Installing or Replacing an ERA/O Card 1-1

This document explains how to install and remove your system’s Embedded Remote Access

Option (ERA/O) card.

Before You Begin

NOTE: For more information about setting up and using an ERA/O card, see the

remote access controller (RAC) documentation provided on the documentation CD that

came with your system or on the Dell Support website at support.dell.com.

NOTE: The Dell™ Remote Access Card III (DRAC III), DRAC III/XT, Embedded

Remote Access (ERA), and the ERA/O are systems management hardware and

software solutions designed to provide remote management capabilities for

PowerEdge™ systems. Collectively, these solutions are known as remote access

controllers (RACs). RACs allow you to remotely manage and monitor your system even

when the system is down.

Before installing the ERA/O card, record the system configuration settings. View the system

configuration screens in the System Setup program and make a note of each setting. See

your User's Guide for instructions about using the System Setup program.

Installing an ERA/O Card

CAUTION: Only trained service technicians are authorized to remove the system

cover and access any of the components inside the system. See your System

Information Guide for complete information about safety precautions, working

inside the computer, and protecting against electrostatic discharge.

1Remove the optional front bezel (if applicable).

2Turn off the system, including attached peripherals, and disconnect the system and

peripherals from their electrical outlets.

3Remove the optional security screw (if applicable). See Figure 1-1.

4Press the latch on the system front panel and lift the left cover.

5Lift the right cover.

K0238ebk0.book Page 1 Monday, February 24, 2003 2:53 PM

1-2 Installing or Replacing an ERA/O Card

www.dell.com | support.dell.com

Figure 1-1. Opening the System Covers

6Remove the SCSI backplane board:

aPull each hard-drive carrier partially out of its slot, approximately 2.5 cm (1 inch).

bDisconnect the diskette-drive interface cable from the FLOPPY connector on the

backplane board. See Figure 1-2.

cDisconnect the CD drive interface cable from the CD_ROM connector on the

backplane board. See Figure 1-2.

dPress the release latch in toward the backplane board and use the handle to pull

the board out of its connector and up out of the chassis. See Figure 1-2.

latch

optional security screw

right cover

left cover

K0238ebk0.book Page 2 Monday, February 24, 2003 2:53 PM

Installing or Replacing an ERA/O Card 1-3

Figure 1-2. SCSI Backplane Board

7If the system has an optional ROMB card installed, remove the ROMB backup battery

(not the ROMB card itself) to expose the ERA/O card connector.

See Figure 1-3; see also "Removing a ROMB Card" in your Installation and

Troubleshooting Guide.

8Unpack the ERA/O card.

If you are replacing an ERA/O card, see "Removing an ERA/O Card" for removal

instructions before continuing with the next step.

CD drive interface

connector (CD_ROM)

diskette drive interface connector

(FLOPPY)

handle

release latch

tabs (2)

K0238ebk0.book Page 3 Monday, February 24, 2003 2:53 PM

1-4 Installing or Replacing an ERA/O Card

www.dell.com | support.dell.com

Figure 1-3. Removing the ROMB Backup Battery

9Install the ERA/O card in the ERA/O card connector (EMBEDDED_REMOTE_

ASSISTANT) on the system board. See Figure 1-4.

aAlign the connector on the bottom of the ERA/O card with the ERA/O connector

on the system board; align the holes along the edges of the card with the center

posts of the four retention clips on the system board.

bPress the card down into the connector and onto the retention clip posts until the

clips snap into place around the card and the card is fully seated into the

connector.

ROMB backup

battery

RAID BATTERY connector

battery standoffs (2)

ROMB card

ERA/O card

connector

K0238ebk0.book Page 4 Monday, February 24, 2003 2:53 PM

Installing or Replacing an ERA/O Card 1-5

Figure 1-4. Installing the ERA/O Card

10 If you removed a ROMB backup battery in step 7, replace the battery. See Figure 1-3;

also see "Installing a ROMB Card" in your Installation and Troubleshooting Guide.

11 Replace the SCSI backplane. See Figure 1-2.

aFit the metal tabs at each end of the backplane into the slots in the chassis wall,

and lower the backplane into the chassis, ensuring that the CD and diskette drive

interface cables are not caught under the backplane.

bPress down firmly over the handle to seat the backplane in its connector.

cPivot the release latch out into the securing slot in the chassis.

dConnect the CD drive interface cable to the CD_ROM connector on the

backplane board.

eConnect the diskette-drive interface cable to the FLOPPY connector on the

backplane board.

fPress all installed hard drives firmly back into the SCSI connectors on the

backplane.

12 Close the system covers.

When closing the covers, close the right (larger) cover first and then close the left

cover. Press firmly on the left cover to snap the securing latch into place.

13 Install the optional security screw (if applicable). See Figure 1-1.

ERA/O card

retention clips (4)

ERA/O card connector

K0238ebk0.book Page 5 Monday, February 24, 2003 2:53 PM

1-6 Installing or Replacing an ERA/O Card

www.dell.com | support.dell.com

14 Reconnect the system and peripherals to their electrical outlets, and turn them on.

15 Install the optional front bezel (if applicable).

16 If the 100-Mbps RAC Ethernet connector on the back of the system has not been used

before, you must remove the thin plastic cover that protects the connector.

You can insert your finger underneath the silver strip at the top of the cover to tear

away the cover. See Figure 1-5 for the location of the connector.

17 Connect a network cable to the RAC Ethernet connector. See Figure 1-5.

Figure 1-5. RAC Ethernet Connector

18 Update the ERA/O card with the latest version of the ERA/O firmware, available at the

Dell Support website at support.dell.com.

See the RAC documentation provided on the documentation CD for

information about updating the firmware.

RAC Ethernet connector
