Dell Latitude XT3 Media Base

Regulatory Mode: K01S

Regulatory Type: K01S001

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your

computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury,

or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarks used in this text: Dell™, the DELL logo, and Latitude™ are trademarks of Dell Inc.

Microsoft®, Windows®, and Windows Vista® are registered trademarks of Microsoft Corporation in the

U.S. and other countries.

Other trademarks and trade names may be used in this publication to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade

names other than its own.

2011 - 05 P/N MK8V0 Rev. A00

Media Base 3

Media Base

Top and Right View

Back and Left View

1 docking connector 2 USB connector

3 optical drive 4 optical drive eject button

1 USB connector 2 Tablet-PC release lever

4Media Base

Before Docking or Undocking Your Tablet-PC

from the Media Base

WARNING: If you are using a multiple-outlet power strip, use caution when you

plug the AC adapter power cable into the power strip. Some power strips may

allow you to insert the connector incorrectly. Incorrect insertion of the power

connector could result in permanent damage to your media base as well as

electric shock and/or fire. Ensure that you insert the ground prong of the power

plug into the mating ground contact of the power strip.

CAUTION: Use the Latitude™ XT3 media base with your Latitude XT3 only. If you

use a media base from earlier models of Dell computers you may damage the

media base or the Tablet-PC.

CAUTION: If the Tablet-PC does not have a charged battery in the battery bay, you

must shut down the Tablet-PC through the Windows pí~êí menu and then undock

the Tablet-PC. If you undock the Tablet-PC without a battery before shutting it

down, you will lose data and the Tablet-PC may not recover normal operation for

several minutes.

Before Docking or Undocking Your Tablet-PC

NOTE: If you re-install the operating system, complete the setup before docking the

Tablet-PC to the media base.

• Save and close any open files, and exit any open programs.

• Set your Tablet-PC power management settings to ensure that the

Tablet-PC does not enter sleep, standby, or hibernate mode when you

close (lower) the display:

Click the Windows

Power

icon

in the Notification area to display

the

Power

icon pop-up window.

Click

More power options

Under the

When I close the lid

drop-down menu, select

Do nothing.

Media Base 5

Docking Your Tablet-PC to the Media Base

CAUTION: If you are docking your Tablet-PC for the first time, complete the steps

in "Before Docking or Undocking Your Tablet-PC from the Media Base" on page 4,

before your proceed.

Follow the procedures in "Before Docking or Undocking Your Tablet-PC

from the Media Base" on page 4.

If this is the first time it is being docked to the media base, ensure that

your Tablet-PC is turned off .

Align the back of the Tablet-PC with the back of the media base, and lower

the Tablet-PC onto the media base.

Press the Tablet-PC onto the media base until it clicks and the Tablet-PC

is firmly seated.

Turn on the Tablet-PC.

The operating system recognizes the media base.

1 Tablet-PC 2 media base

6Media Base

Undocking Your Tablet-PC From the Media Base

CAUTION: Never undock the Tablet-PC without first preparing the Tablet-PC for

undocking. If you undock before preparing the Tablet-PC, you will lose data and

the Tablet-PC may not recover normal operation for several minutes, if at all.

CAUTION: If the Tablet-PC does not have a charged battery in the battery bay, you

must shut down the Tablet-PC through the Windows pí~êí menu and then undock

the Tablet-PC. If you undock the Tablet-PC without a battery before shutting it

down, you will lose data and the Tablet-PC may not recover normal operation for

several minutes.

Follow the procedures in "Before Docking or Undocking Your Tablet-PC

from the Media Base" on page 4.

Pull the Tablet-PC release lever forward to release the Tablet-PC from the

media base.

Lift the Tablet-PC up and slide it out towards the back of the media base.

Removing and Installing the Optical Drive From

the Media Base

Prior to removing or installing the optical drive from the media base, always

perform the following:

Save and close any open files or programs, and turn off the Tablet-PC.

Undock the media base (see "Undocking Your Tablet-PC From the Media

Base" on page 6).

Media Base 7

Removing the Optical Drive

To remove the optical drive:

Remove the screw that secures the optical drive to the media base.

Use your screwdriver to slide the drive out of the media bay.

Installing the Optical Drive

To install the optical drive:

Insert the optical drive into the media bay on the media base.

Replace the securing screw that holds the optical drive in place.

Media Base Specifications

Physical

Height:

Without feet

14.75 mm (0.58 inch)

With feet

16.25 mm (0.64 inch)

Width 292.40 mm (11.51 inches)

Depth 191.50 mm (7.54 inches)

Weight 530 g (1.7 lbs)

Ports and Connectors

USB two 4-pin USB-2.0 compliant connector

Docking 144-pin connector

8Media Base

Finding More Information and Resources

See the safety and regulatory publications that shipped with your computer and the regulatory

compliance website at www.dell.com/regulatory_compliance for more information on:

• Safety best practices

• Warranty

• Terms and Conditions

• Regulatory certification

• Ergonomics
