Dell™ OpenManage™

Client Instrumentation Version 7.6

User’s Guide

Notes and Notices

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarksusedin this text:Dell,the DELL logo, OpenManage,Latitude,OptiPlex, andDell Precision

are trademarks of Dell Inc.; Intel is a trademark of Intel Corporation in the U.S. and other countries;

Altiris is a registered trademark of Altiris Inc.; Microsoft, Windows, and Windows Vista are either

trademarksorregisteredtrademarksofMicrosoftCorporationintheUnitedStatesand/orothercountries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

June 2008

Contents 3

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . 7

CIM Overview . . . . . . . . . . . . . . . . . . . . . . . 7

WMI Overview . . . . . . . . . . . . . . . . . . . . . . . 8

Data Sources Used by OMCI. . . . . . . . . . . . . . . . 8

OMCI Architecture. . . . . . . . . . . . . . . . . . . . . 9

Features . . . . . . . . . . . . . . . . . . . . . . . . . 11

CIM 2.6 Schema Support . . . . . . . . . . . . . . 11

Dell LegacySelect 2.0 Support . . . . . . . . . . . 11

Remote Boot Device Select . . . . . . . . . . . . 12

WMI Security . . . . . . . . . . . . . . . . . . . . 12

Event Reporting . . . . . . . . . . . . . . . . . . . 12

Remote Shutdown . . . . . . . . . . . . . . . . . 13

Remote Wake-Up Configurability. . . . . . . . . . 13

WfM Version 2.0 Compliance. . . . . . . . . . . . 13

What's New . . . . . . . . . . . . . . . . . . . . . . . 13

Supported Operating Systems . . . . . . . . . . . . . . 14

Latest Updates . . . . . . . . . . . . . . . . . . . . . . 14

Other Dell Documents You Might Need . . . . . . . . . 15

Other Resources Which Might Be Of Interest. . . . . . 15

Obtaining Technical Assistance . . . . . . . . . . . . 15

4Contents

2 Installing Dell™ OpenManage™

Client Instrumentation . . . . . . . . . . . . . . 17

User Account Control in Windows Vista . . . . . . . . 18

Local Installation. . . . . . . . . . . . . . . . . . . . . 19

Installing the Client . . . . . . . . . . . . . . . . . 19

Uninstalling the Client. . . . . . . . . . . . . . . . 20

Silent Installation . . . . . . . . . . . . . . . . . . . . 21

Installing the Client in the Silent Mode . . . . . . . 21

Performing a Complete Installation in

Silent Mode . . . . . . . . . . . . . . . . . . . . . 21

Performing a Custom Installation in

Silent Mode . . . . . . . . . . . . . . . . . . . . . 21

Upgrading the Client in Silent Mode . . . . . . . . 22

Uninstalling the Client in Silent Mode . . . . . . . 22

Administrative Installation . . . . . . . . . . . . . . . 23

3 Windows Management

Instrumentation . . . . . . . . . . . . . . . . . . . . 25

WMI Overview . . . . . . . . . . . . . . . . . . . . . . 25

WMI Security. . . . . . . . . . . . . . . . . . . . . . . 25

Retrieving Dell Information With SMS 2.0. . . . . . . . 26

WMI Scripts . . . . . . . . . . . . . . . . . . . . . . . 28

Contents 5

4Alerts. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Overview . . . . . . . . . . . . . . . . . . . . . . . . . 31

ASF Alerting . . . . . . . . . . . . . . . . . . . . . . . 32

WMI Alerting. . . . . . . . . . . . . . . . . . . . . . . 32

5 Component Descriptions . . . . . . . . . . . . . 39

6 Troubleshooting. . . . . . . . . . . . . . . . . . . . 45

Wakeup on LAN . . . . . . . . . . . . . . . . . . . . . 45

Remote Connection to WMI and Remote

BIOS Update . . . . . . . . . . . . . . . . . . . . . . . 45

Installation Problems . . . . . . . . . . . . . . . . . . 48

A Sample Scripts and BIOS Settings . . . . . 49

WMI Sample Scripts. . . . . . . . . . . . . . . . . . . 49

Clear Chassis Intrusion Status . . . . . . . . . . . 49

Disable Desktop Messages for All Alerts . . . . . 51

Remote System Shutdown . . . . . . . . . . . . . 54

Remote System Restart . . . . . . . . . . . . . . . 56

Remote BIOS Update . . . . . . . . . . . . . . . . 58

Enabling PXE Boot on the Next Reboot . . . . . . 61

Enabling Wakeup on LAN . . . . . . . . . . . . . 63

Retrieving Service Tag, Asset Tag, and

BIOS Revision. . . . . . . . . . . . . . . . . . . . 65

Changing BIOS Password . . . . . . . . . . . . . 68

BIOS Settings Supported in OMCI 7.6 . . . . . . . . . . 70

6Contents

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Introduction 7

Introduction

The Dell™ OpenManage™ Client Instrumentation (OMCI) software enables

remote management application programs to access client system information,

monitor the client system status, or change the state of the client system; such

as shutting it down remotely. Through standard interfaces, OMCI exposes key

system parameters allowing administrators to manage inventory, monitor

system health, and gather information on deployed Dell client systems.

OMCI enables Dell client systems to be managed using the Common

Information Model (CIM) standard. CIM reduces your total cost of

ownership, improves security, and provides a holistic approach to managing

all devices in the enterprise, including clients, servers, storage, network, and

software devices.

CIM Overview

The CIM, created by the Desktop Management Task Force (DMTF) as part

of the Web-based Enterprise Management (WBEM) initiative, provides a

unified view of physical and logical objects in the managed environment.

CIM is a systems management protocol defined by industry standards.

The following are important CIM details:

• CIM is an object

oriented data model for describing management

information. CIM describes the way the data is organized, not necessarily

the transport model used to transport the data. The most prevalent

transport method is the Microsoft

Windows

Management

Instrumentation (WMI).

•CIM

capable management applications gather information from a variety

of CIM objects and devices, including client and server systems, network

infrastructure devices, and applications.

• The CIM specification details mapping techniques for improved

compatibility with other management protocols.

8Introduction

• The CIM data model abstracts and describes all elements in a network

environment. The CIM schema provides the actual data model

descriptions and arranges the network into a series of managed objects,

all interrelated and broadly classified.

• The CIM schema is defined by the Managed Object Format (MOF) file,

which provides a standardized model for describing management

information between clients in a management system. The MOF file is not

bound to a particular implementation, and it allows the interchange of

management information between many different management systems

and clients.

WMI Overview

WMI is Microsoft's implementation of CIM instrumentation. WMI supports

CIM and Microsoft-specific CIM extensions. The WMI management

infrastructure also includes the CIM Object Manager (CIMOM), which is

the interface and manipulation point for CIM objects and information.

It acts as a facilitator in gathering information and manipulating object

properties. OMCI provides data to WMI, which is the common interface

to WMI management applications. For more information, see "Windows

Management Instrumentation."

Data Sources Used by OMCI

OMCI contains the underlying driver set that collects system information from a

number of different sources on the client system, including the BIOS, CMOS,

System Management BIOS (SMBIOS), System Management Interface (SMI),

operating system, Application Programming Interfaces (APIs), Dynamic Link

Libraries (DLLs), and registry settings. OMCI exposes that information through

the CIMOM interface of the WMI stack and enables IT administrators to

remotely collect asset information, modify CMOS settings, receive proactive

notification of potential fault conditions, and be alerted to potential security

breaches.

Introduction 9

OMCI uses a variety of data sources resident on the client system which

includes:

• Microsoft Win32 WMI providers

•SMBIOS

• Device drivers

• Operating system registry

• Operating system Application Programming Interfaces (APIs)

• WMI repository

OMCI Architecture

The OMCI architecture is based on a layered model that is tightly integrated

with the Microsoft WMI stack as shown in Figure 1-1.

•

WMI application layer

— C

onsists of management applications such as

Dell Client Manager, Dell OpenManage Client Administrator (OMCA),

and other standards-based management tools and WMI applications

such as Microsoft SMS, LANDesk, and so on. This layer is not a part of

OMCI and the applications are consumers of systems management data

supplied from the client by OMCI. These applications request client

information and receive client alerts through the CIMOM.

•

Dell WMI provider

— Lies

beneath the CIMOM and contains two CIM

providers which register with the CIMOM. When the CIMOM receives

a request for information, it routes the request to the appropriate

provider. Both Dell and Microsoft providers exist in this layer, and they

provide information on system devices. The providers

send management

application requests from the CIMOM to the data router.

•

Data router

— C

ollects information from system components in the

data provider layer and passes the information up to the Dell WMI

provider layer,

which then presents it to the CIMOM.

•

Data provider

— Provides data to the data router. When it receives a

request from the data router, the data provider queries the client system's

hardware, drivers, and operating system to determine the available

instrumentation. It then applies all platform and customer overrides to the

data before returning it to the data router.

10 Introduction

For example, a management console in the WMI application layer requests

the available free space on the client system hard drive. The WMI application

layer makes the request over the network to the CIMOM (in the Dell WMI

provider layer) on the client system. The CIMOM routes the request to the

appropriate WMI provider, which, in turn, routes the request through the

data router layer to the disk data provider in the data provider layer. The

information is then returned (through the same path in reverse) to the

management console.

NOTE: OMCI 7.6 and later versions will not be supported by Dell OpenManage

IT Assistant (ITA) 8.x.

Figure 1-1. Dell OpenManage Client Instrumentation Architecture

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dell Logiciel

Dell

Dell PowerVault 770N Manuel utilisateur

Dell

Dell Server Manuel utilisateur

Dell

Dell DX6000 Guide de référence rapide

Dell

Dell PowerConnect W-Airwave Manuel utilisateur

Dell

Dell PowerConnect W-Airwave Manuel utilisateur

Dell

Dell PowerEdge 180AS Manuel utilisateur

Dell

Dell DX6000 Manuel utilisateur

Dell

Dell PowerVault MD3200 Series Manuel utilisateur

Dell

Dell DVS Simplified Appliance Tower Manuel de service

Dell

Dell PowerConnect W-Airwave Manuel utilisateur

Dell

Dell DX6000 Manuel utilisateur

Dell

Dell PowerVault 701N Manuel utilisateur

Dell

Dell PowerVault MD3060e Series Manuel de l'opérateur

Dell

Dell Color Laser Printer 2130cn Comment utiliser

Dell

Dell PowerEdge UPS 500T Manuel utilisateur

Dell

Dell PowerVault MD3000i Manuel utilisateur

Dell

Dell PowerConnect W-Airwave Manuel utilisateur

Dell

Dell PowerConnect W-Airwave Manuel utilisateur

Dell

Dell PowerConnect W-Airwave Manuel utilisateur

Dell

Dell DX6000 Manuel utilisateur

Dell

Dell PowerVault MD3600f Series Manuel utilisateur

Dell

Dell OpenManage Network Manager Manuel utilisateur

Dell

Dell DX6000 Mode d’emploi

Dell

Dell PowerConnect W-Airwave Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur
