Dedicated Micros CamVu 2000 Manuel utilisateur

CamVu 2000

Camera

User Guide

CamVu 2000 Camera

1.01

Contents

Introduction .................................................................................3

Rear Connections .......................................................................6

Network..................................................................................... 11

General .....................................................................................12

Video.........................................................................................13

6.25Audio.........................................................................................15

Serial.........................................................................................16

User Access ..............................................................................17

6.25Camera .....................................................................................18

6.25Connections..............................................................................19

Connecting to the CamVu 2000 Camera ..................................20

CamVu 2000 Camera

Introduction

1.03

Offering up to six times the denition of analogue cameras, the Dedicated Micros CamVu 2000 Camera is

ideal for situations where high resolution, high quality images are required. The camera’s high denition

technology is based on Dedicated Micros award winning NetVu Connected architecture, allowing seamless

operation and deep integration with a wide range of DVRs and other devices, as well as simplied

integration into large-scale systems.

The unique Dedicated Micros soft codec technology allows the CamVu 2000 camera to transmit

simultaneous MPEG-4 and JPEG images to the associated DVR for image capture. This exibility allows

users to record high quality images for evidence and watch streamed video at the same time.

Ideal for applications such as public space monitoring, retail or banking installations. The CamVu 2000

camera can be housed internally or externally (via an external camera housing) to cover a wide eld of

view. Its web conguration pages allow the installer to adjust the cameras features over the network without

the need to return to the site. The CamVu 2000 camera is the ideal choice for capturing high quality, high

denition images

Features

• Chipwrights 5521 ViSP (Visual Signal Processor)

• 1600x1200 max resolution

• Max frame rate at max res 5fps

• Max frame rate at CIF res 30fps

• Programmable camera settings

• CS mount lens (C mount capable with adapter)

• Extruded aluminium housing

• Accessory mounting ¼” 20 UNC or ¼” BSW (bottom)

• PoE to IEEE802.3af (option)

• Two way push fit connector for 12VDC (or 24VAC option)

• RJ45 network port

• Audio input via 3.5mm stereo jack

• Built in web server for configuration

• JPEG and MPEG-4 delivered simultaneously for live viewing and recording

• Serial port via D-Type for RS232 (3 wire), RS485 (2 wire) and RS422 (4

wire)

Features To Be Supported In Future Releases

• SD media slot

• 2 x EOL alarm inputs

• 500mA light duty relay output

• Audio output

• BNC output congurable for PAL or NTSC

• Four pin lens connector for DD iris control

CamVu 2000 Camera

Benets

• High resolution image capture provides more detail to increase the ability to

identify a suspect.

• Wide area can be covered by a single camera.

• Enables High Definition CCTV, which is not possible with analogue

cameras.

• Operates seamlessly within a NetVu Connected network.

• Telemetry support allows the Megapixel camera to be paired with a Pan/Tilt

housing

• Remote configuration removes the need for multiple revisits

• Images can be viewed over low bandwidth networks using MPEG-4 but

captured in JPEG

• BNC Connector allows local lens adjustment or spot monitor positioning*

• Pre-Alarm allows the moments prior to an incident to be captured.*

* This feature will be available after future development.

Components Supplied

Before installing unit, please verify that all items listed below have been supplied:

1 x CamVu camera

1 x User Guide

1 x Set of 3 CDs containing information and software for use with the camera

1 x C/CS lens conversion ring

1 x 9DF-9DF RS232 communications cable

Note: A PSU is not supplied with this camera. If the camera is a Power Over Ethernet (POE) version

(DM/CMVU2000D) it is not necerssary to use a seperate PSU if power is available via the

Ethernet connection. Otherwise a suitable 12Vdc 0.5A PSU (for any version of the camera) or a

24Vac. 0.25A PSU (for the DM/CMVU2000A version of the camera) is required.

Alternatively a 12Vdc PSU can be purchased from Dedicated Micros.

CE NOTICE (EUROPEAN UNION)

This section contains the regulatory declarations for the EU for the CamVu 2000 Camera.

This product is marked with the CE symbol and indicates compliance with all applicable Directives. A

“Declaration of Conformity” is held at Dedicated Micros LTD, 1200 Daresbury Park, Daresbury, Cheshire

WA4 4HS WWW.dedicatedmicros.com

Hereby, Dedicated Micros LTD, declares that this CamVu 2000 Camera is in compliance with the essential

requirements and other relevant provisions of Directive 95/5/EC.

Marking by the symbol CE indicates compliance of this Dedicated Micros product to the Electromagnetic

Compatibility Directive 89/336/EEC, and the Low Voltage Directive 73/23/EECof the European Union. Such

marking is indicative that this system meets the following technical standards

CamVu 2000 Camera

• EN 61000-6-3 EMC Standard Residential, Commercial and Light Industry.

• EN 62000-3-3 Limitations of voltage changes, uctuations and icker in

public low-voltage supply systems for equipment with rated current up to

16A.

• EN 61000-3-2 Limits for harmonic current emissions for equipment with

rated current up to 16A.

• EN 50130-4 Immunity requirements for components of re, intruder and

social alarm systems.

• EN 60950 Safety of IT and similar equipment.

• EN 55022 Class A. Radiated Emissions Standard, suitable for Commercial

or Residential use

Further details about these applicable standards can be obtained from Dedicated Micros Ltd., 1200

Daresbury Park, Daresbury, Cheshire WA4 4HS

1.01002

RF Interference warning

This is a class A product. In a domestic environment this product may cause radio frequency interference , in

which case the user may be required to take adequate measures.

1.01003

Canadian EMC statement

This product is compliant with Class A ICES-003

Note: This Class A product meets the requirements of the Canadian Interference causing equipment

regulations. Cet appareil numerique de la Classe A, respect toutes les exigencies du reglement

sur le materiel brouilleur du Canada.

Important Safeguards

4.15

Read Instructions

All the safety and operating instructions should be read before the unit is operated and adhered to during

operation. These instructions should be retained with the unit, and all warnings and cautions contained

should be heeded.

Power Sources

This unit should be operated only from the type of power source indicated on the manufacturer’s label.

Power Over Ethernet

Versions of this product support POE and when connected to a suitable switch, will not require an external

PSU to drive the device.

Servicing and Repair

Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous

voltage or other hazards.

Refer all servicing and repair to qualied service personnel.

Equipment

Use only attachments/accessories specied by the manufacturer.

Ventilation

Ensure unit is properly ventilated to protect from overheating.

CamVu 2000 Camera

Rear Connections

The CamVu 2000 features push t connectors which house connections for 12VDC power and the relay

output. There are also connections for an audio input (via 3.5mm stereo jack socket) and an RJ45 socket for

connection to a suitable network point. Telemetry information is passed to the camera via the D type socket.

This can be congured for RS232, RS485 or RS422 protocols. The BNC connection is used in conjunction

with a local monitor to focus the camera once installed.

• Serial port via D-Type for RS232 (3 wire), RS485 (2 wire) and RS422 (4wire)

• Audio input and output via 3.5mm stereo jack

• BNC output congurable for PAL or NTSC*

• Two way push t connector for 12VDC (or 24VAC depending on version)

• LEDs for power and network access

• RJ45 network port (with POE option)

• 2 x EOL alarm inputs*

• 500mA light duty relay output*

• SD media slot with LED*

*Please note that this feature will be available after future development.

CamVu 2000 Camera

Overview of the CamVu 2000

Step 1 Connecting to the Network

Note: If the device utilises POE (Power Over Ethernet), this step should be postponed until all other

devices are connected.

The CamVu 2000 supports one RJ45 network port. Use a properly screened Ethernet cable to connect the

unit to the network.

By default the unit is congured for DHCP (Dynamic Host Conguration Protocol). DHCP works on assigning

an IP address at initial connection to the network. It is however possible for this IP address to change

without notication (i.e. in the case of power failure). Therefore it is recommended that the CamVu 2000 is

allocated a xed IP address to remove the possibility of address change.

5.13

Step 2 Connecting Video

The CamVu 2000 has a 75Ω BNC connector congurable for PAL or NTSC which can be used to focus the

lens during installation. The video feed will be sent via the network connection.

Note: This feature will be available after future development.

Step 3 Connecting Alarms

The CamVu 2000 supports two EOL (End Of Line) alarm inputs, these are located on the push t connector.

The End Of Line (EOL) functionality is part of the Advanced Alarms supported on NetVu Connected products

and included features required for Central Monitoring and is compatible with the British Standard BS8418.

5.14,

Please note that this feature will be available after future development.

CamVu 2000 Camera

Step 4 Connecting Audio

The CamVu 2000 support a single channel of bi-directional audio, accessable through NetVu ObserVer.

Connect the audio equipment to the 3.5mm stereo socket. The tip of the jack shall be used for audio input.

The following modes of operation are supported:

• Challenge – one way audio, DVR to camera, optionally recorded.*

• Listen – one way audio from the camera to the DVR, optionally recorded.

• Help Point – two way audio, optionally recorded.

* Client sourced audio will be available after future development

5.151

Step 5 Connecting Power

Note: If the device utilises POE, this step would not be necessary. Connect the Network connector at

this stage.

The CamVu 2000 is supplied by a two way 3.81mm pitch screw terminal push t connector, seperate to the

alarm connector.

Please note that there are two versions of this camera:

For DM/CMVU2000A, power can be 12Vdc or 24Vac via screw terminal connector

For DM/CMVU2000D power can be 12Vdc via screw terminal connector or POE via network connector.

CamVu 2000 Camera

Conguring the Unit

Locating the Unit IP address

The unit is congured using the on-board web pages. This can be done remotely once the unit has been

installed in position.

The IP address of the unit is required to access these pages. The assigned IP address can be found by

using the serial port. For ease of conguration, it is recommended that the installer sets the IP address

before installing the unit in position.

One of the rst tasks should be to disable DHCP and assign a permanent IP address to the unit. If this is not

done, the IP address of the unit may change whenever it is powered off, and the new address will have to be

acquired directly from the unit (ie using a serial connection or by connecting a spot monitor and cycling the

power).

It is possible to enable DHCP to allow the unit to acquire a free IP address and then allocate the address

permanently by entering the details in the IP address elds of the cameras Network web page (refer to page

11) which will also disable DHCP.

If a permanent IP address is not assigned to the unit, it will attempt to contact the DHCP server every time it

starts up. If for any reason a DHCP server cannot allocate an IP address to the unit, the camera will use a

default IP address (169.254.6.10)

Note: Always consult the network administrator for IP Address, Subnet Mask and Gateway information.

To acquire the IP address using the serial connection;

1. On the PC, click Start->Programs->Accessories->Communications->Hyperterminal and create

a new connection via the COM port using the following settings:

Bits per second 38400

Data Bits 8

Parity None

Stop bits 1

Flow Control None

2. With the power to the camera disconnected, connect a standard 9DF-9DF RS232

communications cable from the PC to the serial port of the unit. Connect power to the camera.

3. Hyperterminal will display the communications information as the unit boots. This will include

the IP address, Subnet and Gateway.

4. To alter the IP address settings of the camera from the Hyperterminal, input the following

information after the camera has nished its startup:

setip followed by the new IP address e.g. setip 192.168.1.100

setsub followed by the new subnet mask e.g. setsub 255.255.0.0

setgw followed by the new gateway address e.g. setgw 192.168.50.1

reset (to reset the camera so that the new IP address settings are adopted)

6.101

6.11

CamVu 2000 Camera

Accessing the Conguration Web Pages

The unit is congured using the on-board web pages. To access these:

1. Launch Internet Explorer (or Netscape Navigator).

6.12

2. Type the IP address of the unit into the address bar.

3. The Main Menu page will be displayed.

6.13

The conguration menus are accessible via the links on the left hand side of the page.

Note: Changes made to the settings on the webpages are saved to the camera when the webpage is

refeshed. Ths can be done by clicking on the webpage name in the links on the left-hand side

of the page. Clicking cancel before the webpage is refeshed will cancel any changes that have

been made on the webpage without saving them to the camera.

Autres manuels pour CamVu 2000

Table des matières

Autres manuels Dedicated Micros Caméra de sécurité

Dedicated Micros

Dedicated Micros ICE series Manuel utilisateur

Dedicated Micros

Dedicated Micros DM/ICE-HYPER-D Manuel utilisateur

Dedicated Micros

Dedicated Micros 2060 Manuel utilisateur

Dedicated Micros

Dedicated Micros Oracle Manuel utilisateur

Dedicated Micros

Dedicated Micros 1000 series Manuel utilisateur

Dedicated Micros

Dedicated Micros DM/ICEVC-BH39 Manuel utilisateur

Dedicated Micros

Dedicated Micros Dennard 2040 Guide de l'utilisateur

Dedicated Micros

Dedicated Micros 2010 Manuel utilisateur

Dedicated Micros

Dedicated Micros DM/ICEVS-BH39 Manuel utilisateur

Dedicated Micros

Dedicated Micros CamVu 2000 Manuel utilisateur

Dedicated Micros

Dedicated Micros DM Manuel utilisateur

Dedicated Micros

Dedicated Micros 2060 Manuel utilisateur

Dedicated Micros

Dedicated Micros DM/CAM/SDH36/N Manuel utilisateur

Dedicated Micros

Dedicated Micros DM18X Manuel utilisateur

Dedicated Micros

Dedicated Micros 2060 Manuel utilisateur

Dedicated Micros

Dedicated Micros HyperSense Manuel utilisateur

Dedicated Micros

Dedicated Micros DM/CMVUD500 Manuel utilisateur

Dedicated Micros

Dedicated Micros 504 Manuel utilisateur

Dedicated Micros

Dedicated Micros 2060 Manuel utilisateur

Dedicated Micros

Dedicated Micros Dennard 2040 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
