Dell SE2716H Manuel utilisateur

Model: SE2716H

Regulatory model: SE2716Ht

Dell SE2716H Monitor

User’s Guide

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

Dell™and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions. All

other marks and names mentioned herein may be trademarks of their respective companies.

2015 – 08 Rev. A00

Contents

About Your Monitor ..................................... 5

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Identifying Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Monitor Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

LCD Monitor Quality and Pixel Policy. . . . . . . . . . . . . . . . . . . . . . .17

Setting Up the Monitor.................................. 18

Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting Your Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Organizing Your Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Removing the Monitor Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Operating the Monitor .................................. 23

Turning on the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using the Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using the On-Screen Display (OSD) Menu . . . . . . . . . . . . . . . . . . . 25

Using Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Troubleshooting ....................................... 39

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Contents | 3

4| Contents

Product Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Mobile High-Definition Link (MHL) Specific Problems. . . . . . . . . . . . 44

Speakers Specific Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Appendix ..............................................45

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

FCC Notices (U.S. only) and Other Regulatory Information . . . . . . . . 45

Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Setting Up Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

About Your Monitor | 5

About Your Monitor

Package Contents

Your monitor ships with the components shown below. Make sure that you have

received all the components and contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Somefeatures or media may not be available in certain countries.

Monitor

Stand riser

Stand base

Power cable (varies by country)

HDMI cable

6| About Your Monitor

•Drivers and documentation media

•Quick Setup Guide

•Safety and Regulatory Information

Product Features

The Dell SE2716H curved monitor has an active matrix, thin-film transistor (TFT), liquid

crystal display (LCD), and light emitting diode (LED) backlight. The monitor features

include:

• 68.58cm (27-inch) viewable area display (measured diagonally).

1920x1080 resolution with full-screen support for lower resolutions.

• Wide viewing angle to allow viewing from a sitting or standing position, or while

moving from side-to-side.

• Mega dynamic contrast ratio (8,000,000:1).

• Tilt capability.

• Ultra-thin bezel minimizes the bezel gap in multi-monitor usage, enabling easier

set up with an elegant viewing experience.

• HDMI(MHL) offers seamless connectivity to secondary devices such as select

smartphones , DVD players, gaming consoles etc.

• Removable stand.

• Plug and play capable if supported by your system.

• Color gamut of 85% (typical).

• On-screen display (OSD) adjustments for easy setup and screen optimization.

• Software and documentation media includes an information file (INF), Image-color

matching file (ICM), and product documentation.

• Dell display manager software (available on the disc shipped with the monitor).

• Energy saver feature for energy star compliance.

• Security-lock slot.

• Capability of switching from wide aspect to standard aspect ratio while maintaining

image quality.

• EPEAT Silver rating.

• BFR/PVC- reduced.

• TCO-certified displays.

• Arsenic-free glass and mercury-free for the panel only.

• 0.3 W standby power when in the sleep mode.

• Energy gauge shows the energy level being consumed by the monitor in real time.

• Analog backlight dimming control for flicker free display.

About Your Monitor | 7

Identifying Parts and Controls

Front view

Label Description

1Function buttons (For more information, see Operating the Monitor)

2Power on/off button (with LED indicator)

Back View

Label Description Use

1Security-lock slot Secures monitor with security lock

(sold separately).

2Barcode, serial number, and

Service Tag label Refer to this label if you need to contact

Dell for technical support.

3Regulatory label Lists the regulatory approvals.

4Letter etching Lists the regulatory approvals.

5Cable-management slot Use to organize cables by placing them

through the slot.

8| About Your Monitor

Bottom View

Label Description Use

1AC power connector To connect the monitor power cable.

2HDMI (MHL) 1 port Connect your computer with HDMI cable or

portable device with MHL cable.

3HDMI (MHL) 2 port Connect your computer with HDMI cable or

portable device with MHL cable.

4VGA port Connect your computer with VGA cable (optional).

5Audio-in port Connect to your computer audio output (optional).

6Headphone port WARNING: Excessive sound pressure from

earphones or headphones can cause hearing

damage or loss.

Monitor Specifications

Flat Panel Specifications

Screen type Active matrix - TFT LCD

Panel type Vertical Alignment

Panel curvature 4000 mm radius

Viewable image:

Diagonal 68.58 cm (27 inches)

Active Area:

Horizontal 597.36 mm (23.52 inches)

Vertical 336.31 mm (13.24 inches)

Area 200898.14 mm2(311.40inch2)

Pixel pitch 0.3114 mm x 0.3114 mm

Viewing angle:

Horizontal 178° (typical)

About Your Monitor | 9

Vertical 178° (typical)

Luminance output 300 cd/m² (typical)

Contrast ratio 3000 to 1 (typical)

8,000,000 to 1 (mega dynamic contrast on)

Faceplate coating AG type, Haze 2.3% , Hard coating (2H)

Backlight White LED Edge slim Backlight

Response time Fast mode: 6ms grey-to-grey (typical)

Normal mode: 8ms grey-to-grey (typical)

Color depth 16.7 million colors

Color gamut 85% (typical)*

*SE2716H Color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test

standards.

Resolution Specifications

Horizontal scan range 30 kHz to 83 kHz (automatic)

Vertical scan range 56 Hz to 76 Hz (automatic)

Maximum preset resolution 1920x1080 at 60 Hz

Video display capabilities

(VGA & HDMI & MHL playback)

480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Preset Display Modes

Display Mode

Horizontal

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/

Vertical)

VESA, 720 x 400 31.5 70.0 28.3 -/+

VESA, 640 x 480 31.5 60.0 25.2 -/-

VESA, 640 x 480 37.5 75.0 31.5 -/-

VESA, 800 x 600 37.9 60.0 40.0 +/+

VESA, 800 x 600 46.9 75.0 49.5 +/+

VESA, 1024 x 768 48.4 60.0 65.0 -/-

VESA, 1024 x 768 60.0 75.0 78.8 +/+

VESA, 1152 x 864 67.5 75.0 108.0 +/+

VESA, 1280 x 1024 64.0 60.0 108.0 +/+

VESA, 1280 x 1024 80.0 75.0 135.0 +/+

VESA, 1600 x 1200 75.0 60.0 162.0 +/+

VESA, 1920x1080 67.5 60.0 148.5 +/+

10 | About Your Monitor

MHL Source Display Modes

Display Mode Frequency (Hz)

640 x 480p 60

720 x 480p 60

720 x 576p 50

720 (1440) x 480i 60

720 (1440) x 576i 50

1280 x 720p 60

1280 x 720p 50

1920x1080i 60

1920x1080i50

1920x1080p 30

1920x1080p 60

1920x1080p 50

Electrical Specifications

Video input signals •Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm

input impedance

•HDMI 1.4 (MHL 2.0), 600mV for each dierential line, 100

ohm input impedance per dierential pair

Synchronization input

signals

Separate horizontal and vertical synchronization,

polarity-free TTL level, SOG (Composite SYNC on green)

AC input voltage/

frequency/current

100-240 VAC / 50 or 60 Hz ± 3 Hz / 1.5 A (maximum)

Inrush current 120 V:30 A (Max.) at 0 °C (cold start)

240 V:60 A (Max.) at 0 °C (cold start)

Speaker Specifications

Speaker rated power 2 x (3 W + 6 W)

Frequency response 100 Hz - 20 kHz

Impedance 8 ohm
