Dell™E2211H/E2311HmonitorUser'sGuide

Notes, Notices, and Cautions



Information in this document is subject to change without notice.

©2010DellInc.Allrightsreserved.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELLlogoaretrademarksofDellInc;Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in

the United States and/or other countries, Intel is a registered trademark of Intel Corporation in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices,

Inc. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product meets the

ENERGY STAR guidelines for energy efficiency.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model E2211Hb/E2311Hf.

August 2010 Rev. A00

About Your Monitor

Setting Up the Monitor

Operating the Monitor

Troubleshooting

Appendix

NOTE: A NOTE indicates important information that helps you make better use of your monitor.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury or death.

Downloaded from ManualMonitor.com Manuals

Back to Contents Page



About Your Monitor

Dell™E2211H/E2311HmonitorUser'sGuide

Package Contents

Your monitor ships with the components shown below. Ensure that you have received all the components and contact Dell if something is missing.

Package Contents

Product Features

Identifying Parts and Controls

Monitor Specifications

Plug and Play Capability

LCD Monitor Quality and Pixel Policy

Maintenance Guidelines

NOTE: Some items may be optional and may not ship with your monitor. Some features or media may not be available in certain countries.

NOTE: To set up with any other stand, please refer to the respective stand setup guide for setup instructions.



lMonitor

lStand

lPower Cable

lVGA Cable

Downloaded from ManualMonitor.com Manuals



Product Features

The Dell™E2211H/E2311H flat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD), and LED backlight. The monitor

features include:

■E2211H: 54.52cm(21.5inch)viewableareadisplay(Measureddiagonally).1920x1080resolution,plusfull-screen support for lower resolutions.

■E2311H: 58.42cm(23inch)viewableareadisplay(Measureddiagonally).1920x1080 resolution, plus full-screen support for lower resolutions.

■Wide viewing angle to allow viewing from a sitting or standing position, or moving side-to-side.

■Tilt adjustment capability.

■RemovablepedestalandVideoElectronicsStandardsAssociation(VESA™)100mmmountingholesforflexiblemountingsolutions.

■Plug and play capability if supported by your system.

■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

■Software and documentation media includes an information file (INF), Image color Matching File (ICM), PowerNap software application and product

documentation.

■Energy Saver feature for Energy Star compliance.

■Security lock slot.

■Asset Management Capability.

■Capability to switch from wide aspect to standard aspect ratio while maintaining the image quality.

■EPEAT Gold Rating.

■Halogen Reduced.

■Arsenic-free glass and Mercury-free panel.

■Energy Gauge shows the energy level being consumed by the monitor in real time.

■PowerNap Software included (comes in the CD shipped with the monitor).

Identifying Parts and Controls

Front View

lDVI Cable

lDrivers and Documentation media

lQuick Setup Guide

lProduct and Safety Information Guide

Downloaded from ManualMonitor.com Manuals

Back View



Front View

Front panel controls

Label

Description

Preset Modes (default, but configurable)

Brightness & Contrast (default, but configurable)

Exit

Power button (with power light indicator)

Back view

Back view with monitor stand

Label

Description

Use

VESA mounting holes (100 mm x 100 mm -

behind attached VESA Plate)

Wall mount monitor using VESA-compatible wall mount kit (100 mm x 100 mm)

Regulatory label

Lists the regulatory approvals.

Stand release button

Release stand from monitor.

Security lock slot

Secures monitor with security cable lock.

Dell Soundbar mounting brackets

Attaches the optional Dell Soundbar.

Barcode serial number label

Refer to this label if you need to contact Dell for technical support.

Cable management slot

Use to organize cables by placing them through the slot.

Downloaded from ManualMonitor.com Manuals

Side View

Bottom View



Right view

Bottom view

Bottom view with monitor stand

Label

Description

Use

AC power cord connector

Connect the power cable

DVI connector

Connect your computer DVI cable

VGA connector

Connect your computer VGA cable

Stand lock feature

To lock the Stand to the Monitor

Monitor Specifications

Flat Panel Specifications

Model

E2211H

E2311H

Screen type

Active matrix - TFT LCD

Panel type

Screen dimensions

21.5 inches (21.5-inch viewable image size)

23 inches (23-inch viewable image size)

Preset display area:

476.64 (H) X 268.14 (V) mm

509.76 (H) X 286.74 (V) mm

Horizontal

476.64 mm (18.77 inches)

509.76 mm (20.07 inches)

Downloaded from ManualMonitor.com Manuals

*[E2211H] color gamut (typical) is based on CIE1976 (81%) and CIE1931 (68%) test standards.

** [E2311H] color gamut (typical) is based on CIE1976 (81%) and CIE1931 (68%) test standards.

Vertical

268.14 mm (10.56 inches)

286.74 mm (11.29 inches)

Pixel pitch

0.248 mm

0.265 mm

Viewing angle

160°(vertical)typ,170°(horizontal)typ

Luminance output

250 cd/m ²(typ)

Contrast ratio

1000 to 1 (typ)

Faceplate coating

Antiglare with hard-coating 3H

Backlight

LED edgelight system

Response Time

5 ms typical

Color depth

16.7 million colors

Color gamut (Typical)

81%*

81%**

Resolution Specifications

Video Supported Modes



Model

E2211H

E2311H

Horizontal scan range

30 kHz to 83 kHz (automatic)

Vertical scan range

56Hzto75Hz(automatic)

Maximum resolution

1920 x 1080 at 60 Hz

Model

E2211H

E2311H

Video display capabilities (DVI playback)

480p, 480i, 576p, 576i, 720p, 1080p and 1080i

Downloaded from ManualMonitor.com Manuals

Preset Display Modes



Display Mode

Horizontal Frequency

(kHz)

Vertical Frequency

(Hz)

Pixel Clock

(MHz)

Sync Polarity

(Horizontal/Vertical)

720 x 400

31.5

70.0

28.3

-/+

640 x 480

31.5

60.0

25.2

-/-

640 x 480

37.5

75.0

31.5

-/-

800 x 600

37.9

60.0

40.0

+/+

800 x 600

46.9

75.0

49.5

+/+

1024 x 768

48.4

60.0

65.0

-/-

1024 x 768

60.0

75.0

78.8

+/+

1152 x 864

67.5

75.0

108.0

+/+

1280 x 1024

64.0

60.0

108.0

+/+

1280 x 1024

80.0

75.0

135.0

+/+

1920 x 1080

67.5

60.0

148.5

+/+

Electrical Specifications



Model

E2211H/E2311H

Video input signals

Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance

Digital DVI-

D TMDS, 600mV for each differential line, positive polarity at 50 ohm input

impedance

Synchronization input signals

Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG

(Composite SYNC on green)

AC input voltage/frequency/current

100 to 240 VAC/50 or 60 Hz +3 Hz/1.5 A (Max.)

Inrush current

120V:30A (Max.)

240V:60A (Max.)

Downloaded from ManualMonitor.com Manuals

Physical Characteristics



Model

E2211H

E2311H

Connector type

15-pin D-subminiature, blue connector; DVI-

D, white connector

15-pin D-subminiature, blue connector; DVI-D,

white connector

Signal cable type

Digital: Detachable, DVI-D, Solid pins,

shipped detached from the monitor

Analog: Detachable, D-Sub, 15 pins,

shipped attached to the monitor

Digital: Detachable, DVI-D, Solid pins, shipped

detached from the monitor

Analog: Detachable, D-Sub, 15 pins, shipped

attached to the monitor

Dimensions (with stand)

Height

380.4 mm (14.98 inches)

402.59 mm (15.85 inches)

Width

514.8 mm (20.27 inches)

547.97 mm (21.57 inches)

Depth

158.9 mm (6.25 inches)

163.86 mm (6.45 inches)

Dimensions (without stand)

Height

306.3 mm (12.06 inches)

325.07 mm (12.80 inches)

Width

514.8 mm (20.27 inches)

547.97 mm (21.57 inches)

Depth

61.5 mm (2.42 inches)

Stand dimensions

Height

296.8 mm (11.68 inches)

310.39 mm (12.22 inches)

Width

258.9 mm (10.09 inches)

265.86 mm (10.47 inches)

Depth

158.9 mm (6.25 inches)

163.86 mm (6.45 inches)

Weight

Weight with packaging

5.30 kg (11.68 lb)

5.81 kg (12.81 lb)

Weight with stand assembly and cables

4.24 kg (9.34 lb)

4.70 kg (10.36 lb)

Weight without stand assembly

(For wall mount or VESA mount considerations -no

cables)

2.98 kg (6.56 lb)

3.36 kg (7.41 lb)

Weight of stand assembly

0.97 kg (2.14 lb)

1.05 kg (2.31 lb)

Downloaded from ManualMonitor.com Manuals

Environmental Characteristics



Model

E2211H

E2311H

Temperature

Operating

0°Cto40°C

Non-operating

Storage: -20°Cto60°C(-4°Fto140°F)

Shipping: -20°Cto60°C(-4°Fto140°F)

Storage: -20°Cto60°C(-4°Fto140°F)

Shipping: -20°Cto60°C(-4°Fto140°F)

Humidity

Operating

10% to 80% (non-condensing)

Non-operating

Storage: 5% to 90% (non-condensing)

Shipping: 5% to 90% (non-condensing)

Storage: 5% to 90% (non-condensing)

Shipping: 5% to 90% (non-condensing)

Altitude

Operating

4,850 m (15,902 ft) max

Non-operating

12,192 m (40,000 ft) max

Thermal dissipation

95.54 BTU/hour (maximum)

68.24 BTU/hour (typical)

102.36 BTU/hour (maximum)

81.89 BTU/hour (typical)

Power Management Modes

Downloaded from ManualMonitor.com Manuals

IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotinuse.Thisis

referred to as Power Save Mode

*. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes functioning. The

following table shows the power consumption and signaling of this automatic power saving feature:

E2211H

VESA Modes

Horizontal Sync

Vertical Sync

Video

Power Indicator

Power Consumption

Normal operation

Active

Blue

20 W (typical)/28 W (maximum)

Active-off mode

Inactive

Blanked

Amber

Less than 1.0 W

Switch off

Off

Less than 0.5 W

Downloaded from ManualMonitor.com Manuals

Autres manuels pour E2211H

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dell Moniteur

Dell

Dell E170S - 17" LCD Monitor Manuel utilisateur

Dell

Dell UltraSharp 1706FPV Instructions d'utilisation

Dell

Dell P1424H Instructions d'utilisation

Dell

Dell E178WFP - 17" LCD Monitor Manuel utilisateur

Dell

Dell SE198WFP - 19" LCD Monitor Manuel utilisateur

Dell

Dell S3219D Manuel utilisateur

Dell

Dell P2722HB Instructions d'utilisation

Dell

Dell E2720HB Instructions d'utilisation

Dell

Dell UltraSharp U2417HA Manuel utilisateur

Dell

Dell 1708FP - UltraSharp - 17" LCD Monitor Manuel utilisateur

Dell

Dell E1913 Instructions originales

Dell

Dell U4021QW Manuel utilisateur

Dell

Dell D1025TM - UltraScan 1000HS - 17" CRT Display Manuel utilisateur

Dell

Dell UltraSharp U2412MWh Manuel utilisateur

Dell

Dell E2723H Manuel utilisateur

Dell

Dell UltraSharp U2419H Manuel utilisateur

Dell

Dell UltraSharp U2713H Manuel utilisateur

Dell

Dell U2410 - UltraSharp - 24" LCD Monitor Manuel utilisateur

Dell

Dell P3418HW Manuel utilisateur

Dell

Dell 2405FPW - UltraSharp - 24" LCD Monitor Manuel utilisateur

Dell

Dell 3007WFP-HC - UltraSharp - 30" LCD Monitor Manuel utilisateur

Dell

Dell S3222DGM Manuel utilisateur

Dell

Dell S2721QSB Manuel utilisateur

Dell

Dell P2419H Instructions d'installation

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Philips

Philips 107C64 Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation

LG M1950D-PZ Manuel utilisateur

Sceptre

Sceptre D40 Manuel utilisateur

Hunt Electronic

Hunt Electronic HCD-15AH Manuel utilisateur
