Regulation
IniControl
For C 330 / C 630 ECO
C003108-A
Installation, User
and Service
Manual
7600717-001-06
Contents
1 Introduction ................................................................................................4
1.1 Symbols used .......................................................4
1.2 Liabilities ...............................................................4
1.2.1 Manufacturer’s liability .............................................4
1.2.2 Installer’s liability .....................................................5
1.2.3 User’s liability ..........................................................5
1.3 Certifications .........................................................6
2Safety instructions and recommendations ..............................................7
2.1 Recommendations ................................................7
3Technical specifications ............................................................................8
3.1 Sensor characteristics .........................................8
4Installation ..................................................................................................9
4.1 Package list ...........................................................9
4.1.1 Standard delivery ....................................................9
4.1.2 Accessories .............................................................9
4.2 Installing the outside sensor ...............................9
4.2.1 Choice of the location ..............................................9
4.2.2 Connecting the outside sensor ..............................10
4.3 Fitting and connecting the control panel .........10
4.4 Electrical connections ........................................11
4.4.1 Connecting a direct heating circuit ........................11
4.4.2 Connection in cascade (with OpenTherm AD287)
option ....................................................................11
5 Commissioning ........................................................................................13
5.1 Control panel .......................................................13
5.1.1 Description of the keys ..........................................13
5.1.2 Description of the display ......................................14
5.2 Switch on the instrument panel ........................15
5.3 Reading out measured values ...........................16
5.3.1 Reading out measured values ..............................16
5.3.2 Readout from the hour counter and percentage of
successful starts ....................................................17
5.3.3 Status and sub-status ...........................................18
1260216 - 7600717-001-06
5.4 Changing the settings ........................................19
5.4.1 General .................................................................19
5.4.2 Parameter descriptions .........................................19
5.4.3 Modification of the user-level parameters .............23
5.4.4 Modification of the installer-level parameters ........24
5.4.5 Setting the maximum heat input for central heating
operation ...............................................................25
5.4.6 Return to the factory settings Reset Param ..........26
5.4.7 Carrying out an auto-detect ...................................26
5.4.8 Setting the manual mode ......................................27
6 Troubleshooting .......................................................................................28
6.1 Shutdowns and lock-outs ..................................28
6.1.1 General .................................................................28
6.2 Error memory ......................................................35
6.2.1 Error readout memorised ......................................35
6.2.2 Deletion of the error display ..................................36
Contents
2260216 - 7600717-001-06
3260216 - 7600717-001-06
1 Introduction
1.1 Symbols used
In these instructions, various danger levels are employed
to draw the user’s attention to particular information. In so
doing, we wish to safeguard the user’s safety, highlight
hazards and guarantee correct operation of the appliance.
DANGER
Risk of a dangerous situation causing serious
physical injury.
WARNING
Risk of a dangerous situation causing slight
physical injury.
CAUTION
Risk of material damage.
Signals important information.
¼Signals a referral to other instructions or other pages
in the instructions.
1.2 Liabilities
1.2.1. Manufacturer’s liability
Our products are manufactured in compliance with the
requirements of the various applicable European
Directives. They are therefore delivered with [ marking
and all relevant documentation.
IniControl For C 330 / C 630 ECO 1. Introduction
260216 - 7600717-001-06 4
In the interest of customers, we are continuously
endeavouring to make improvements in product quality.
All the specifications stated in this document are therefore
subject to change without notice.
Our liability as the manufacturer may not be invoked in the
following cases:
4Failure to abide by the instructions on using the
appliance.
4Faulty or insufficient maintenance of the appliance.
4Failure to abide by the instructions on installing the
appliance.
1.2.2. Installer’s liability
The installer is responsible for the installation and
commissioning of the appliance. The installer must
respect the following instructions:
4Read and follow the instructions given in the manuals
provided with the appliance.
4Carry out installation in compliance with the prevailing
legislation and standards.
4Perform the initial start up and carry out any checks
necessary.
4Explain the installation to the user.
4If a maintenance is necessary, warn the user of the
obligation to check the appliance and maintain it in
good working order.
4Give all the instruction manuals to the user.
1.2.3. User’s liability
To guarantee optimum operation of the appliance, the
user must respect the following instructions:
4Read and follow the instructions given in the manuals
provided with the appliance.
4Call on qualified professionals to carry out installation
and initial start up.
4Get your installer to explain your installation to you.
4Ensure the Appliance is serviced in accordance with
the manufacturer’s instructions by a suitable qualified
person.
4Keep the instruction manuals in good condition close
to the appliance.
1. Introduction IniControl For C 330 / C 630 ECO
5260216 - 7600717-001-06
This appliance is not intended to be used by persons
(including children) whose physcial, sensory or mental
capacity is impaired or persons with no experience or
knowledge, unless they have the benefit, through the
intermediary of a person responsible for their safety, of
supervision or prior instructions regarding use of the
appliance. Care should be taken to ensure that children
do not play with the appliance.
If the mains power lead is damaged it must be replaced
by the original manufacturer, the manufacturer’s dealer or
another competent person to prevent hazardous
situations.
1.3 Certifications
This product complies to the requirements to the
european directives and following standards:
42006/95/EC Low Voltage Directive. Reference
Standard: EN60.335.1.
42004/108/EC Electromagnetic Compatibility Directive.
Generic standards: EN1000-6-3 , EN 61000-6-1.
IniControl For C 330 / C 630 ECO 1. Introduction
260216 - 7600717-001-06 6
2 Safety instructions and
recommendations
2.1 Recommendations
WARNING
Any intervention on the appliance and heating equipment
must be carried out by a qualified engineer.
For a proper operating of the boiler, follow carefully the
instructions.
Keep this document close to the place where the boiler is
installed.
2. Safety instructions and recommendations IniControl For C 330 / C 630 ECO
7260216 - 7600717-001-06
3 Technical specifications
3.1 Sensor characteristics
Outside sensor
Temperature in °C -20 -16 -12 -8 -4 0 4 8 12 16 20 24
Resistance in Ω 2392 2088 1811 1562 1342 1149 984 842 720 616 528 454
Specifications of the flow sensor circuit B + C
Specifications of the DHW sensor
Specifications of the system sensor
Temperature in °C 0 10 20 25 30 40 50 60 70 80 90
Resistance in Ω 32014 19691 12474 10000 8080 5372 3661 2535 1794 1290 941
IniControl For C 330 / C 630 ECO 3. Technical specifications
260216 - 7600717-001-06 8
4 Installation
4.1 Package list
4.1.1. Standard delivery
The delivery includes:
4The control panel with the IniControl module
4Installation, use and maintenance manual for the control panel
4.1.2. Accessories
Various options are available depending on the configuration of the
installation:
Control system options
Description package
BUS connection cable (length 12 m) AD134
voice remote monitoring module AD152
OpenTherm interface AD287
Outside sensor FM46
RX11 cable AD124
Modulating room thermostat AD265
Radio-controlled modulating room thermostat AD266
Digital room thermostat AD137
Wireless settable ambient thermostat AD200
SCU-S05 PCB
SCU-S03 PCB
4.2 Installing the outside sensor
4.2.1. Choice of the location
It is important to select a place that allows the sensor to measure the
outside conditions correctly and effectively.
Advised positions:
4on one face of the area to be heated, on the north if possible
4half way up the wall in the room to be heated
4under the influence of meteorological variations
4. Installation IniControl For C 330 / C 630 ECO
9260216 - 7600717-001-06
