Dell Latitude E6440

Setup and Features Information

About Warnings

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Front View and Back View

Figure 1. Front View

1. microphone

2. display release latch

3. camera

4. camera status light

5. microphone

6. display latch

7. display

8. hard-drive activity light

9. battery status light

10. wireless status light

11. power button

12. security lock

13. USB 3.0 connectors (2)

14. headset port

15. optical drive

16. optical-drive release latch

17. optical-drive eject button

18. wireless switch

19. express-card reader (optional)

20. fingerprint reader

Regulatory Model: P38G

Regulatory Type: P38G001

2013 - 06

21. SD card reader

22. contactless smart-card reader

23. touchpad

24. touchpad buttons (2)

25. trackstick buttons (3)

26. trackstick

27. keyboard

28. mute button

29. volume-down button

30. volume-up button

Figure 2. Back View

1. power status light

2. hard-drive activity light

3. battery status light

4. USB 3.0 connector with PowerShare

5. network connector

6. HDMI connector

7. power connector

8. VGA connector

9. USB 3.0 connector

10. cooling vents

11. smart card slot

Base View

Figure 3. Base View

1. battery release latch (left)

2. battery bay

3. docking station connector

4. SIM card slot

5. battery release latch (right)

WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell

computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can

damage the computer or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is

normal and does not indicate a problem with the fan or the computer.

Quick Setup

WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with

your computer. For additional best practices information, see www.dell.com/regulatory_compliance

WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips

vary among countries. Using an incompatible cable or improperly connecting the cable to the power strip or

electrical outlet may cause fire or equipment damage.

CAUTION: When you disconnect the AC adapter cable from the computer, grasp the connector, not the cable itself,

and pull firmly but gently to avoid damaging the cable. When you wrap the AC adapter cable, ensure that you

follow the angle of the connector on the AC adapter to avoid damaging the cable.

NOTE: Some devices may not be included if you did not order them.

1. Connect the AC adapter to the AC adapter connector on the computer and to the electrical outlet.

Figure 4. AC Adapter

2. Connect the network cable (optional).

Figure 5. Network Connector

3. Connect USB devices, such as a mouse or keyboard (optional).

Figure 6. USB Connector

4. Open the computer display and press the power button to turn on the computer.

Figure 7. Power Button

NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards

or connect the computer to a docking device or other external device, such as a printer.

Specifications

NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your

computer. For comprehensive specification of your computer go to Specifications’ section in your Owner’s Manual

available on the support site at dell.com/support. For more information about the configuration of your computer,

go to Help and Support in your Windows operating system and select the option to view information about your

computer.

Power

AC Adapter 65 W and 90 W

Input Voltage 100 VAC to 240 VAC

Coin-cell battery 3 V CR2032 lithium coin-cell

Physical

Height • Front – 28.60 mm (1.12 inches)

Physical

• Back – 30.80 mm (1.21 inches)

Width 338.00 mm (13.30 inches)

Depth 232.60 mm (9.16 inches)

Weight (with 6–cell battery and optical drive) 2.12 kg (4.68 lb)

Environmental

Operating Temperature 0 °C to 35 °C (32 °F to 95 °F)

Information para NOM (únicamente para México)

The following information is provided on the device described in this document in compliance with the requirements of

the official Mexican standards (NOM).

Voltaje de alimentación 100 VAC – 240 VAC

Frecuencia 50 Hz – 60 Hz

Consumo eléctrico 1,5 A

Voltaje de salida 19,50 V de CC

Intensidad de salida 3,34 A /4,62 A

Finding More Information and Resources

See the safety and regulatory documents that shipped with your computer and the regulatory compliance website at

www.dell.com/regulatory_compliance for more information on:

• Safety best practices

• Regulatory certification

• Ergonomics

See www.dell.com for additional information on:

• Warranty

• Terms and Conditions (U.S. only)

• End User License Agreement

Additional information on your product is available at www.dell.com/support/manuals

Trademarks used in this text: Dell™, the DELL logo, Dell Precision™, Precision ON™,ExpressCharge™, Latitude™, Latitude ON™,

OptiPlex™, Vostro™, and Wi-Fi Catcher™are trademarks of Dell Inc. Intel®, Pentium®, Xeon®, Core™, Atom™, Centrino®, and Celeron®

are registered trademarks or trademarks of Intel Corporation in the U.S. and other countries. AMD®is a registered trademark and

AMD Opteron™, AMD Phenom™, AMD Sempron™, AMD Athlon™, ATI Radeon™, and ATI FirePro™are trademarks of Advanced Micro

Devices, Inc. Microsoft®, Windows®, MS-DOS®, Windows Vista®, the Windows Vista start button, and Office Outlook®are either

trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Blu-ray Disc™is a trademark

owned by the Blu-ray Disc Association (BDA) and licensed for use on discs and players. The Bluetooth®word mark is a registered

trademark and owned by the Bluetooth®SIG, Inc. and any use of such mark by Dell Inc. is under license. Wi-Fi®is a registered

trademark of Wireless Ethernet Compatibility Alliance, Inc.

2013 - 06

Rev. A00
