Dell P4317Q Manuel utilisateur

Model No.: P4317Q

Regulatory model: P4317Qc

User’s Guide

Dell P4317Q

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better

use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury or death.

_________________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission

of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; Microsoft

and Windows are either trademarks or registered trademarks of Microsoft. Corporation in

the United States and/or other countries, Intel is a registered trademark of Intel Corporation

in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices, Inc.

ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an

ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR

guidelines for energy efficiency.

Other trademarks and trade names may be used in this document to refer to either the

entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary

interest in trademarks and trade names other than its own.

2016 - 03 Rev. A00

Contents | 3

Contents

About your monitor ................................................................ 5

Package contents.......................................................................................5

Product features.........................................................................................6

Monitor specifications............................................................................... 7

Universal Serial Bus (USB) Interface .....................................................16

Identifying parts and controls................................................................18

Plug and play capability ..........................................................................21

LCD monitor quality and pixel policy...................................................21

Maintenance guidelines.......................................................................... 21

Setting up the monitor .........................................................22

Attaching the stand..................................................................................22

Connecting your monitor ......................................................................23

Removing the monitor stand.................................................................27

Wall Mounting (Optional) .......................................................................27

4| Contents

Operating your monitor.......................................................28

Power on the monitor.............................................................................28

Using the front panel controls ..............................................................28

Using the on-screen display (OSD) menu ......................................... 30

Setting up your monitor..........................................................................45

Setting the maximum resolution ..........................................................45

Using tilt .................................................................................................... 46

Troubleshooting....................................................................47

Self-test ......................................................................................................47

Built-in diagnostics ................................................................................. 48

Common problems ................................................................................ 49

Product-specific problems .................................................................... 51

Universal Serial Bus (USB) specific problems .....................................52

Mobile high-definition link (MHL) specific problems .......................52

Appendix ....................................................................................................53

FCC notices (U.S. Only) and other regulatory information.............53

Contacting Dell.........................................................................................53

About your monitor | 5

About your monitor

Package contents

Your monitor ships with the components shown below. Ensure that you have

received all the components and Contacting Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor. Some

features or media may not be available in certain countries.

NOTE: To set up with any other stand, please refer to the respective stand setup

guide for setup instructions.

∞ Monitor

∞ Stand riser

∞ Stand base

∞ VESA cover

∞ Power cable (varies by

countries)

∞ HDMI cable

6| About your monitor

∞ mDP to DP cable

∞ DP to DP cable

∞ USB 3.0 upstream cable

(enables the USB ports on

the monitor)

DellTM UltraSharp U2715H Monitor

∞ Drivers and

Documentation Guide

∞ Quick Setup Guide

∞ Safety and Regulatory

Information

Product features

The Dell P4317Q flat panel display has an active matrix, Thin-Film Transistor (TFT),

Liquid Crystal Display (LCD), and LED backlight. The monitor features include:

∞ 107.98 cm (42.51 inch) viewable area display (measured diagonally). 3840 x 2160

resolution, plus full-screen support for lower resolutions.

∞ Plug and play capability if supported by your system.

∞ VGA and HDMI (MHL) and DP and mDP connectivity makes it simple and easy to

connect with legacy and new system.

∞ Build-in Speaker (8W x 2).

∞ On-Screen Display (OSD) adjustments for ease of set-up and screen

optimization.

∞ Software and documentation media includes an Information File (INF), Image

Color Matching File (ICM), and product documentation.

∞ Dell Display Manager Software included (in the CD shipped with the monitor).

∞ Support PIP and PBP Function.

About your monitor | 7

Monitor specifications

Model P4317Q

Screen type Active matrix - TFT LCD

Panel type In-plane Switching

Viewable image

Bezel width

Diagonal

Horizontal, Active Area

Vertical, Active Area

Area

566.40 mm (22.30 in)

107.98 cm (42.51 in)

941.18 mm (37.05 in)

529.42 mm (20.84 in)

1274.79 cm2(197.59 inch2)

Pixel pitch 0.2451 x 0.2451 mm

Viewing angle (vertical

/ horizontal)

178° / 178° (typical)

Brightness 350 cd/m² (typical)

Contrast ratio 1000 to 1 (typical)

Aspect Ratio 16:9

Display screen coating Anti-Glare with 2H hardness

Backlight Technology white LED edgelight system

Response time 8 ms

Color depth 1.06 Billion colors

PIP / PBP Yes

Connectivity 1 x DP 1.2

1 x mDP 1.2

2 x HDMI 1.4 (MHL)

1 x VGA

1 x USB 3.0 port - Upstream

4 x USB 3.0 port

1 x Audio Input

1 x Headphone Output

1 x RS232

Audio output 8W x 2

Built in device - usb Upstream x 1

Downstream x 4 (including one Charging Port)

8| About your monitor

DDM compatibility Yes

Adjustability

Tilt -5° to 10°

Security Security lock slot (cable lock sold separately)

* 72% (CIE 1931), 82%(CIE 1976)

Resolution specifications

Model P4317Q

Horizontal scan range 30 kHz to 83 kHz (automatic)

Vertical scan range 56 Hz to 76 Hz (automatic)

Maximum preset

resolution

3840 x 2160 at 60 Hz (DP only)

Preset display modes

Display Mode Horizontal

Frequency

(kHz)

Vertical

Frequency

(Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal /

Vertical)

VESA, 720 x 400 31.5 70.1 28.3 -/+

VESA, 640 x 480 31.5 60.0 25.2 -/-

VESA, 640 x 480 37.5 75.0 31.5 -/-

VESA, 800 x 600 37.9 60.3 40.0 +/+

VESA, 800 x 600 46.9 75.0 49.5 +/+

VESA, 1024 x 768 48.4 60.0 65.0 -/-

VESA, 1024 x 768 60.0 75.0 78.8 +/+

VESA, 1280 x 1024 64.0 60.0 108.0 +/+

VESA, 1280 x 1024 80.0 75.0 135.0 +/+

VESA, 1440 x 900 55.5 60.0 88.8 +/-

VESA, 1440 x 900 70.1 75.0 136.8 -/+

**VESA, 1920 x 1080 67.5 60.0 148.5 +/+

VESA, 3840 x 2160 67.5 30.0 297.0 +/+

*VESA, 3840 x 2160 135.0 60.0 594.0 +/+

* Requires a graphics card that supports DisplayPort 1.2

** PBP mode maximum resolution support 1920x1080@60Hz

About your monitor | 9

Electrical specifications

Model P4317Q

Video input signals ∞ Analog RGB, 0.7 Volts +/-5%, positive polarity at 75

ohm input impedance

∞ HDMI1.4, 600 mV for each differential line, positive

polarity at 100 ohm input impedance

Synchronization input

signals

Separate horizontal and vertical synchronizations,

polarity-free TTL level, SOG (Composite SYNC on

green)

AC input voltage/frequency/

current

100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/

2 A

Inrush current 120 V:30 A (Max.)

240 V:60 A (Max.)

Physical characteristics

Model P4317Q

Signal cable type ∞ Analog: detachable, D-Sub, 15 pins

∞ Digital: detachable, HDMI, 19 pins

∞ Digital: detachable, mDP, 20 pins

∞ Digital: detachable, DP, 20 pins

Dimensions (with stand)

Height 658.0 mm (25.90 in)

Width 973.1 mm (38.31 in)

Depth 250.0 mm (9.84 in)

Dimensions (without stand)

Height 566.4 mm (22.29 in)

Width 973.1 mm (38.31 in)

Depth 83.0 mm (3.27 in)

Stand dimensions

Height 488.6 mm (19.24 in)

Width 320.0 mm (12.60 in)

Depth 250.0 mm (9.84 in)

Weight

Weight with packaging 24.4 kg (53.78 lb)

Weight with stand

assembly and cables

17.93 kg (39.51 lb)

10 | About your monitor

Weight without stand

assembly

14.11 kg (31.09 lb)

Weight of stand

assembly

3.3 kg (7.26 lb)

Caution: Any third-party arm or pole purchased separately should support the weight

of the monitor as well as any external brackets and interface plates.

Environmental characteristics

Model P4317Q

Temperature

Operating 0°C to 40°C (32°F to 104°F)

Non-operating Storage ∞ -20°C to 60°C (-4°F to 140°F)

∞ -20°C to 60°C (-4°F to 140°F)

Shipping

Humidity

Operating 10% to 80% (non-condensing)

Non-operating ∞ Storage: 5% to 90% (non-condensing)

∞ Shipping: 5% to 90% (non-condensing)

Altitude

Operating (maximum) 5,000 m (16,400 ft)

Non-operating (maximum) 12,192 m (40,000 ft)

Thermal dissipation ∞ 494.9 BTU/hour (maximum)

∞ 238.9 BTU/hour (typical)

Power management modes

If you have VESA's DPM™ compliance display card or software installed in your PC,
