MD‐QUADHardwareManualforFirmwareVersion2.0
Copyright©2014DecimatorDesignPtyLtd,Sydney,Australia
E&OE
4
MenuSubset=0/Rotary=A.AudioMeterEnableforSelectedInput/s
LED1LED2LED3LED4Description
OffOffOffOffOff
OffGreenOffOff1PairsonLeft
GreenOffOffOff2PairsonLeft
OffOffOffGreen1PairsonRight
OffGreenOffGreen1PairsonLeftandRight
GreenOffOffGreen2PairsonLeftand1PaironRight
OffOffGreenOff2PaironRight
OffGreenGreenOff1PairsonLeftand2PaironRight
GreenOffGreenOff2PairsonLeftand2PaironRight
MenuSubset=0/Rotary=B.AudioBarScale
LED1LED2LED3LED4ReferenceLevel
OffOffOffOffAES/EBU
OffOffOffGreenVU
OffOffGreenOffExtendedVU
OffOffGreenGreenBBC(IEC2a)
OffGreenOffOffEBU(IEC2b)
OffGreenOffGreenDIN(IEC2b)
OffGreenGreenOffNORDIC(IEC2b)
MenuSubset=0/Rotary=C.AudioTestSignals
LED1LED2LED3LED4AudioTestSignals
OffOffOffOffOff
Off Off OffGreen1kHzonGroup1,Pair1only
Off Off GreenOffPair1=1kHzTone,Pair2=500HzTone
Pair3=1kHzBrokenTone,Pair4=500HzBrokenTone
Off Off GreenGreen1kHzToneonLeftforPair1,2,3&4
1kHzBrokenToneonRightforPair1,2,3&4
MenuSubset=0/Rotary=D.TestPattern
LED1LED2LED3LED4TestPattern
OffOffOffOff1.SMPTEHDBars
Off Off OffGreen2.Bars100/0/100/0
Off Off OffRed3.Bars100/0/75/0
Off Off OffOrange4.Bars75/0/75/0
Off Off Green Off5.Bars100%&Red
Off Off Green Green6.SMPTEEG1Bars
Off Off Green Red7.PathEqualizer&PLL
Off Off Green Orange8.Squareon4:3Mon.
Off Off Red Off9.Squareon16:9Mon.
Off Off Red Green10.5StepYStaircase
Off Off Red Red11.5StepUVStaircase
Off Off Red Orange12.YSweep
Off Off Orange Off13.UVSweep
Off Off Orange Green14.YMultiburst
Off Off Orange Red15.UVMultiburst
Off Off Orange Orange16.YRamp
Off Green Off Off17.UVRamp
Off Green Off Green18.Pluge
Off Green Off Red19.Convergence
Off Green Off Orange20.TartanBars
