.

5. Replace the cappuccino maker by inserting it as far as it will go

into the steam nozzle.

fig. 18

fig. 19

fig. 20

fig. 21

fig. 22

HOT WATER PRODUCTION

1. Turn the appliance on by pressing the espresso coffee ON/OFF

button (fig. 8).

2. Place a container under the cappuccino maker.

3.When the temperature OK light comes on, press the coffee run-

off button (fig. 11) and at the same time turn the steam knob anti-

clockwise (fig. 21).Water comes out of the cappuccino maker;

4. To interrupt the flow of hot water, close the steam knob by rotating

clockwise and press the coffee button again.

Cleaning and maintenance

Before performing any cleaning or maintenance operations, turn

the machine off, unplug it from the power socket and allow it to

cool down.

1. Do not use solvents or detergents when cleaning the coffee

maker.A soft, damp cloth is sufficient.

2. Remove the filter-trays, empty them and wash them periodically.

ATTENTION: during cleaning, never immerse the unit in

water – it is an electrical appliance.

Cleaning the filter holder for ground coffee

About every 200 coffees, clean the filter holder of ground coffee as

follows:

• Remove the filter and frother by turning the filter holder upside

down and tapping;

•Clean the inside of the filter holder. Never wash in a dishwasher.

•Clean the metal filter thoroughly in hot water using a brush (fig.

23. Make sure the holes in the metal filter are not blocked. If

necessary, clean with a pin (see fig.24).

•Separate the two parts of the frother and rinse under hot water

(fig. 25).

•Replace the rubber diaphragm, making sure it adheres well to the

plastic support.

Failure to clean as described above invalidates the guarantee.

fig. 23

fig. 24

fig. 25

Coffee Maker 8

Coffee Maker

Cleaning the boiler outlet

About every 200 coffees, the espresso boiler outlet must be cleaned

as follows:

• Make sure the appliance is not hot and that it is unplugged from

the mains;

•Using a screwdriver, unscrew the screw fixing the espresso boiler

outlet (fig. 26);

•Clean the boiler with a damp cloth (fig. 27);

•Clean the outlet thoroughly in hot water using a brush. Make sure

the holes are not blocked. If necessary, clean with a pin (fig. 24).

•Rinse under running water, rubbing all the time.

•Replace the espresso boiler outlet, making sure the gasket is cor-

rectly positioned.

Failure to clean as described above invalidates the guarantee.

Descaling the espresso coffee section

It is advisable to clean the calcium from the machine every 200

cups of coffee. It is recommended to use specificproducts for

descaling of espresso coffe machines.

1. Fill the water tank (espresso coffee) up to the MAX level;

2. Dissolve 2 spoonfuls (about 30 grams) of citric acid (obtainable

from chemist's or drug stores);

3. Press the espresso coffee ON/OFF button and wait for the tem-

perature OK indicator light to come on.

4. Make sure the filter holder is not attached and position a recipient

under the outlet.

5. Press the coffee run-off button and run off half the solution in the

tank.Then interrupt by pressing the same button again.

6. Leave the solution to work for about 15 minutes, then run off the

rest of the water in the tank.

7. To eliminate residues of solution and scale, rinse the tank well, fill

with clean water and replace in position.

8. Press the coffee run-off button and allow the water to run off until

the tank is completely empty;

9. Press the coffee run-off button and repeat operations 7 and 8

again.

Repair of damage to the coffee machine caused by scale is not

covered by the guarantee unless descaling is performed

regularly as described above

fig. 27

fig. 26

Descaling the filter coffee section

Formation of scale depends on the hardness of the water and on

how often the coffee machine is used.To obtain optimum perform-

ance, the appliance should be descaled regularly, at least every 40

cycles.

To descale, proceed as follows:

1. Fill the carafe with four cups of water;

2. Dissolve two spoonfuls (about 30 grams) of citric acid (available

from chemists or drug stores) in the carafe and pour the solu-

tion into the water tank.

3. Place the carafe on the hot plate and the filter holder without

ground coffee.

4. Filter the equivalent of two cups then turn the appliance off.

5. Leave the solution to work for 15 minutes, then repeat steps 4

and 5 once again.

6 Turn the appliance on again and allow the rest of the solution

to filter.

7 Rinse by operating the appliance with water only at least three

times (a full carafe each time).

Repairs for malfunctioning caused by problems of calcium

build-up are not covered by the guarantee if the descaling

process described above is not carried out regularly.

Coffee Maker 10

Table des matières

Autres manuels DeLonghi Cafetière

DeLonghi

DeLonghi BCO70 Manuel utilisateur

DeLonghi

DeLonghi DINAMICA plus ECAM37095 Manuel utilisateur

DeLonghi

DeLonghi EC820 Manuel utilisateur

DeLonghi

DeLonghi DC76T Manuel utilisateur

DeLonghi

DeLonghi EC5 Manuel utilisateur

DeLonghi

DeLonghi NESPRESSO Lattissima Touch Manuel utilisateur

DeLonghi

DeLonghi My Machine NESPRESSO EN550.W Manuel utilisateur

DeLonghi

DeLonghi MAGNIFICA EVO Manuel utilisateur

DeLonghi

DeLonghi DC76T Manuel utilisateur

DeLonghi

DeLonghi Essenza Automatic Manuel utilisateur

DeLonghi

DeLonghi NESPRESSO MY MACHINE LATTISSIMA ONE EN640.W Manuel utilisateur

DeLonghi

DeLonghi Nespresso LATTISSIMA PRO EN 750.MB Manuel utilisateur

DeLonghi

DeLonghi NESPRESSO CITIZ & MILK Manuel utilisateur

DeLonghi

DeLonghi NESPRESSO Lattissima+ Manuel utilisateur

DeLonghi

DeLonghi EC860 Manuel utilisateur

DeLonghi

DeLonghi ICMO210 Manuel utilisateur

DeLonghi

DeLonghi ECAM65*.55 series Manuel utilisateur

DeLonghi

DeLonghi DINAMICA PLUS Manuel utilisateur

DeLonghi

DeLonghi Magnifica ESAM3500N Manuel utilisateur

DeLonghi

DeLonghi Nespresso Lattissima+ EN 520 Manuel utilisateur

DeLonghi

DeLonghi Dinamica ECAM35X.15 Manuel utilisateur

DeLonghi

DeLonghi DD1000TC Series Manuel utilisateur

DeLonghi

DeLonghi La Specialista ARTE EC915 Series Manuel utilisateur

DeLonghi

DeLonghi Nespresso LATTISSIMA PRO EN 750.MB Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur

LAVAZZA

LAVAZZA CLASSY PLUS Manuel utilisateur

Black & Decker

Black & Decker DLX900 Instructions d'installation
