Dell™Inspiron™1300/B120/B130ServiceManual

Before You Begin

Hinge

System Components

Battery

Memory, Optical Drive, and Mini PCI Card

Hard Drive

Keyboard

Display Assembly

Palm Rest

Modem

Coin-Cell Battery

Microprocessor Thermal-Cooling Assembly

Microprocessor Module

Speakers

System Board

Antenna

Fan

Flashing the BIOS

Base Plastics

Pinout Assignments for I/O Connectors

Model PP21L

Notes, Notices, and Cautions

Information in this document is subject to change without notice.

©2005DellInc.Allrightsreserved.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and Inspiron are trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Back to Contents Page

Antenna

Dell™Inspiron™1300/B120/B130ServiceManual

Replacing the Antenna

Replacing the Antenna



1. Follow the instructions in Before Working Inside Your Computer.



2. Remove the hard drive. See Removing the Hard Drive.



3. Remove the optical drive. See Removing the Optical Drive.



4. Remove the memory module. See Removing the Memory Module.



5. Remove the Mini PCI card. See Removing the Mini PCI Card.



6. Remove the microprocessor thermal-cooling assembly. See Removing the Microprocessor Thermal-Cooling Assembly.



7. Remove the microprocessor. See Removing the Microprocessor Module.



8. Remove the hinge cover. See Removing the Hinge Cover.



9. Remove the keyboard. See Removing the Keyboard.



10. Remove the display assembly. See Removing the Display Assembly.



11. Remove the palm rest. See Removing the Palm Rest.



12. Remove the modem. See Removing the Modem.



13. Remove the speakers connector. See Removing the Speakers.



14. Remove the system board. See Removing the System Board.



15. Remove the antenna cable from the guides.



16. Replace the antenna cable, securing it under the guides.

CAUTION: Before performing the following procedures, read the safety instructions in the Product Information Guide.

CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of

your computer's electronic components. You can do so by touching an unpainted metal surface.

Back to Contents Page



antenna cable

guides



Back to Contents Page

Base Plastics

Dell™Inspiron™1300/B120/B130ServiceManual



1. Follow the instructions in Before Working Inside Your Computer.



2. Remove the hard drive. See Removing the Hard Drive.



3. Remove the optical drive. See Removing the Optical Drive.



4. Remove the memory module. See Removing the Memory Module.



5. Remove the Mini PCI card. See Removing the Mini PCI Card.



6. Remove the microprocessor thermal-cooling assembly. See Removing the Microprocessor Thermal-Cooling Assembly.



7. Remove the microprocessor. See Removing the Microprocessor Module.



8. Remove the hinge cover. See Removing the Hinge Cover.



9. Remove the keyboard. See Removing the Keyboard.



10. Remove the display assembly. See Removing the Display Assembly.



11. Remove the palm rest. See Removing the Palm Rest.



12. Remove the modem. See Removing the Modem.



13. Remove the speakers connector. See Removing the Speakers.



14. Remove the system board. See Removing the System Board.

Back to Contents Page



CAUTION: Before performing the following procedures, read the safety instructions in the Product Information Guide.

CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of

your computer's electronic components. You can do so by touching an unpainted metal surface.

Back to Contents Page

Battery

Dell™Inspiron™1300/B120/B130ServiceManual

Replacing the Battery

Replacing the Battery



To remove the battery:



1. If the computer is connected to a docking device (docked), undock it. See the documentation that came with your docking device for instructions.



2. Ensure that the computer is turned off.



3. Turn over the computer.



4. Slide the battery-bay latch release lock on the bottom of the computer away from the battery.



5. Slide and hold the battery-bay latch release, and then remove the battery from the bay.

To replace the battery, follow the removal procedure in reverse order.

Back to Contents Page



CAUTION: Before performing these procedures, disconnect the modem from the telephone wall jack.

CAUTION: Using an incompatible battery may increase the risk of fire or explosion. Replace the battery only with a compatible battery purchased

fromDell.ThebatteryisdesignedtoworkwithyourDell™computer.Donotuseabatteryfromothercomputerswithyourcomputer.

battery

battery-bay latch release

battery-bay latch release lock

Back to Contents Page

Before You Begin

Dell™Inspiron™1300/B120/B130ServiceManual

Recommended Tools

Turning Off Your Computer

Before Working Inside Your Computer

Computer Orientation

Screw Identification

This chapter provides procedures for removing and installing the components in your computer. Unless otherwise noted, each procedure assumes that the

following conditions exist:

lYou have performed the steps in Turning Off Your Computer and Before Working Inside Your Computer.

lYou have read the safety information in the Product Information Guide.

lA component can be replaced by performing the removal procedure in reverse order.

Recommended Tools

The procedures in this document may require the following tools:

lSmall flat-blade screwdriver

lPhillips screwdriver

lSmall plastic scribe

lHex nut driver

lFlash BIOS-update program floppy disk or CD

Turning Off Your Computer



1. Shut down the operating system:

a. Save and close any open files, exit any open programs, click the Start button, and then click Turn Off Computer.

b. In the Turn off computer window, click Turn off.

The computer turns off after the operating system shutdown process finishes.



2. Ensure that the computer and any attached devices are turned off. If your computer and attached devices do not automatically turn off when you shut

down your operating system, press and hold the power button for 4 seconds.

Before Working Inside Your Computer

Use the following safety guidelines to help protect your computer from potential damage and to help ensure your own personal safety.



1. Ensure that the work surface is flat and clean to prevent the computer cover from being scratched.



2. Turn off your computer. See Turning Off Your Computer.

NOTICE: To avoid losing data, save and close any open files and exit any open programs before you turn off your computer.

CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.

CAUTION: Handle components and cards with care. Do not touch the components or contacts on a card. Hold a card by its edges or by its metal

mounting bracket. Hold a component such as a processor by its edges, not by its pins.

NOTICE: Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell is not

covered by your warranty.

NOTICE: When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the cable itself. Some cables have a connector with

locking tabs; if you are disconnecting this type of cable, press in on the locking tabs before you disconnect the cable. As you pull connectors apart, keep

them evenly aligned to avoid bending any connector pins. Also, before you connect a cable, ensure that both connectors are correctly oriented and

aligned.

NOTICE: To avoid damaging the computer, perform the following steps before you begin working inside the computer.



3. Disconnect any telephone, network, and USB cables from the computer.



4. Disconnect your computer and all attached devices from their electrical outlets.



5. Turn over the computer.



6. Remove the battery.

a. Slide the battery-bay latch release lock on the bottom of the computer away from the battery.

b. Slide and hold the battery-bay latch release, and then remove the battery from the bay.



7. Press the power button to ground the system board.



8. Remove any installed ExpressCards from the ExpressCard slot.

Computer Orientation

Screw Identification

When you are removing and replacing components, print this section as a tool to lay out and keep track of the screws. The printout provides the number of

screws and their sizes.

NOTICE: To disconnect a network cable, first unplug the cable from your computer and then unplug it from the network wall jack.

NOTICE: To avoid damaging the system board, you must remove the main battery before you service the computer.

battery

battery-bay latch release

battery-bay latch release lock

front

left

back

right

Back to Contents Page



Optical Drive:

(1 each)



Fan Module:

(4 each)

Display Assembly

to Computer Base:

(4 each)



Modem to

System Board:

(2 each)

Display Bezel:

(6 each)



Display Panel:

(8 each)



Top of Palm Rest to

Computer Base:

(5 each of M2.5 x 5 mm)

(2 each of M2 x 3 mm)



Base Plastic to

Palm Rest From Bottom:

(10 each)

Hard Drive Carrier to

Hard Drive:

(2 each)



Speakers to

Base Plastics:

(1 for left speaker, 2 for right

speaker, 3 total)

System Board to

Base Plastics:

(5 each, system board)

Keyboard to Palm Rest:

(2 each)

Back to Contents Page

Flashing the BIOS

Dell™Inspiron™1300/B120/B130ServiceManual

Flashing the BIOS From a CD

Flashing the BIOS From the Hard Drive

If a BIOS-update program CD is provided with the new system board, flash the BIOS from the CD. If you do not have a BIOS-update program CD, flash the BIOS from

the hard drive.

Flashing the BIOS From a CD



1. Ensure that the AC adapter is plugged in and that the main battery is installed properly.



2. Insert the BIOS-update program CD, and restart the computer.

Follow the instructions that appear on the screen. The computer continues to boot and updates the new BIOS. When the flash update is complete, the

computer will automatically reboot.



3. Press <F2> during POST to enter the system setup program.



4. Press <Alt> and <F> to reset the computer defaults.



5. Press <Esc>, select Save changes and reboot, and press <Enter> to save configuration changes.



6. Remove the flash BIOS-update program CD from the drive and restart the computer.

Flashing the BIOS From the Hard Drive



1. Ensure that the AC adapter is plugged in, the main battery is properly installed, and a network cable is attached.



2. Turn on the computer.



3. Locate the latest BIOS update file for your computer at support.dell.com.



4. Click Download Now to download the file.



5. If the Export Compliance Disclaimer window appears, click Yes, I Accept this Agreement.

The File Download window appears.



6. Click Save this program to disk and then click OK.

The Save In window appears.



7. Click the down arrow to view the Save In menu, select Desktop, and then click Save.

The file downloads to your desktop.



8. Click Close if the Download Complete window appears.

The file icon appears on your desktop and is titled the same as the downloaded BIOS update file.



9. Double-click the file icon on the desktop and follow the instructions on the screen.

Back to Contents Page



NOTE: If you use a BIOS-update program CD to flash the BIOS, set up the computer to boot from a CD before inserting the CD.

Back to Contents Page

Coin-Cell Battery

Dell™Inspiron™1300/B120/B130ServiceManual

Removing the Coin-Cell Battery

Replacing the Coin-Cell Battery

Removing the Coin-Cell Battery



1. Follow the instructions in Before Working Inside Your Computer.



2. Remove the hinge cover. See Removing the Hinge Cover.



3. Remove the keyboard. See Removing the Keyboard.



4. Locate the coin-cell battery and disconnect the cable from the system board connector by pulling toward the coin-cell battery.



5. Remove the cable from the guides and lift the coin-cell battery from the computer.

Replacing the Coin-Cell Battery



1. Connect the cable to the system board by pushing it into the connector.



2. Route the cable through the channel and press the coin-cell battery into place.

CAUTION: Before performing the following procedures, read the safety instructions in the Product Information Guide.

CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of

your computer's electronic components. You can do so by touching an unpainted metal surface.

Autres manuels pour Inspiron 1300

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dell Ordinateur portable

Dell

Dell Latitude 5300 Manuel d'exploitation et d'entretien

Dell

Dell Inspiron 15 3000 Series Manuel utilisateur

Dell

Dell Latitude 6430u Manuel utilisateur

Dell

Dell N1100 Manuel utilisateur

Dell

Dell Inspirion M5040 Manuel utilisateur

Dell

Dell G5 15 5500 Manuel d'exploitation et d'entretien

Dell

Dell 1525 - Inspiron - Pentium Dual Core 1.86 GHz Manuel utilisateur

Dell

Dell D420 - Latitude Notebook Computer Manuel utilisateur

Dell

Dell Inspiron 14 3437 Manuel utilisateur

Dell

Dell Inspiron 1425 Manuel utilisateur

Dell

Dell Networking 8100 Series Mode d’emploi

Dell

Dell Inspiron 7300 2n1 Black Manuel utilisateur

Dell

Dell Inspiron 8200 Manuel utilisateur

Dell

Dell Vostro 3300 Manuel du propriétaire

Dell

Dell Latitude 100L Manuel utilisateur

Dell

Dell Inspiron 15 5000 Series Manuel utilisateur

Dell

Dell Latitude 6430u Manuel du propriétaire

Dell

Dell P01S Guide de référence

Dell

Dell Precision M70 Manuel utilisateur

Dell

Dell Latitude D510 Manuel utilisateur

Dell

Dell Inspiron 14 5000 Series Manuel utilisateur

Dell

Dell 3330 Manuel utilisateur

Dell

Dell G7 15 Manuel d'exploitation et d'entretien

Dell

Dell Inspiron 17 5000 Series Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

HP PROBOOK 4520S Manuel

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel

Lenovo

Lenovo THINKPAD X31 Manuel

Sony

Sony VGN-T240P VAIO Manuel utilisateur

Compaq

Compaq Armada E700 Series Manuel utilisateur

Fujitsu

Fujitsu Lifebook A6230 Manuel utilisateur

Acer

Acer Aspire ONE 722 Manuel utilisateur

Toshiba

Toshiba L300-EZ1524 Manuel utilisateur
