Dell PowerEdge 6850 Manuel technique

www.dell.com | support.dell.com

Dell™ PowerEdge™ 6850 Systems

Information Update

信息更新

Mise à jour des informations

Aktuelle Informationen

アップデート情報

설명서 갱신본

Actualización de información

www.dell.com | support.dell.com

Dell™ PowerEdge™ 6850 Systems

Information Update

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the

problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarksusedinthistext:Dell,theDELLlogo,andPowerEdgearetrademarksofDellInc.;IntelisaregisteredtrademarkofIntelCorporation;

MicrosoftandWindowsareregisteredtrademarksandWindowsServerisatrademarkofMicrosoftCorporation;RedHatisaregisteredtrademark

of Red Hat Corporation; SUSE is a registered trademark of SUSE LINUX Products GmbH.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

September 2006 P/N F3412 Rev. A08

Information Update 3

This document provides updated information for your system on the following topics:

• Expansion-card slot restrictions

–Intel

PRO/1000 MT dual-port server adapter expansion-card slot 2 restriction

– Adaptec SCSI Card 39160 expansion-card slot restriction

• System start-up behavior

• Integrated NIC IPMI port functionality

• Remote Access Controller card interaction with integrated video

• System and status messages

– System screen messages

– LCD status messages

• IRQ5 availability

• Environmental data sheets

• Removing and installing a hot-pluggable memory riser card

• Hot-adding a memory riser card

• Processor upgrades

• Memory test at system startup

• Linux operating system information

– Booting Red Hat

Enterprise Linux AS (Version 4) for Intel x86 with more than eight logical

processors

– Using more than eight logical processors with Red Hat Enterprise Linux (Version 4)

for Intel Extended Memory 64 Technology (Intel EM64T)

– Rebooting Red Hat Enterprise Linux AS (Version 4) for Intel EM64T

– NIC device names

• Microsoft

Windows Server

™

2003 installation with more than eight logical processors

• Microsoft Windows

2000 installation

• Console redirection—escape key sequences

4Information Update

Expansion-Card Slot Restrictions

Intel PRO/1000 MT Dual-Port Server Adapter Expansion-Card Slot 2 Restriction

Do not install an Intel PRO/1000 MT dual-port server adapter card in expansion-card slot 2. Your

system’s expansion-card slot 2 is a hot-pluggable PCI-X connector, and the Intel PRO/1000 MT dual-port

server adapter card does not support hot-pluggable slot capabilities. If this adapter model is installed in

slot 2 and the AC power cord is disconnected from the system or if AC power is lost, the card is not

detected by BIOS when the system is turned on.

NOTE: Although the slot 2 indicator is green after the system is turned on following an AC power loss,

the Intel PRO/1000 MT dual-port server adapter card is not detected by BIOS.

This restriction does not apply to the Intel PRO/1000 MT single-port server adapter card.

Adaptec SCSI Card 39160 Expansion-Card Slot Restriction

If you add an Adaptec SCSI Card 39160 to a system running the Microsoft Windows 2000 Server

operating system, and a Dell™ Remote Access Controller 4/P (DRAC 4/P) card is installed in expansion-

card slot 7, the Adaptec 39160 card must be installed in expansion-card slot 2.

System Start-Up Behavior

The following system behaviors during system start-up are normal and do not indicate a problem with

the system:

• When AC power is applied to the system, if the System Setup program’s

AC Power Recovery

option is

not set to allow the system to power up when AC power is applied, the cooling fans will spin-up briefly

and then stop. (See your

User’s Guide

for information on the System Setup program.)

• It may take 30 seconds or longer for video to display after the system is powered on.

Integrated NIC IPMI Port Functionality

If you configure the integrated NIC for Intelligent Platform Management Interface (IPMI) pass-through

traffic, and you also configure the system to boot from the network using the same IPMI port, the NIC

will not be available for management traffic during system boot. After system boot is completed, IPMI

functionality is automatically restored.

In addition, if you configure the NIC to support IPMI management traffic, the NIC driver’s

Large-Send Offload (LSO) feature will be disabled on that port.

Remote Access Controller Card Interaction With Integrated Video

If you install an optional remote access controller card for remote systems management, the system’s

front and back panel video ports will be disabled.

Information Update 5

System and Status Messages

System Screen Messages

Table 1-1 provides an additional system message that your system may display on the screen.

See "System Messages" in your Installation and Troubleshooting Guide for information about

other system messages.

LCD Status Messages

Table 1-2 provides an updated list of system status messages that the system’s front-panel LCD may

display at system startup if a memory error occurs. See "System Messages" in your Installation

and Troubleshooting Guide for additional information about system messages.

Table 1-1. System Messages

Line 1

Message

Line 2

Message

Causes

E1000 FAIL SAFE Failsafe event.

Table 1-2. LCD Status Messages

Line 1

Message

Line 2

Message

Causes Corrective Actions

SYSTEM

SYSTEM NAME SYSTEM ID is a unique name,

five characters or less, defined

by the user.

SYSTEM NAME is a unique

name, 16 characters or less,

defined by the user.

The system ID and name display

under the following conditions:

• The system is powered on.

• The power is off and active

POST errors are displayed.

This message is for information

only.

You can change the system ID

and name in the System Setup

program. See your User's Guide

for instructions.

E0000 OVRFLW CHECK LOG LCD overflow message.

A maximum of three error

messages can display sequentially

on the LCD. The fourth message

displays as the standard overflow

message.

Check the SEL for details

on the events.

6Information Update

E1000 FAIL SAFE Failsafe event. Capture the event log and

see "Getting Help" in your

Installation and Troubleshooting

Guide.

E1000 MISCONFIG Missing or improperly installed

VRMs.

See "Installing a Processor VRM"

in your Installation

and Troubleshooting Guide. If the

VRMs appear to be properly

configured and installed, see

"Getting Help" in your

Installation and Troubleshooting

Guide.

E0119 TEMP AMBIENT Ambient system temperature is

out of acceptable range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0119 TEMP PROC # The specified processor is out of

acceptable temperature range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0119 TEMP PLANAR System board temperature is out

of acceptable temperature range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0212 PROC VTT Processor VTT voltage is out

of acceptable voltage range.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

E0212 VOLT PG nSystem power supply is out of

acceptable voltage range; faulty

or improperly installed power

supply.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

E0212 VOLT PG nVideo Video voltage is out of acceptable

voltage range.

See "Getting Help" in your

Installation and Troubleshooting

Guide.

E0212 VOLT BATT ROMB Faulty RAID battery. Replace the RAID battery.

See "Activating the Optional

Integrated RAID Controller"

in your Installation

and Troubleshooting Guide.

Table 1-2. LCD Status Messages (continued)

Line 1

Message

Line 2

Message

Causes Corrective Actions

Information Update 7

E0212 VOLT BATT CMOS Faulty system battery. See "Troubleshooting the System

Battery" in your Installation

and Troubleshooting Guide. If the

problem persists, see "Getting

Help" in your Installation

and Troubleshooting Guide.

E0276 PROC # STATUS Faulty or improperly installed

processor.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

E0276 PROC # VCORE The VCORE voltage of the

specified processor is out of

acceptable range.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide. If the problem still

persists, see "Getting Help"

in your Installation

and Troubleshooting Guide.

E0276 VRM # PG The voltage of the specified VRM

is out of acceptable range.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide. If the problem still

persists, see "Getting Help"

in your Installation

and Troubleshooting Guide.

E0276 VCACHE # PG The voltage of the specified

VCACHE is out of acceptable

range.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide. If the problem still

persists, see "Getting Help"

in your Installation

and Troubleshooting Guide.

E0276 PS AC CURRENT Power supply AC current is out

of acceptable range.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

E0276 PS OVER CURRENT Power supply current is out

of acceptable range.

See "Troubleshooting Power

Supplies" in your Installation

and Troubleshooting Guide.

Table 1-2. LCD Status Messages (continued)

Line 1

Message

Line 2

Message

Causes Corrective Actions

8Information Update

E0412 RPM FAN PS BLANK Power supply fan RPM is out

of acceptable range.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0412 RPM FAN n

FAN REDUNDANCY

LOST

Specified cooling fan is faulty,

improperly installed, or missing.

See "Troubleshooting System

Cooling Problems" in your

Installation and Troubleshooting

Guide.

E0780 PROC # CONFIG

ERR

The specified processor has a

configuration error.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

E0780 PROC # DISABLED The specified processor is

disabled.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

E0780 PROC nPRESENCE Microprocessor is not installed

in socket n.

Install a microprocessor in socket

n. See "Installing a Processor"

in your Installation

and Troubleshooting Guide.

E07F0 PROC nIERR Faulty or improperly installed

microprocessor.

See "Troubleshooting the

Microprocessors" in your

Installation and Troubleshooting

Guide.

Table 1-2. LCD Status Messages (continued)

Line 1

Message

Line 2

Message

Causes Corrective Actions

Autres manuels pour PowerEdge 6850

Table des matières

Langues :

Autres manuels Dell Serveur

Dell

Dell Force10 S2410-01-10GE-24P Manuel utilisateur

Dell

Dell PowerEdge 2410 Manuel utilisateur

Dell

Dell PowerEdge C6100 Manuel utilisateur

Dell

Dell EMC PowerEdge R940 Instructions de montage

Dell

Dell PowerEdge C2100 Manuel utilisateur

Dell

Dell PowerEdge M610x Guide de démarrage rapide

Dell

Dell EMC ScaleIO Ready Node 14G Manuel utilisateur

Dell

Dell PowerEdge C6145 Manuel utilisateur

Dell

Dell PowerEdge 1750 Manuel utilisateur

Dell

Dell Dimension 2400 Series Manuel utilisateur

Dell

Dell Active Fabric Manager Manuel utilisateur

Dell

Dell Olympus O-T600 Manuel

Dell

Dell PowerEdge T105 Systems Manuel utilisateur

Dell

Dell PowerEdge R210 II Guide de démarrage rapide

Dell

Dell PowerEdge 4600 Manuel utilisateur

Dell

Dell E69S001 Manuel utilisateur

Dell

Dell PowerEdge C8000 Manuel utilisateur

Dell

Dell PowerEdge T430 Manuel utilisateur

Dell

Dell Poweredge el Manuel utilisateur

Dell

Dell PowerEdge 1400SC Manuel du propriétaire

Dell

Dell PowerEdge R620 Manuel utilisateur

Dell

Dell PowerEdge T110 II Guide de démarrage rapide

Dell

Dell PowerEdge R520 Guide de démarrage rapide

Dell

Dell Poweredge metered Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur

Planet

Planet NAS-7410 Manuel utilisateur

Lenovo

Lenovo ThinkSystem SR635 V3 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX900 Manuel utilisateur

Asus

Asus RS700DA-E6 PS4 Manuel utilisateur
