Drop-Ins

Drop-in product solutions

Delﬁ eld’s large variety of drop-in products is the best in the market. All models are stocked standard for quick

shipment or can be customized with available options to suit your needs. Whether for planned projects or un-

foreseen replacement needs, Delﬁ eld is ready to provide a solution. Each model can be ordered as individual

component or as part of Component Crafted Custom or Shelley Mobile Counters.

Safety:

UL and NSF

All Delﬁ eld Drop-in products are UL approved and NSF

certiﬁ ed. Which means you can count on safe, consistent

construction and performance every time.

Convenience:

Delﬁ eld Drop-in products are easy to install into any new

or existing counter. A press ﬁ t gasket comes pre-installed

making the units ready to drop-in immediately.

Quality:

Delﬁ eld Drop-in products have an unmatched level of

quality. The units are reliably built by the best in the in-

dustry and come standard with a 90-day labor and 1-year

parts warranty.

Construction:

Delﬁ eld Drop-in products are constructed with stainless steel tops and interiors. Cold

units are insulated with high-density polyurethane foam and hot units are insulated with

ﬁ berglass.

Refrigeration lines are secured to the liner with stainless steel spot clips and thermal

transfer compound is applied to improve heat transfer and cool the food product better.

N8100B N8000 8100-EF N8100-FA N8200G

N8100B 8100-EF

Delﬁ eld’s standard cold pans are built to suit your

needs. Superb operation and construction combine to

give you what you need, safe product temperatures.

LiquiTec® is better than the average cold pan!

Traditional cold pans are inefﬁ cient due to lack of contact

between the refrigeration lines and the interior liner

side. LiquiTec® takes what is usually on about 1/16”

contact per wrap and magniﬁ es it to 100% contact on

all 5 sides of the interior liner. An eutectic ﬂ uid is used

to completely surround the interior liner of the pan. The

ﬂ uid is harmless and sealed in by a stainless steel exterior

liner. The result is improved cooling ability that allows the

unit to have ﬂ ush mount pans and still maintain NSF-7

certiﬁ ed temperatures.

N8000

Mechanically Cooled Cold Pans

• Integral “V” shaped pan rest: no thumbscrews,

clips or hard to clean messes.

• Insulated with high density polyurethane foam.

• Pre-installed press ﬁ t ﬂ ange gasket for easy

installation into counters.

• HFC-134 refrigerant.

• Stainless steel louver is provided.

• Adapter bars for 12”x20” pans included.

• 1” drain provided.

• NSF-7 certiﬁ ed.

• Thermostat control with OFF position.

• 8’ cord with plug is standard.

Ice Cooled Cold Pans

• Integral “V” shaped pan rest: no thumbscrews,

clips or hard to clean messes.

• Insulated with high density polyurethane foam.

• Pre-installed press ﬁ t ﬂ ange gasket for easy

installation into counters.

• Adapter bars for 12”x20” pans included.

• 1” drain provided.

• Perforated false bottom is standard.

• NSF-2 certiﬁ ed.

LiquiTec® Cold Pans

• NSF-7 certiﬁ ed ﬂ ush mount design.

• Insulated with high density polyurethane foam.

• Preinstalled press ﬁ t ﬂ ange gasket for easy

installation into counters.

• HFC-404A refrigerant.

• Stainless steel louver provided.

• 12”x20” pan conﬁ gurations.

• 1” drain provided.

• Thermostat control with OFF position.

• Better Merchandising

• Better Ergonomics

• Better Labor Efﬁ ciency

• Better Energy Efﬁ ciency

• Better Food Retention

100%

cold contact

<2mm

cold contact

LiquiTec® Pan

Traditional Wrap Pan

100%

cold contact

<2mm

cold contact

N8100-FA N8200G

The N8100-FA cold pans are ideal for merchan-

dising your product. The ﬂ ush mount air-screen

design keeps your product cool and in view of

your customers.

Delﬁ eld frost tops are ideal for product presen-

tation while maintaining product temperatures.

Whether the granite or stainless steel tops are

desired, these units will help merchandise your

quick turn products.

Forced-Air Cold Pans

• Merchandise product in ﬂ ush mount pans.

• Air screen over pans for NSF-7 certiﬁ ed

temperatures.

• Air curtain assembley is easily removable

without tools for cleaning.

• Insulated with high density polyurethane foam.

• Pre-installed press ﬁ t ﬂ ange gasket for easy

installation into counters.

• 1” drain provided.

• HFC-404A refrigerant.

• Stainless steel louver is provided.

• Adapter bars for 12”x20” pans included.

Granite Frost Top

• “Absolute Black” granite top.

• Insulated with high density polyurethane foam.

• Drain trough around perimeter of top with

3/4” stainless steel drain.

• HFC-404A refrigerant.

• Stainless steel louver provided.

• On/Off switch.

• NSF-2 certiﬁ ed.

N8200

Frost Top

• Insulated with high density polyurethane foam.

• 1” raised top with slope to drain trough.

• Drain trough around perimeter of top with 1/2”

stainless steel drain.

• Preinstalled press ﬁ t ﬂ ange gasket for easy

installation into counters.

• HFC-404A refrigerant.

• Stainless steel louver provided.

• On/Off switch.

• NSF-2 certiﬁ ed.

N8600 N8700-D

At the ﬂip of a switch it’s two units in one! The

N8600 Hot and Cold Combination models provide

the needed functionality of both hot and cold

operations without having to add additional space to

your operation. The unit may be utilized in different

operations throughout the day or week as the menu

dictates. When ﬂexibility is a concern, this is the unit

for the job

Delﬁeld offers both individual well and single

tank models to suit your operation. Heavy duty

construction and easy installation make a nice

combination for any counter.

Hot and Cold Combination Pan

• NSF-4 and NSF-7 certiﬁed.

• 2 units in one, hot and cold operation.

• Insulated with high density polyurethane foam.

• Flush mount design for hot operation or recess

2” for cold operation.

• Single tank well with stainless steel immersion

heater(s).

• HFC-404A refrigerant.

• Preinstalled press ﬁt ﬂange gasket for easy

installation into counters.

• Remote control box with thermostat for hot

operation, indicator light and a 3-way power

switch for operation selection.

• Thermostat for cold operation is mounted next

to the compressor section.

Individual Well Hot Pans

• NSF-4 certiﬁed.

• Flush mount individual 12”x20” wells.

• Fiberglass insulation.

• 1/2” stainless steel drain with manifold and gate

valve.

• Preinstalled press ﬁt ﬂange gasket for easy

installation into counters.

• Remote panel with individual temperature

controls for each well.

• Utilize for wet or dry operation.

N8800

Open Well Hot Pans

• NSF-4 certiﬁed.

• Fiberglass insulation.

• 1/2” stainless steel drain.

• Preinstalled press ﬁt ﬂange gasket for easy

installation into counters.

• Remote thermostat control for mounting in

counter.

• Single tank with 12”x20” openings.

• Utilize for wet or dry operation.

N225/N227 F5

Delﬁeld’s N225 and N227 models make serving

ice cream cool! These units make adding ice

cream to any menu possible.

The F5 Serview display case can be used to

merchandise everything from drinks to desserts.

Whether in the back counter for full service

operation or front counter for self-service

operation, the product is in your customer’s

sight.

Ice Cream Cabinets

• NSF-7 certiﬁed.

• Preinstalled press ﬁt ﬂange gasket for easy

installation into counters.

• Insulated with high density polyurethane foam.

• Thermostat temperature control.

200/300

Water and Ice Stations

• Glass and pitcher ﬁllers.

• Ice chests.

• Combination units.

Serview Display Cases

• NSF-7 certiﬁed.

• Insulated with high density polyurethane foam.

• Thermostat temperature control.

• Sliding glass doors.

• See-through back, mirrored back and pass-thru

models available.

• Interior light with exterior mounted On/Off switch.

• Several dish dispenser, cup dispenser and tray

dispenser models available.

• Dish dispensers available as heated or non-heated.

Shelleymatic

Dispensers

Options

Drop-in units can be customized to suit your needs! Everything from custom counter

protectors to custom pan sizes are available. Let us know what your requirements are and we’ll

provide the solution.

Options for Drop-Ins

Additional adaptor bars

or plates.

Single and double service

sneezeguards.

Custom counter

protectors.

220V/50C electrical.

Mullion fan assembly.

Extended warranties.

Remote refrigeration or

relocate the compressor.

Add/omit drains,

manifolds and valves.

Custom sizes.

N8600 N8700-D N225/N227 F5 Shelleymatic















              















 



REACH-INS / PREP TABLES / SHELLEY® SERVING COUNTERS / DROP-INS / COMPONENT CRAFTED EQUIPMENT

PHONE: 800-733-8948 / FAX: 800-699-0619 / WEB: WWW.DELFIELD.COM

Mechanically Cooled Cold Pan Cutout Size

N8118B 17" X 25"

N8130B 29.75 X25"

N8143B 42.50 X 25"

N8156B 55.25 X 25"

N8169B 68" X 25"

N8181B 80.75" X 25"

Mechanically Cooled Narrow Cold Pan Cutout Size

N8146NB 45.75" X 17"

N8168NB 66.5" 17"

Ice Cooled Cold Pan Cutout Size

N8018 17" X 25"

N8030 29.75 X25"

N8043 42.50 X 25"

N8056 55.25 X 25"

N8069 68" X 25"

N8081 80.75" X 25"

Ice Cooled Narrow Cold Pan Cutout Size

N8046N 45.75" X 17"

N8068N 66.5" 17"

Forced-Air Cold Pan Cutout Size

N8131-FA 30.25" X 25.5"

N8144-FA 43" X 25.5"

N8157-FA 55.75" X 25.5"

N8169-FA 68.5" X 25.5"

N8182-FA 81.25" X 25.5"

LiquiTec Mechanically Cooled Cold Pan Cutout Size

8118-EF 17" X 25"

8132-EF 30.75" X 25"

8145-EF 44.25" X 25"

8159-EF 57.87" X 25"

8172-EF 71.5" X 25"

8186-EF 85" X 25"

DBDROPINS

04/06

LiquiTec Mechanically Cooled Narrow

Cold Pan

Cutout Size

8148-EFN 46.88" X 17.25"

8169-EFN 68.5" X 17.25"

8191-EFN 90" X 17.25"

Granite Frost Top Cutout Size

N8231G 30.75" X 25"

N8245G 44.63" X 25"

N8259G 58.5" X 25"

N8273G 72.38" X 25"

Stainless Steel Frost Top Cutout Size

N8231 30.75" X 25"

N8245 44.63" X 25"

N8259 58.5" X 25"

N8273 72.38" X 25"

N8287 86.25" X 25"

Combination Hot/Cold Food Well Cutout Size

N8630 29.75 X25"

N8643 42.50 X 25"

N8656 55.25 X 25"

N8669 68" X 25"

N8681 80.75" X 25"

Individually Heated Food Wells Cutout Size

N8717-D 16.88" X 25"

N8731-D 30.75" X 25"

N8745-D 44.62" X 25"

N8759-D 58.5" X 25"

N8773-D 72.37" 25"

N8787-D 86.25" X 25"

Individually Heated Narrow Food Wells Cutout Size

N8746N 44.62" X 15"

N8768N 66.5" X 15"

Single Tank Heated Food Well Cutout Size

N8831 30.75" X 25"

N8845 44.63" X 25"

N8859 58.5" X 25"

N8873 72.38" X 25"

N8887 86.25" X 25"

Ice Cream Freezers with S/S Lid Cutout Size

N225 26.37" X 15.37"

N227 26.37" X 28.56"

Ice Cream Freezers with Lexan Lid Cutout Size

225L 26.37" X 15.37"

227L 26.37" X 28.56"

200/300 Ice & Water Stations Cutout Size

See specs for details

F5 Display Cases Cutout Size

See specs for details

ShelleyMatic Cutout Size

See specs for details

Autres manuels pour N225

Ce manuel convient aux modèles suivants

Autres manuels Delfield Réfrigérateur

Delfield

Delfield 4472N-12 Manuel utilisateur

Delfield

Delfield UCD4472N Manuel utilisateur

Delfield

Delfield ST4472N Manuel utilisateur

Delfield

Delfield 4400 series Manuel utilisateur

Delfield

Delfield Shelleyspeed SPRH-68W Manuel utilisateur

Delfield

Delfield Enodis 400 Series Manuel utilisateur

Delfield

Delfield Shelleybasic Manuel utilisateur

Delfield

Delfield Specification Line GADTR1P-SH Guide de dépannage

Delfield

Delfield UC4432N Manuel utilisateur

Delfield

Delfield UC4472N-18M Manuel utilisateur

Delfield

Delfield 4432N-12M Manuel utilisateur

Delfield

Delfield ST4427N Manuel utilisateur

Delfield

Delfield SADFLPT2-S Manuel utilisateur

Delfield

Delfield Shelleyspeed SPR-40W Manuel utilisateur

Delfield

Delfield Salad Top ST4472N-12 Manuel utilisateur

Delfield

Delfield 4472N-18M Manuel utilisateur

Delfield

Delfield 4400 series Manuel utilisateur

Delfield

Delfield 4460N-12M Manuel utilisateur

Delfield

Delfield 4472N Manuel utilisateur

Delfield

Delfield Shelleybasic Series Manuel utilisateur

Delfield

Delfield Versa Drawer Manuel utilisateur

Delfield

Delfield Versa Drawer 18600VD Manuel utilisateur

Delfield

Delfield Nordic Zone Cold Food Bars Manuel utilisateur

Delfield

Delfield F15 Series Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
