Dell S3423DWC Manuel utilisateur

Model: S3423DWC

Regulatory model: S3423DWCc

Dell S3423DWC

Dell Display Manager

User’s Guide

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective

owners.

2022 – 03

Rev. A00

Contents | 3

Contents

Overview ....................................................... 4

Using the Quick Settings dialog box................. 5

Setting basic display options........................... 7

Assigning preset modes to applications............ 9

Organizing windows with Easy Arrange ...........10

Managing multiple video inputs ...................... 13

Restoring application positions ...................... 14

Attach DDM to the active window................... 16

Setting energy conservation options............... 17

Other shortcut keys ...................................... 18

Troubleshooting............................................ 19

4| Overview

Overview

Dell Display Manager(DDM) is an application that allows users to configure their

supported Dell monitor settings such as brightness, contrast, and preset modes.

After its installation, DDM is accessible from the notification tray. Information about

monitors connected to the system is available when the mouse is hovered over the

notification-tray icon.

S3423DWC

NOTE: DDM uses Display Data Channel Command Interface (DDC/

CI) channel to communicate with your monitor. Ensure that DDC/CI is

enabled in the menu as shown in the following image:

Dell 34 Monitor

Display

Dell 34 Monitor

Input Source

Color

Audio

PersonalizePersonalize

Audio

PIP/PBP

USB Selection

Others

Brightness / Contrast

DDC/CI

O

Display Info

Reset Others

Factory Reset

LCD Conditioning

Service Tag

Self-Diagnostic

Firmware

Using the Quick Settings dialog box | 5

Using the Quick Settings dialog box

When you click the DDM icon in the notification tray, the Quick Settings window is

displayed.

If more than one supported Dell monitor is connected to the computer, a specific

target monitor can be selected from the Display drop-down list.

In the Quick Settings dialog box, you can also change the following:

* Resolution

* Auto Mode or Manual Mode

* Brightness and contrast levels

* Easy Arrange window layouts for the monitor

In the Quick Settings dialog box, you can also click Open Dell Display Manager

for more advanced settings.

6| Using the Quick Settings dialog box

NOTE:

Feature Function Description

Quick DDM Access Shortcut key to

open the DDM UI.

Ctrl+Shift+D

Control individual

monitor in a multi-

monitor setup

In the drop-down list with monitors, the

currently selected monitor has the Dell

logo next to it.

Move DDM UI to the monitor to be

controlled.

Press Ctrl+Shift+D to open the mini UI

under the mouse pointer.

Setting basic display options | 7

Setting basic display options

You can select Manual Mode to manually select a preset mode or select Auto

Mode to apply a preset mode based on the active application. An on-screen

message displays the current preset mode whenever it changes. The selected

monitor’s brightness and contrast levels can also be directly adjusted in the Basic

tab.

NOTE: When multiple Dell monitors are connected, select “Enable

display matrix control” to apply brightness, contrast, and color presets

to all monitors.

8| Setting basic display options

Assigning preset modes to applications | 9

Assigning preset modes to applications

The Auto Mode tab enables you to associate a Preset Mode with a specific

application, and apply it automatically. When Auto Mode is enabled, DDM will

automatically switch to the corresponding Preset Mode whenever the associated

application is activated. The Preset Mode assigned to a particular application may

be the same on each connected monitor, or it can vary from one monitor to the

other.

DDM is preconfigured for many popular applications. To add a new application to the

Application list, simply drag the application from the desktop, Windows Start menu

or elsewhere, and drop it onto the current list.

NOTE: Preset Mode assignments are not supported for batch les,

scripts, loaders, and non-executable les such as zip archives or packed

les.

You can also configure the Game preset mode to be used whenever a Direct3D

application runs in full-screen mode. To prevent an application from using mode,

assign a different preset mode to it.

10 | Organizing windows with Easy Arrange

Organizing windows with Easy Arrange

On supported Dell monitors, the Easy Arrange tab enables you to easily arrange

the open windows in one of the predefined layouts by dragging them into the zones.

Press “>” or use Page Up/Page Down key to find more layouts. To create a custom

layout, arrange the open windows and then click Save.

To get started with Easy Arrange, choose a target monitor and select one of

the predefined layouts. The regions for that layout are displayed momentarily on

the monitor. Next, drag an open window across the monitor. While the window is

being dragged, the current window layout is displayed and an active region gets

highlighted as the window passes over it. At any time, drop the window into the

active region to place the window in that region.

To create a custom window layout, set the size and position the windows on the

desktop and then click the Save link in Easy Arrange. The size and position of the

windows are saved as a custom layout, and the custom layout icon is created.

NOTE: This option does not save or remember the applications that are

open. Only the size and position of the windows are saved.
