Dell Inspiron 14 Manuel utilisateur

Trademarks used in this text: Dell™, the DELL logo, and Inspiron™are trademarks of Dell Inc.

Intel®, Pentium®, and Celeron®are registered trademarks and Core™is a trademark of Intel Corporation in the

U.S. and other countries. Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell

under license. Blu-ray Disc™is a trademark owned by the Blu-ray Disc Association (BDA) and licensed for use

on discs and players.

2013 - 10 Rev. A00

Regulatory model: P37G | Type: P37G001/P37G003

Computer model: Inspiron 3421/5421/3437/5437

Specifications

14/14R

Dimensions

Height (front and back):

Inspiron 3421 17.78 mm to 25.35 mm (0.70 inch to 1.00 inch)

Inspiron 5421 17.48 mm to 25.00 mm (0.69 inch to 0.98 inch)

Inspiron 3437 25.35 mm (1.00 inch)

Inspiron 5437 25.00 mm (0.98 inch)

Width 346.00 mm (13.62 inches)

Depth 245.00 mm (9.65 inches)

Weight (with 4-cell battery):

Inspiron 3421/3437 1.98 kg (4.37 lb)

Inspiron 5421/5437 1.95 kg (4.30 lb)

NOTE: The weight of your laptop varies

depending on the configuration ordered and

the manufacturing variability.

System Information

Computer Model Inspiron 3437/5437/3421/5421

3437/5437 3421/5421

Processor • Intel Celeron Dual Core

(4th generation)

• Intel Pentium Dual Core

(4th generation)

• Intel Core i3 ULV

(4th generation)

• Intel Core i5 ULV

(4th generation)

• Intel Core i7 ULV

(4th generation)

• Intel Celeron Dual Core

(3rd generation)

• Intel Pentium Dual Core

(3rd generation)

• Intel Core i3 ULV

(3rd generation)

• Intel Core i5 ULV

(3rd generation)

• Intel Core i7 ULV

(3rd generation)

L1 cache 64 KB

L2 cache 256 KB

L3 cache Up to 4 MB

System chipset Integrated in processor Intel HM76 chipset

Memory

Connectors Two internally-accessible SODIMM sockets

Memory

Type:

Inspiron 3421/5421 Dual-channel DDR3

Inspiron 3437/5437 Dual-channel DDR3L

Speed Up to 1600 MHz

Configurations supported 2 GB, 4 GB, 6 GB, and 8 GB

Ports and Connectors

Audio One headphone/microphone combo (headset)

port

HDMI One HDMI port

Network adapter One RJ45 port

USB • One USB 2.0 port

(supports Windows debugging)

• Two USB 3.0 ports

Mini-card (internal) One half-size mini-card slot for

Wi-Fi+BT combo

Communications

Network adapter 10/100 Ethernet LAN on system board

Wireless • Wi-Fi b/g/n

• Wi-Di (optional)

• Bluetooth 4.0

Video

Inspiron 3421/5421 Inspiron 3437/5437

Controller:

Integrated • Intel HD graphics 3000

• Intel HD graphics 4000

Intel HD graphics

4200/4400/5100 series

Discrete • NVIDIA GeForce GT625M

• NVIDIA GeForce GT640M

• NVIDIA GeForce GT720M

• NVIDIA GeForce GT740M

• NVIDIA GeForce GT750M

Memory:

Integrated System shared memory

Discrete Up to 2 GB

Audio

Controller Realtek ALC3223

Speaker 2 x 2 W

Internal microphone support Single digital microphone in camera assembly

Volume controls Program menus and keyboard media

functionkeys

Storage

Type SATA

Interface • SATA 1.0 (1.5 Gb/s)

• SATA 2.0 (3 Gb/s)

• SATA 3.0 (6 Gb/s)

Hard drives One 2.5-inch SATA drive

Optical drives One 9.5 mm SATA drive

Drives supported • DVD+/-RW

• Blu-ray RW

Media-card reader

Type One 8-in-1 slot

Cards supported • SD card

• SD Hi-Capacity (SDHC) card

• SD Extended Capacity (SDXC) card with

Ultra High Speed (UHS)

• Memory Stick

• Memory Stick PRO

• Memory Stick XC (MSXC)

• MultiMedia Card (MMC)

• MultiMedia Card plus (MMC+)

Display

Type • 14.0-inch HD WLED with TrueLife

(1366 x 768)

• 14.0-inch HD WLED with TrueLife

(1366 x 768) - Touchscreen

• 14.0-inch anti-glare HD+ WLED with TrueLife

(1600 x 900)

Dimensions:

Height 173.95 mm (6.85 inches)

Width 309.40 mm (12.18 inches)

Diagonal 355.60 mm (14.00 inches)

Refresh rate 60 Hz

Operating angle 0 degree (closed) to 135 degrees

Horizontal viewing angle 40 degrees/40 degrees

Vertical viewing angle (H/L) 10 degrees/30 degrees

Pixel pitch 0.2265 mm

Keyboard

Type Chiclet keyboard

Camera

Resolution:

Still Image 0.92 megapixels

Video (maximum) 1280 x 720 pixels (HD)

Diagonal viewing angle 60 degrees

Touchpad

Resolution:

Horizontal 1261 dpi

Vertical 1810 dpi

Dimensions:

Height 56.00 mm (2.20 inches)

Width 100.00 mm (3.94 inches)

Battery

Type • 4-cell “smart” lithium ion (40 WHr)

• 6-cell “smart” lithium ion (65 WHr)

Dimensions: 4-cell 6-cell

Height 20.00 mm (0.79 inch) 35.40 mm (1.39 inches)

Width 272.40 mm (10.72 inches) 272.40 mm (10.72 inches)

Depth 46.30 mm (1.82 inches) 46.30 mm (1.82 inches)

Weight 0.26 kg (0.57 lb) 0.36 kg (0.79 lb)

Voltage 14.80 VDC 11.10 VDC

Operating time Battery operating time varies depending on operating

conditions and can significantly reduce under certain

power-intensive conditions

Life span

(approximate)

300 discharge/charge cycles

Temperature range:

Operating 0 °C to 35 °C (32 °F to 95 °F)

Storage –40 °C to 65 °C (–40 °F to 149 °F)

Coin-cell battery CR-2032

Power Adapter

Type • 65 W

• 90 W

Input voltage 100-240 VAC

Input current (maximum) 1.50 A/1.60 A/1.70 A

Input frequency 50 Hz-60 Hz

Output current (continuous) 3.34 A/4.62 A

Rated output voltage 19.50 +/- 1 VDC

Temperature range:

Operating 0 °C to 40 °C (32 °F to 104 °F)

Storage –40 °C to 70 °C (–40 °F to 158 °F)

Computer Environment

Temperature range:

Operating 0 °C to 35 °C (32 °F to 95 °F)

Storage –40 °C to 65 °C (–40 °F to 149 °F)

Relative humidity (maximum):

Operating 10 % to 90 % (non-condensing)

Storage 10 % to 95 % (non-condensing)

Maximum vibration (Measured using a random vibration spectrum that simulates

user environment):

Operating 0.66 GRMS

Storage 1.3 GRMS

Maximum shock (Measured with hard drive in operating status and a 2-ms half-

sine pulse for operating. Also measured with hard drive in head-parked position

and a 2-ms half-sine pulse for storage):

Operating 110 G

Storage 160 G

Altitude (maximum):

Operating –15.2 m to 3048 m (–50 ft to 10,000 ft)

Storage –15.2 m to 10,668 m (–50 ft to 35,000 ft)

Airborne contaminant level G1 as defined by ISA-S71.04-1985
