Dell P1424H Manuel utilisateur

Dell P1424H

User’s Guide

Monitor Model: P1424H

Regulatory Model: P1424Hf

Notes, Cautions and Warnings

NOTE: A NOTE indicates important information that helps you make better

use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of

data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

2023 - 05

Rev. A00

Contents │ 3

Contents

Safety instructions............................................5

About your monitor ...........................................6

Package contents ..................................................... 6

Product features....................................................... 7

Identifying features and controls................................ 8

Back view and label information ............................................. 9

Monitor specifications...............................................10

Resolution specifications.......................................................11

Preset display modes ............................................................11

Electrical specifications........................................................ 12

Physical characteristics........................................................ 13

Environmental characteristics ............................................... 14

Pin assignments .................................................................. 15

Plug and play capability .............................................16

LCD monitor quality and pixel policy ...........................16

Maintenance guidelines .............................................16

Cleaning your monitor .......................................................... 16

Setting up the monitor ..................................... 18

Sleeve......................................................................18

Tilt adjustment .........................................................18

Connecting your monitor ...........................................19

Connecting with Docking device ............................... 22

4 │ Contents

Operating the monitor ......................................23

Turning on the monitor ............................................. 23

Using the front panel control .................................... 23

Using the On-Screen Display (OSD) menu.................. 25

Accessing the OSD menu...................................................... 26

OSD warning messages ........................................................ 27

Setting up display resolution on your monitor ............. 28

Troubleshooting ...............................................29

Self-test ................................................................. 29

Built-in diagnostics ...................................................31

Common problems ................................................... 32

Regulatory information .....................................34

FCC notices (U.S. only) and other regulatory

information ............................................................. 34

EU product database for energy label and product

information sheet .................................................... 34

Contacting Dell ................................................35

Safety instructions │5

Safety instructions

Use the following safety guidelines to protect your monitor from potential damage and to

ensure your personal safety. Unless otherwise noted, each procedure included in this document

assumes that you have read the safety information that shipped with your monitor.

NOTE: Before using the monitor, read the safety information that is shipped

with your monitor and printed on the product. Keep the documentation at a

secure location for further reference.

WARNING: Use of controls, adjustments, or procedures other than those

specified in this documentation may result in exposure to shock, electric

hazards, and/or mechanical hazards.

WARNING: The possible long-term effect of listening to audio at high volume

through the headphones (on monitor that support it) may cause damage to

your hearing ability.

• Place the monitor on a solid surface and handle it carefully. The screen is fragile and can be

damaged if dropped or hit with a sharp object.

• Keep the monitor in room temperature. Excessive cold or hot conditions can have an

adverse effect on the liquid crystals of the display.

• Connect the power cable from the monitor to a wall outlet that is near and accessible. See

Connecting your monitor.

• Do not place and use the monitor on a wet surface or near water.

• Do not subject the monitor to severe vibration or high impact conditions. For example, do

not place the monitor inside a car trunk.

• Unplug the monitor when it is going to be left unused for an extended period.

• To avoid electric shock, do not attempt to remove any cover or touch the inside of the

monitor.

• Read these instructions carefully. Keep this document for future reference. Follow all

warnings and instructions marked on the product.

For information on safety instructions, see the Safety, Environmental, and Regulatory

Information (SERI) document that is shipped with your monitor

6│About your monitor

About your monitor

Package contents

Your monitor ships with the components indicated in the table. Ensure that you have

received all the components and see Contacting Dell if anything is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Some features may not be available in certain countries.

Component image Component description

Display

USB Type-C cable

(C to C, 1.0 m)

Sleeve

• Quick Start Guide

• Safety, Environmental, and

Regulatory Information

About your monitor │7

Product features

The Dell P1424H monitor has an active matrix, Thin-Film Transistor (TFT), Liquid Crystal

Display (LCD), anti-static, and LED backlight.

The monitor features include:

• 35.56 cm (14.0 in.) diagonal viewable area display (measured diagonally),

1920 x 1080 resolution, with full-screen support for lower resolutions

• Viewing angles of 178 degrees in horizontal and vertical directions

• Dynamic contrast ratio (700:1)

• Digital connectivity with USB Type-C

• Dual USB Type-C port supports DP Alternate Mode, power pass through and power

delivery 65 W

• Tilt adjustment capability

• Plug and play capable if supported by your computer

• On-Screen Display (OSD) adjustments for easy setup and screen optimization

• ≤0.3 W in Standby Mode

• Optimize eye comfort with ComfortView

• Arsenic-free glass and mercury-free panel

• BFR/PVC free monitor (excluding external cables)

• RoHS Compliant

• EPEAT registered where applicable. EPEAT registration varies by country

See https://www.epeat.net for registration status by country

• Energy Star®Certified

• Compatible with Dell Display Manager 2.1 and above

WARNING: The possible long-term effects of blue light emission from the

monitor may cause damage to the eyes, which includes but is not limited

to eye fatigue and digital eye strain. ComfortView Plus feature is designed

to reduce the amount of blue light emitted from the monitor to optimize

eye comfort.

8│About your monitor

Identifying features and controls

1234

Label Description Use

1Power On/Off button

(with LED indicator)

To turn the monitor On or Off.

Solid white light indicates the monitor is turned

on and functioning normally. Blinking white light

indicates the monitor is in Standby Mode.

2USB Type-C

(support Alt mode DP

1.2 and PD function)

Connect to your computer/phone using the

USB Type-C cable (C to C).

Note: USB data not supported.

4Function buttons

To access the OSD menu and change the

settings if required. For more information, see

Using the front panel control.

About your monitor │9

Back view and label information

Label Description Use

Barcode, serial number,

service tag, and

regulatory information

Refer to this label if you need to contact Dell

for technical support.

List of regulatory approvals.

10 │About your monitor

Monitor specifications

Model P1424H

Screen type Active matrix-TFT LCD

Panel type In-Plane Switching

Viewable area

Diagonal 355.60 mm (14.00 in.)

Active area:

Horizontal

Vertical

Area

309.31 mm (12.18 in.)

173.99 mm (6.85 in.)

53816.85 mm2(83.42 in.2)

Pixel pitch 0.1611 mm

Pixel per inch (PPI) 158

Viewing angle:

Horizontal

Vertical

178° (typical)

Brightness 300 cd/m2(typical)

Contrast ratio 700 to 1 (typical)

Faceplate coating Hard coating (H), Anti-Glare

Backlight LED light bar system

Response time (Gray to Gray) 6 ms (typical)

Color depth 16.7 million colors

Color gamut 72% NTSC (CIE1931)

Dell display manager

compatibility

Yes

Connectivity 2 x USB Type-C (Alt Mode DP1.2, HBR, HDCP 1.4,

Power Delivery PD up to 65 W)

Bezel width (edge of monitor

to active area)

- Top: 6.54 mm

- Left/Right: 6.53 mm

- Bottom: 22.16 mm

Tilt angle 10° to 90°
