Dedicated Micros CamVu 500 Manuel utilisateur

CamVu 500

Installation and

Operation Manual

DM/CMVU500

DM/CMVU500/N

CamVu 500

Contents

Introduction ......................................................................3

Rear Connections ............................................................8

Connections.....................................................................9

Lenses ...........................................................................11

Conguring the Unit .......................................................12

System...........................................................................14

Display ...........................................................................40

Camera ..........................................................................45

ICR Settings...................................................................48

Schedule........................................................................60

Alarm Settings ...............................................................65

Network Settings............................................................76

Features & Text..............................................................93

Diagnostics ..................................................................100

Event Search ...............................................................102

Unit Operation..............................................................104

Specication ................................................................118

CamVu 500

Introduction

1.03

The updated CamVu500 is the latest addition to Dedicated Micros range of CamVu IP Cameras. Providing

excellent low light, performance the CamVu500 can transmit and record images in real-time and is designed

for Dedicated Micros next generation of video surveillance - Closed IPTV.

EXCELLENT LOW LIGHT PERFORMANCE

The CamVu500 uses a 1/4” CMOS progressive scan sensor that provides exceptional low light resolution

(<0.3 lux, @ F1.2). This incredible performance allows colour images to be produced in dimly lit scenes.

MULTIPLE, SIMULTANEOUS VIDEO STREAMS

Dedicated Micros’ unique Visual Signal Processor (ViSP) allows the CamVu 500 to transmit multiple

simultaneous MPEG-4, H.264 and/ or JPEG images to any number of associated NetVu Connected devices

for image viewing. Each stream can be tailored to suit the viewer’s bandwidth requirements.

11246

ANALYTICSCAPABLE

As part of our growing range of AnalyticsCapable products, the CamVu Day/Night dome is able to contain

the latest analytics solutions from Dedicated Micros including Object Left/Removed Detection Tripwire and

Counting Tripwire, all locally hosted on the camera.

11245

CLOSED IPTV

Dedicated Micros’ award winning Closed IPTV solution combines open standard IP protocols with patent

pending innovation to provide simple to install, safe and secure IP video solutions across new or existing

networks.

Automatically allocating IP addresses to IP cameras by physical port, a Closed IPTV system is completely

deterministic, creating rewalls and monitoring point-to-point IP connections so they cannot be hacked

or intercepted. Critical to the security of a Closed IPTV system is the unique implementation of Trusted

Endpoint technology; a secret signature, applied at lock down, enables endpoint devices such as IP

cameras to be secure, immediately triggering a security alert should any interference be detected.

This ground breaking solution provides a very simple and secure answer to IP video, meaning that no prior

knowledge of IP networking is required. Sophisticated and Dependable network security can be achieved

with a single click.

Features

■ Colour IP Mini-dome with excellent low light sensitivity

■ Integrated Camera Recording and full enterprise video server within camera

■ 0.3 lux F1.2

■ Can form part of a Closed IPTV system

■ Transmission of multiple, simultaneous video streams in MPEG-4, H.264 and JPEG format

enables multiple users to view video streams at the settings they require

■ AnalyticsCapable - enables analytics solutions to be deployed on your CCTV system

■ Direct conguration from any compatible NetVu Connected DVR or Video Server

■ MultiMode Recording - Dynamically-switchable resolution, record-rate & compression (MPEG-

4/H.264/JPEG) settings

CamVu 500

■ Web server for remote conguration of camera features

■ Power over Ethernet (PoE)

■ Local analogue test monitor output for use when positioning and adjusting the camera’s eld of

view and focus

■ Uses the latest Chipwrights ViSP to minimise power consumption and heat build up

Benets

• The camera supports recording to local SD card and network attached storage using ATA over

Ethernet

• The latest technology provides low light performance superb image quality and colour delity in

variable and high contrast lighting conditions.

• Operates seamlessly within a NetVu Connected network.

• Remote conguration removes the need for multiple revisits

• Images recorded locally on the camera in JPEG format can be viewed over low bandwidth

networks using MPEG-4

• BNC Connector allows local lens adjustment and display of the unit’s network settings on a

service monitor

Models

DM/CMVU500 ¼” 480p IP 2.8-10mm, PoE, 0.2 lux

DM/CMVUD500/N ¼” 480p IP 2.8-10mm PoE, 0.2 lux, NTSC

1. Back focus mechanism locking screw (both sides)

2. Back focus adjustment (Top & bottom)

3. Mounting bush (Top & bottom)

4. AI lens connector (DC & video)

CamVu 500

Components Supplied

Before installing unit, please verify that all items listed below have been supplied:

1 x CamVu Camera

1 x POE Injector Cable

1 x User Guide

1 x CD containing information for use with the camera

Note: A PSU is not supplied with this camera. A suitable 12Vdc 0.5A PSU is required if powering

the unit from its DC input connector - VS-PSU15W-EXT can be purchased separately from

Dedicated Micros.

If the camera utilises Power Over Ethernet, a separate PSU is not necessary (if power is

available via the Ethernet connection).

Alternatively if powering the unit over PoE using the supplied injector, a 48Vdc PSU that can

supply 15W is required - DM/PSU/48V can be purchased separately from Dedicated Micros.

CamVu 500

CE NOTICE (EUROPEAN UNION)

This section contains the regulatory declarations for the EU for the Unit Camera.

This product is marked with the CE symbol and indicates compliance with all applicable Directives. A

“Declaration of Conformity” is held at Dedicated Micros Ltd, 1200 Daresbury Park, Daresbury, Cheshire WA4

4HS www.dedicatedmicros.com

Hereby, Dedicated Micros LTD, declares that this Unit Camera is in compliance with the essential

requirements and other relevant provisions of Directive 95/5/EC.

Marking by the symbol CE indicates compliance of this Dedicated Micros product to the Electromagnetic

Compatibility Directive 89/336/EEC, and the Low Voltage Directive 73/23/EEC of the European Union. Such

marking is indicative that this system meets the following technical standards

• EN 61000-6-3 EMC Standard Residential, Commercial and Light Industry.

• EN 62000-3-3 Limitations of voltage changes, uctuations and icker in public low-voltage

supply systems for equipment with rated current up to 16A.

• EN 61000-3-2 Limits for harmonic current emissions for equipment with rated current up to 16A.

• EN 50130-4 Immunity requirements for components of re, intruder and social alarm systems.

• EN 60950 Safety of IT and similar equipment.

• EN 55022 Class A. Radiated Emissions Standard, suitable for Commercial or Residential use

Further details about these applicable standards can be obtained from Dedicated Micros Ltd., 1200

Daresbury Park, Daresbury, Cheshire WA4 4HS

1.01002

RF Interference warning

This is a class A product. In a domestic environment this product may cause radio frequency interference , in

which case the user may be required to take adequate measures.

1.01003

Canadian EMC statement

This product is compliant with Class A ICES-003

Note: This Class A product meets the requirements of the Canadian Interference causing equipment

regulations. Cet appareil numerique de la Classe A, respect toutes les exigencies du reglement

sur le materiel brouilleur du Canada.

Important Safeguards

4.15

Read Instructions

All the safety and operating instructions should be read before the unit is operated and adhered to during

operation. These instructions should be retained with the unit, and all warnings and cautions contained

should be heeded.

Power Sources

This unit should be operated only from the type of power source indicated on the manufacturer’s label.

CamVu 500

Power Over Ethernet

This product supports POE and when connected to a suitable switch, will not require an external PSU to

drive the device (Bridge and end-span compatible).

Servicing and Repair

Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous

voltage or other hazards.

Refer all servicing and repair to qualied service personnel.

Equipment

Use only attachments/accessories specied by the manufacturer.

Ventilation

Ensure unit is properly ventilated to protect from overheating.

Camera Care

In order to avoid damaging your camera, note the following points:

CAUTION

• The camera has threaded mounting points on the top and bottom of the case. Only use a

standard, photographic mounting bolt with a 1/4-20 UNC thread.

• Before tting the lens, make sure that its back will not touch the CMOS sensor or associated

components when screwed fully home.

• Do not touch the image surface of the sensor. If the sensor is accidentally touched, only clean it

using isopropanol.

• Do not expose the camera sensor to very bright light over a long period of time as this may

cause damage to the sensor. The camera and lens set-up must be correct to avoid possible

damage due to long term exposure to bright light. A lens with an automatic iris is recommended

under these conditions.

CamVu 500

Rear Connections

The CamVu 500 features push t connectors which house connections for 12VDC power. There is also

a PoE capable RJ45 socket for connection to a suitable network point. The BNC video output connection

is used in conjunction with a local monitor to focus the camera during installation and can also be used to

display the camera’s current network settings.

Note: The BNC output only operates for 10 minutes after the camera is powered up.

DM/CMVU500

DM/CMVU500/N

DM/CMVU500/P

DM/CMVU500/PN

3 4

1. Low voltage connector (12Vdc/24Vac 50/60Hz)

2. Power indicator LED

3. Power over Ethernet capable RJ45 socket

4. Composite video output BNC

5. MicroSD activity LED

6. MicroSD card slot

CamVu 500

Connections

Power Connections

CamVu 500 cameras are available in PoE plus AC/DC low voltage types. The voltage required to operate

the camera is clearly marked on the rear panel of the camera. The power LED on the rear panel indicates

that power is connected.

Power over Ethernet

The camera can be powered from any suitable PoE injector conforming to IEEE 802.3-2008. End span and

bridging injectors supported.

Auto-Switching Low Voltage Power Supply

The camera is tted with an automatic selecting power supply operate between 12 VDC and 24 VAC.

Connections and polarity are indicated beside the connector on the rear panel. The power supply must be a

class 2 isolated type.

Network Connections

Connection to a 10/100 BaseT network is made via the RJ45 on the rear panel.

Video Connector

Connect a video coaxial cable terminated with a 75Ω BNC connector to the BNC socket marked VIDEO

OUT on the rear of the camera to align the camera.

Note: This video output is only active for 10 minutes after the unit is powered up.

CamVu 500

Lens Connections

Fixed and Manual iris lenses (for indoor use only) require no wiring connections.

Auto Iris Lens

Connect the auto iris lens to the four-pin connector located on the side of the camera. If the lens does not

have a DD plug tted then wire the lens to a suitable plug. Pin connections for the iris drive plug are shown

below.

PIN DIRECT DRIVE AUTO IRIS LENS

1 Control coil positive (+)

2 Control coil negative (-)

3 Drive coil negative (-)

4 Drive coil positive (+)

POE Injector Cable

The POE Injector cable is designed to enable the use of POE (Power over Ethernet) before a POE capable

switch has been installed. It is installed alongside a suitable 48Vdc PSU that can supply 15W is required -

DM/PSU/48V can be purchased separately from Dedicated Micros.

A Connection to DVR/NVR/Layer 3 Enhanced CCTV Switch

B Connection to suitable 48Vdc 15W PSU - (DM/PSU/48V)

C Ethernet cable connection to camera.

Important: 48V is supplied to connection C. There is no voltage at Connection A. Do NOT

connect an ethernet cable from connection C to the DVR/Layer 3 Enhanced CCTV

Switch as this could cause irreparable damage.

POE Injector Power Supply specication

Adaptor socket - 5.5mm diameter with a 2.1mm central circular pin

+48V goes to the centre pin of the power connector - 0V to the outside barrel

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dedicated Micros Caméra IP

Dedicated Micros

Dedicated Micros CamVu 720 Manuel

Dedicated Micros

Dedicated Micros smartvu Manuel utilisateur

Manuels Caméra IP populaires d'autres marques

FLIR

FLIR Exx series Manuel utilisateur

Avigilon

Avigilon H4A-BO1-IR Manuel utilisateur

Digital Watchdog

Digital Watchdog DWCA-C128-64 Manuel utilisateur

ShareTech

ShareTech AV1 Manuel utilisateur

Ezviz

Ezviz C6C Manuel utilisateur

Melchioni

Melchioni UCAM 2015 Manuel utilisateur

Geutebruck

Geutebruck G-Cam/ESD-4630 Manuel utilisateur

Arecont Vision

Arecont Vision MegaBall AV3146DN-3310-D-LG Manuel utilisateur

Mitel

Mitel 6800i Series Manuel de service

Vitek

Vitek VTC-IR403-212NP Manuel utilisateur

THOMSON

THOMSON DSC - 323W Manuel utilisateur

AVer

AVer FB2027 Manuel utilisateur

ENFORCER

ENFORCER EV-T5105-N2SQ Manuel utilisateur

Wansview

Wansview NC543 Manuel utilisateur

Eneo

Eneo MCB-64A0003M0A Manuel utilisateur

deView electronics

deView electronics CBDNI36F Manuel utilisateur

Swann

Swann SwannEye Manuel utilisateur

LevelOne

LevelOne IP CamSecure Manuel utilisateur
