Dell XPS 13 Manuel utilisateur
Views
Specifications
© 2013 Dell Inc.
Trademarks used in this text: Dell™, the DELL logo, and XPS™are trademarks of Dell Inc.
Intel®is a registered trademark and Core™is a trademark of Intel Corporation in the U.S. and other countries.
Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under license.
2013 ‑ 10 Rev. A00
Regulatory model: P29G | Type: P29G003
Computer model: XPS 9333
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
13
Power-adapter port
Connect a power adapter to provide power to your computer
and charge the battery.
Headset port
Connect a headphone, a microphone, or a headphone and
microphone combo (headset).
USB 3.0 port with PowerShare
Connect peripherals such as storage devices, printers, and soon.
Provides data transfer speeds up to 5 Gbps.
PowerShare allows you to charge your USB devices even when
your computer is turned off.
NOTE: If your computer is powered off or in Hibernate state,
you must connect the power adapter to charge your devices
using the PowerShare port. You must enable this feature in
system setup.
NOTE: Certain USB devices may not charge when the
computer is powered off or in Sleep state. In such cases, turn on
the computer to charge the device.
Left
Power-adapter port
USB 3.0 port with PowerShare
Headset port
Views
Specifications
Left
Right
Base
Display
Mini DisplayPort
Connect an external display or a projector.
Battery-charge status lights (5)
Turn on when the battery‑charge status button is pressed. Each
light indicates approximately 20% charge.
Battery-status button
Press to check the charge remaining in the battery.
USB 3.0 port with PowerShare
Connect peripherals such as storage devices, printers, and soon.
Provides data transfer speeds up to 5 Gbps.
PowerShare allows you to charge your USB devices even when
your computer is turned off.
NOTE: If your computer is powered off or in Hibernate state,
you must connect the power adapter to charge your devices
using the PowerShare port. You must enable this feature in
system setup.
NOTE: Certain USB devices may not charge when the
computer is powered off or in Sleep state. In such cases, turn on
the computer to charge the device.
Right
Mini DisplayPort
Battery-charge status lights (5)
Battery-status button
USB 3.0 port with PowerShare
Views
Specifications
Left
Right
Base
Display
Power button
Press to turn on the computer if it is turned off or in Sleep state.
Press to put the computer in Sleep state if it is turned on.
Press and hold for 10 seconds to force shut‑down the
computer.
NOTE: You can customize the power‑button behavior in
Power Options. For more information, see Me and My Dell at
dell.com/support.
Left-click area
Press to left‑click.
Right-click area
Press to right‑click.
Touchpad
Move your finger on the touchpad to move the mouse pointer.
Tap to left‑click.
Base
Power button
Touchpad
Right-click area
Left-click area
Views
Specifications
Left
Right
Base
Display
Camera
Allows you to video chat, capture photos, and record videos.
Ambient-light sensor
Detects the ambient light and automatically adjusts the keyboard
backlight and display brightness.
Power-status light
Indicates the power‑state of the computer.
Camera-status indicator
Turns on when the camera is in use.
Digital microphones (2)
Provide high‑quality digital sound input for audio recording,
voice calls, and so on.
Display
Camera-status indicator
Camera
Ambient-light sensor Digital microphones (2)
Power-status light
Views
Specifications
Left
Right
Base
Display
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display Keyboard
Dimensions and Weight
Height:
Front 0.24 inches (6 mm)
Back 0.71 inches (18 mm)
Width 12.44 inches (316 mm)
Depth 8.07 inches (205 mm)
Weight (minimum) 2.94 lb (1.33 kg)
NOTE: The weight of your laptop varies depending on the configuration ordered
and the manufacturing variability.
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display Keyboard
System Information
Computer model XPS 9333
Processor • Intel Core i3 (4th generation)
• Intel Core i5 (4th generation)
• Intel Core i7 (4th generation)
Chipset Integrated Premium PCH
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display Keyboard
Memory
Type Dual‑channel DDR3L
Speed Up to 1600 MHz
Configurations supported 4 GB and 8 GB
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display Keyboard
Ports and Connectors
External:
USB Two USB 3.0 ports with PowerShare
Mini DisplayPort One mini DisplayPort
Audio One headset (microphone and headphone combo) port
Internal:
NGFF One Next Generation Form Factor (NGFF) slot for WLAN and Bluetooth combo
card
Mini card One full mini card slot for mSATA
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display Keyboard
Communications
Wireless • Wi‑Fi 802.11 ac, Wi‑Fi 802.11 n
• Bluetooth 4.0
• Intel Wireless Display (WiDi)
