DeLonghi BCO120 Manuel utilisateur

instructions

Coffee Maker

Please retain these instructions for future use.

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 1

Coffee Maker 2

Flavour system

filter coffee strength

selector knob

Power supply cable

Large carafe for filter coffee

Small carafe for

espresso/cappuccino

Measuring spoon

Filter for

espresso coffee

Filter

Removable

water reservoir

Flavour savor device

Filter holder

for filter coffee

Tw o cup attachment

for espresso coffee

Filter holder for

espresso coffee

Boiler cap

Steam release

knob

Steam exit tube

Steam nozzle

Vario system

espresso strength

selector knob

Warming plate

Removable drip tray

ON/OFF espresso/cappuccino switch

ON/OFF filter coffee switch

ON espresso/cappuccino light

ON filter coffee light

Boiler outlet

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 2

Thank you for choosing this coffee machine. To get the very

best out of your new coffee machine it is advisable to read

these instructions before using the appliance. This is the only

way to ensure optimum results and maximum safety.

Using for the first time

Before using the machine for the first time, wash all the acces-

sories in warm soapy water and rinse. For the best tasting coffee

the internal circuits must be flushed through at least five times.To

do this follow the instructions in the paragraph “Preparing the fil-

ter coffee” using just water.

To wash the steam boiler, fill the small carafe with water up to

level “4” indicated on the “WATER LEVEL” side, then pour the

water into the boiler and close rotating firmly the safety cap. Press

the cappuccino button and after 5 minutes open the steam knob;

leave the steam knob opened until no more steam comes out: this

means that there is no more water in the boiler.

Installation

• Place the coffee maker on a flat work surface at a safe distance

from taps and sinks.

•After having positioned the appliance on the work bench, make

sure that there is a free space of around 20 cm between the

surfaces of the appliance and the side and rear walls and a free

space of at least 25 cm above the coffee maker.

• Check that the voltage corresponds to that indicated on the

appliance rating plate.The appliance must always be connected

to a well-earthed socket rated at 10A minimum.The manufac-

turer is not liable for damage caused by inadequate earthing of

the appliance.

• In the event of incompatibility between the plug on the appli-

ance and the socket, have the plug replaced by a qualified pro-

fessional.The power cable for this appliance must not be

replaced by the user, in that this operation requires the use of

special tools. In the event of damage, only contact a service cen-

tre authorised by the manufacturer so as to avoid any risks.

• Never install the machine in an environment that can reach a

temperature less than or equal to 0°C (if the water in it

freezes, the coffee maker may be damaged).

Coffee Maker

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 3

fig. 6 fig. 7

Coffee Maker 4

Preparing the filter coffee

• Raise the lid and remove the water reservoir (fig. 1).

• Fill the tank with cold, clean water, up to the level indicated on

the tank corresponding to the number of cups of coffee that

are desired (fig. 2).

• Replace the tank into the machine by pressing down firmly.

If desired, the tank can be left in the machine and the large carafe can

be used to fill it with water. The carafe also has water level indicators on

it (fig. 3).

• Open the filter holder by pulling it towards the right using the

plastic tab (fig. 4).

• Place the filter into the filter holder (fig. 5).

•Put the ground coffee into the filter by using the measuring

spoon included with the machine and level off the grounds

evenly (fig. 6). As a general rule, use a level measure of coffee

(about 7 grams) for each cup required (for example, 10 meas-

ures for 10 cups). However, the quantity of coffee used can be

varied according to personal taste. Use good quality coffee for

filter coffee machines.

•Close the filter holder and place the large carafe complete with

lid onto the warming plate.

•Select the filter coffee flavour as described in the paragraph

“How to choose the flavour of the filter coffee”.

•Press the “ON/OFF” switch for filter coffee (fig. 7). The

ON/OFF indicator light for filter coffee above the switch itself

indicates that the filter machine is functioning properly.

•The brewed coffee will begin to drip out after a few seconds.

During filtration, it is normal for the appliance to give off steam

and for condensation to form near the lid.

•To keep the coffee hot after filtration, place the carafe on the

hot plate and leave the appliance on (coffee ON indicator light):

The coffee in the carafe is kept at the right temperature.

fig. 1

fig. 2

fig. 3

fig. 4

fig. 5

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 4

Coffee Maker

fig. 14 fig. 13

fig. 8

fig. 9

fig. 10

fig. 11

fig. 12

How to choose the flavour of the filter coffee

With the flavour selector, the flavour of the filter coffee can be

selected according to personal taste. By turning the flavour selector

knob (Fig. 8), the coffee maker can be set for coffee with a strong

(STRONG position) or light aftertaste (LIGHT position).

The flavour selector changes the strength of the aftertaste of the

coffee, while the actual taste remains the same.

How to prepare espresso coffee

1. Unscrew the boiler cap by turning it in a anti-clockwise direc-

tion.

2. Fill the small carafe according to the number of cups of espres-

so coffee that are required, using the WATER LEVEL indicators

printed on it (fig. 9) (see the chart page 10).

3. Pour the water into the steam boiler (fig. 10).

4. Replace the boiler cap by turning firmly in a clockwise direc-

tion.

5. Insert the filter for espresso coffee into the filter holder (fig.

11).

6. Fill the filter with the ground coffee, using the measures indicat-

ed in the chart page 10 and level evenly in the filter (without

packing) (fig. 12). It is important to use high quality ground cof-

fee with a medium grind in order to avoid the blocking of the

filter during the brewing.

7. Remove any excess coffee from around the edges of the filter

(fig. 13).

8. To attach the filter holder to the appliance, position it under the

hot water spout with the handle towards the left (fig 14). Push

upwards, and at the same time, turn the handle as far right as

possible. It does not matter if the handle is not centrally aligned

with the machine, as long as the filter holder is firmly attached

to the appliance.

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 5

fig. 18

fig. 19 fig. 20 fig. 21

Coffee Maker 6

fig. 15

fig. 16

fig. 17

9. Place the small carafe under the filter holder (fig. 15), the carafe

lid will slot under the filter holder; be sure that the holes of the

filter holder correpond to the carafe lid’s aperture.

10.Position the “Vario System” selector knob according to the type

of espresso coffee desired: “LIGHT” for a weaker coffee and

“STRONG” for a stronger tasting brew (fig. 16).

11.Make sure that the steam release knob is closed. (to close turn

in a clockwise direction until tightened)

12.Push the ON/OFF switch for espresso/cappuccino.The ON

indicator light for espresso/cappuccino will turn on (fig. 17).

13.After approximately two minutes, the espresso coffee will begin

to flow out (fig. 18).

ATTENTION: to avoid spraying, do not detach the fil-

ter holder while the machine is brewing coffee.

14.When the coffee no longer flows out from the filter holder,

push the espresso/cappuccino ON/OFF switch to turn off the

steam boiler.

15.The coffee can then be served into cups.

15.To remove the used coffee in the filter, detach the filter holder,

from the machine hold the filter in place with the special lever

incorporated on the handle and let the coffee fall out by turn-

ing the filter holder upside down and knocking gently (fig. 19).

ATTENTION: Before removing the filter holder, it is impor-

tant to eliminate all of the residual steam from inside the steam

boiler. Allow the steam to blow out completely by rotating the

steam release knob in an anti-clockwise direction (fig 20).

NOTE: For safety reasons, when the steam boiler is hot, it is not

possible to remove the steam boiler cap; this is a safety feature. If

for any reason it is necessary to remove it, it is important always

to release the steam in the steam boiler by turning the steam

release knob first.

How to use the two cup attachement

The attachment must be used every time coffee is dispensed

directly into a cup. To mount it, simply insert the attachment into

the lower part of the filter holder (fig 21).

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 6

fig. 24

fig. 25

fig. 26

Preparing cappuccino

1. Prepare the espresso coffee as described in the paragraph

“How to prepare espresso coffee” from points 1 to 11; using

the quantity of water required to obtain 2 cappuccinos as indi-

cated in the chart page 10. Note that the quantity of water

required for making cappuccinos is greater that the

amount necessary for making espresso coffee: the extra

water is used for producing steam for frothing the milk.

2. Brew the coffee into the small espresso carafe. When the cof-

fee reaches level 2 on the “coffee level” side of the small

espresso carafe (fig. 22), turn the Vario System selector to “cap-

puccino” (fig. 16). If you allow too much coffee to come

through at this point there will not be enough steam for froth-

ing the milk.

3. Pour the coffee into 2 large cups.

4. Fill a container, ideally a small metal jug, with around 100 grams

of milk for each cappuccino being prepared.

Note: It is recommended to use semi-skimmed milk at fridge

temperature.

5. When choosing the size of the container, remember that the

volume will increase by 2 or 3 times.

6. Hold the jug of milk so that the tip of the steam nozzle is 5 mm

immersed (fig. 23). Gently turn the steam release knob anti -

clockwise (fig. 20) (turning more or less the steam knob, the

quantity of steam will change).

7. The milk will increase its volume and will be creamer.

8. When the volume of milk has doubled, immerse the steam noz-

zle deeper into the milk to continue to froth and heat the milk

(fig. 24). Froth the milk until the steam in the boiler has been

completely used up: this will prevent the milk becoming trapped

inside the steam tube.

9. Press the ON/OFF switch for espresso/cappuccino to turn off

the appliance.

10.Pour the frothed milk over the coffee, with the aid of a spoon.

Then, as a final touch, sprinkle a bit of cocoa powder over the

frothy milk to make a perfect cappuccino.

11.In order to make 4 cappuccinos, it is necessary to repeat the

previous operation, paying attention to the quantity of ground

coffee and water, indicated in the chart page 10. Before turning

the Vario System selector to “cappuccino”, brew the coffee into

the small espresso carafe until it reaches level 4 on the COFFEE

LEVEL side (fig. 25).

IMPORTANT: The steam nozzle must be thoroughly cleaned

after each use. Proceed as follows:

•Unscrew the steam nozzle from the tube by turning in a clock-

wise direction (fig. 26) and wash it thoroughly with warm water.

5 mm

fig. 22

fig. 23

Coffee Maker

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 7

fig. 30

Coffee Maker 8

•Make sure that the three holes in the steam nozzle, illustrated

in fig. 27, are not blocked. If necessary, clean the holes with a

pin or needle.

•Clean the steam exit tube carefully to avoid being burnt.

•Screw the steam nozzle back into place.

CLEANING AND MAINTENANCE

•Before performing any cleaning operations, the machine must

have cooled down and must be disconnected from the mains

power supply.

•Never immerse the machine in the water: it is an electrical

appliance.

•Do not use solvents or abrasive detergents to clean the coffee

maker.A soft damp cloth will suffice.

•Regularly clean the filter holder, the removable drip tray, the

boiler outlet, and the carafes. Do not wash the filter holder in

the dish washer.

•From time to time check that the holes in the filter for espres-

so coffee are not obstructed. If necessary, carefully clean the fil-

ter with hot water, scrubbing with an abrasive pad. (see fig. 28).

Make sure the holes in the metal filter are not blocked. If neces-

sary, clean with a pin (fig. 29).

•To clean the Flavor Savor, remove it from the filter holder mov-

ing it up (fig. 30).Than, after cleaning, reinsert it by pulling from

the top (fig. 30).

DESCALING

Due to the continuous heating of the water used to make the cof-

fee, over time it is normal for the tubing inside the machine to fill

with lime scale.

The espresso coffee machine must be decalcified every 2-6

months (depending on the hardness of the water and the frequen-

cy of use). Proceed as follows:

1. Fill with water the small carafe up to level 4 of the “water

Level” side.

2. Dissolve 1 spoon of citric acid (15-20 grams, available from

chemists or drug stores) .

3. Pour the descaling solution in the boiler and close the cap.

4. Attach the filter holder and ensure that the steam knob is

closed.

5. Place the small carafe under the filter holder for espresso cof-

fee.

6. Turn the Vario System in the “LIGHT” position and turn the

appliance on.

7. After few minutes, the descaling solution will flow in the carafe.

fig. 27

fig. 28

fig. 29

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 8

Coffee Maker

From time to time turn the steam knob and leave a little quan-

tity of solution from the milk frother.

8. When all of the solution has gone through the machine, turn off

the appliance and let it cool down.

9. To rinse the appliance, operate the machine with plain water

(without acid citric) repeating the operations from point 1 to 8

at least 2 times.

The filter coffee machine must be decalcified every 40 cycles

(according to the water hardness). Proceed as follows:

1. Fill with water the carafe up to level 4 CUPS.

2. Dissolve 2 spoons of citric acid (30 grams, available from

chemists or drug stores);

3. Pour the descaling solution in the reservoir and put it in the

appliance;

4. Remove the filter;

5. Place the carafe on the warming plate;

6. Press the ON/OFF filter coffee switch, brew the equivalent of a

cup of the solution and then turn off the appliance.

7. Allow the solution to sit in the machine for an hour;

8. Turn the machine back on and allow the rest of the solution to

filter through the circuits;

9.To rinse the appliance, operate the machine with plain water and

without using ground coffee at least 3 times (3 full tanks of

water).

Repairs for malfunctioning caused by problems of calcium

build-up are not covered by the guarantee if the descaling

process described above is not carried out regularly.

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 9

Coffee Maker 10

Reference table for espresso/cappuccino

To make

Water quantity required

for espresso/cappuccino

to pour in the steam

boiler (small carafe,

“Water level” side)

The quantity of ground

coffee to put into the

filter

2 coffees

2 cappuccinos

4 coffees

4 cappuccinos

- 4

- 2

- 4

- 2

- 4

- 2

- 4

- 2

5732136000 BCO120 UK 4-04-2005 9:38 Pagina 10

Table des matières

Autres manuels DeLonghi Cafetière

DeLonghi

DeLonghi Coffee machine Manuel utilisateur

DeLonghi

DeLonghi EC-610 Manuel utilisateur

DeLonghi

DeLonghi BAR 140USA Manuel utilisateur

DeLonghi

DeLonghi La Specialista ARTE Manuel utilisateur

DeLonghi

DeLonghi ELECTRIC MOKA COFFEE MAKER EMK6 Manuel utilisateur

DeLonghi

DeLonghi ESSENZA MANUAL Manuel utilisateur

DeLonghi

DeLonghi PrimaDonna Elite Experience ECAM65X.85 Manuel utilisateur

DeLonghi

DeLonghi Eletta ECAM45.760.W Manuel utilisateur

DeLonghi

DeLonghi La Specialista EC933X Manuel utilisateur

DeLonghi

DeLonghi ESAM 4200 Manuel utilisateur

DeLonghi

DeLonghi La Specialista ARTE EC9155MB Manuel utilisateur

DeLonghi

DeLonghi Nespresso Lattissima+ EN521.R Manuel utilisateur

DeLonghi

DeLonghi Nespresso VERTUO LATTISSIMA Manuel utilisateur

DeLonghi

DeLonghi La Specialista Maestro Manuel utilisateur

DeLonghi

DeLonghi Magnifica ESAM03.105 Manuel utilisateur

DeLonghi

DeLonghi NESPRESSO VERTUO Manuel utilisateur

DeLonghi

DeLonghi DNS80 Manuel utilisateur

DeLonghi

DeLonghi ECAM37X.95 Manuel utilisateur

DeLonghi

DeLonghi Nespresso My Machine Lattissima Touch Manuel utilisateur

DeLonghi

DeLonghi La Specialista ARTE EC915X Manuel utilisateur

DeLonghi

DeLonghi EC250 Manuel utilisateur

DeLonghi

DeLonghi SER3017 Manuel utilisateur

DeLonghi

DeLonghi ICM16210.WS Manuel utilisateur

DeLonghi

DeLonghi EAM4000 Series Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur

LAVAZZA

LAVAZZA CLASSY PLUS Manuel utilisateur

Black & Decker

Black & Decker DLX900 Instructions d'installation
