About the Product
Industrial wood-fired pizza oven and smoking
oven, ideal for cooking/smoking pizza, sh, meat,
vegetables and much more. Two side shelves
creates additional storage and preparation space.
Features two rear wheels for easy manoeuvrability.
Fuel Source: Untreated wood, logs or charcoal (not
included). Supplied with pizza paddle, cleaning
brush and water resistant cover. Not recommended
for use in strong winds.
Safety Instructions
• This product is intended for outdoor use only.
• DO NOT use indoors.
• Never leave a burning re unattended.
• DANGER of carbon monoxide poisoning.
• NEVER light this product or let it smoulder or
cool down in conned spaces.
• DO NOT use this product in a tent, caravan, car,
cellar, loft or on a boat.
• DO NOT use under awnings, parasols or
gazebos.
• DO NOT overload the unit with fuel.
• FIRE HAZARD - Hot embers may emit while
in use.
• WARNING - DO NOT use petrol, white spirit,
lighter uid, alcohol or other similar chemicals
for lighting or relighting.
• This product is ONLY suitable for use with
wood pellets, wood, logs or charcoal.
• DO NOT use this oven on any other ammable
surfaces.
• Ensure that the oven is positioned at least 2
metres away from ammable items.
• DO NOT use this oven as a furnace.
• DO NOT handle or move the oven whilst alight
as it will be hot.
• ALWAYS USE heat resistant gloves when in
use as the unit will be hot.
• Allow the unit to cool down completely before
moving or storing.
• ALWAYS keep children and pets at a safe
distance from the oven when in use.
• ALWAYS inspect the unit prior to use for
fatigue and damage.
• DO NOT use in high winds.
Assembly
Prior to assembly, read the instructions carefully.
Check all parts against the parts list. Only use
fasteners from the xing kit supplied with this
item. Carry out assembly on a soft surface to
avoid scratching the paint. Wear protective gloves
during assembly. Seek physical assistance during
assembly. Please retain this information for future
reference. For ease of assembly, only loosely
tighten bolts and then tighten fully when assembly
is complete.
IMPORTANT - Remove any packaging before use,
but retain the safety instructions and store them
with this product.
STEP 1 - Attach 1 x trolley legs (8) and (13) to 1 x
short bracket (6) and 2 x long brackets (5) using
6 x M8 bolts, 6 x Φ8 washers and 6 x M8 nuts.
Remember to align left front hole to connect with
handle. Note - The handle cannot be xed here until
the base is assembled.
STEP 2 - Attach 1 x short bracket (6) and 1 x trolley
legs (9 and 10) to STEP 1 half-completed base
using 8 x M8 bolts, 8 x Φ8 washers and 8 x M8
nuts. Fixed 1 x handle (7) to assembled base by
M8 bolts, 2 x Φ8 washers and 2 x M8 nuts.
STEP3 - Feed wheel axle (11) through holes in
wheel trolley section ( 9 and 10) and attach wheels
(12) securing with M12 nut and Φ12 washer per
wheel.
STEP 4 - Attach oven body (2) to assembled base
securing with 4 x Φ6 washer and 4 x M5 bolts.
STEP 5 - Attach chimney (1) to body (2).
STEP 6 - Attach side shelf (3) to left and right side
of well assembled base.
STEP 7 - Attach door (4) to oven body (2).
The oven is now ready to use, but please ensure
your have read these instructions thoroughly prior
to use.
STEP 8 - Once completed, fully tighten all xings
and ensure the oven is stable.
Positioning, Lighting, Usage &
Care Information
• Ensure the oven is positioned on a permanent,
at, level, heat resistant non-ammable
surface away from ammable items.
Refer to
instruction
manual
Wear
protective
gloves
