Dell UltraSharp UP2716DA Manuel utilisateur

Model:UP2716DA

Regulatory model: UP2716Dt

Dell UltraSharp

UP2716DA

User’s Guide

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions.

All other marks and names mentioned herein may be trademarks of their respective companies.

2020 – 11 Rev. A00

Contents

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About Your Monitor ..................................... 6

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Identifying Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Monitor Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

LCD Monitor Quality and Pixel Policy. . . . . . . . . . . . . . . . . . . . . . .21

Ergonomics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Handling and moving your display . . . . . . . . . . . . . . . . . . . . . . . 24

Maintenance guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Setting Up the Monitor.................................. 26

Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Using the Tilt, Swivel, and Vertical Extension . . . . . . . . . . . . . . . . . 29

Adjusting the Rotation Display Settings of Your System . . . . . . . . . . 30

Connecting Your Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Organizing Your Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Removing the Monitor Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Wall Mounting (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Contents | 3

4| Contents

Operating the Monitor .................................. 35

Turning on the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Using the Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . 35

Using the On-Screen Display (OSD) Menu . . . . . . . . . . . . . . . . . . . 38

Troubleshooting ....................................... 57

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Product Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Appendix .............................................. 63

FCC Notices (U.S. only) and Other Regulatory Information . . . . . . . . 63

Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

EU product database for energy label and product information sheet . . 63

| 5

Safety Instructions

For displays with glossy bezels the user should consider the placement of the display as

the bezel may cause disturbing reflections from surrounding light and bright surfaces.

WARNING: Use of controls, adjustments, or procedures other than those

specified in this documentation may result in exposure to shock, electrical

hazards, and/or mechanical hazards.

For information on safety instructions, see the Safety, Environmental, and Regulatory

Information (SERI).

6| About Your Monitor

About Your Monitor

Package Contents

Your monitor ships with the components shown below. Make sure that you have

received all the components and contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Somefeatures or media may not be available in certain countries.

Monitor

Stand riser

Stand base

Power cable (varies by country)

About Your Monitor | 7

USB 3.0 upstream cable (enables

the USB ports on the monitor)

DP cable (mDP to DP)

• Quick Setup Guide

• Safety and Regulatory Information

• Factory Calibration Report

Product Features

The Dell UltraSharp UP2716DA monitor has an active matrix, thinfilm transistor (TFT),

liquid crystal display (LCD), and LED backlight. The monitor features include:

• 68.47 cm (27-inch) active area display (Measured diagonally) 2560 x 1440

resolution, plus full-screen support for lower resolutions.

• Tilt, swivel, pivot and vertical extension adjustment capabilities.

• Removable pedestal and Video Electronics Standards Association (VESA™) 100 mm

mounting holes for flexible mounting solutions.

• Ultra-thin bezel minimizes the bezel gap in multi-monitor usage, enabling easier

set up with an elegant viewing experience.

• Extensive digital connectivity with DP, mDP, HDMI, and USB 3.0 helps future-proof

your monitor.

• High Dynamic Contrast Ratio (2,000,000:1) .

• Supports major industry standards: 100% AdobeRGB, 100% sRGB, 100% REC709,

98% DCI-P3.

• Plug and play capability if supported by your system.

• On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

• Security lock slot.

• Asset Management Capability.

• RoHS compliant.

• BFR/PVC Free monitor (excluding cables).

• TCO Certified Displays.

• Arsenic-Free glass and Mercury Free for Panel only.

• ≤ 0.3 W in Standby Mode.

• Energy Gauge shows the energy level being consumed by the monitor in real time.

8| About Your Monitor

Identifying Parts and Controls

Front view

Front panel controls

Label Description

1Function buttons (For more information, see Operating the Monitor)

2Power on/off button (with LED indicator)

Solid white light indicates the monitor is turned on and functioning normally.

Blinking white light indicates the monitor is in Standby Mode.

About Your Monitor | 9

Back View

Label Description Use

1VESA mountiong holes (100 mm

x 100 mm-behind attached VESA

cover)

Wall mount monitor using VESA-

compatible wall mount kit (100 mm x 100

mm).

2Regulatory label Lists the regulatory approvals.

3Stand release button Release stand from monitor.

4Security lock slot Secures monitor with security cable lock

(sold separately).

5Barcode, serial number, and Service

Tag label

Refer to this label if you need to contact

Dell for technical support.

6Dell soundbar mounting slots Attaches the optional Dell soundbar.

NOTE: Please remove the plastic strip

covering the mounting slots before affixing

the Dell Soundbar.

Dell soundbar is sold separately.

7Cable management slot Use to organize cables by placing them

through the slot.

10 | About Your Monitor

Side View

Bottom View

Label Description Use

1AC power connector To connect the monitor power cable.

2a HDMI 1 connector Connect your computer with HDMI cable devices .

2b HDMI 2 connector

3DP connector (in) Connect your computer with DP cable.

4mDP connector (in) Connect your computer with mDP to DP cable.

5DP connector (out) DP output for MST (multi-stream transport) capable

monitor. DP 1.1 monitor can only be connected as

the last monitor in the MST chain. To enable MST,

refer to instruction on section “Connecting the

Monitor for DP MST Function”.

NOTE: Remove the rubber plug when use DP out

connector.

USB downstream port

Port with lightning icon is for BC 1.2
