DEC RRD42 Manuel utilisateur
DECpc
600-MBSCSICD–ROMDrive
InstallationGuide
Order Number: EK–XCRAA–IG. B03
Digital Equipment Corporation
Maynard, Massachusetts
First published, August 1992
Revised, August 1992, October 1992
The information in this document is subject to change without notice and should not be
construed as a commitment by Digital Equipment Corporation. Digital Equipment Corporation
assumes no responsibility for any errors that may appear in this document.
The software described in this document is furnished under a license and may be used or copied
only in accordance with the terms of such license.
No responsibility is assumed for the use or reliability of software on equipment that is not
supplied by Digital Equipment Corporation or its affiliated companies.
Restricted Rights: Use, duplication, or disclosure by the U.S. Government is subject to
restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer
Software clause at DFARS 252.227-7013.
The following are trademarks of Digital Equipment Corporation: Digital, DECdirect, DECpc,
ULTRIX, VMS, RRD42, and the Digital logo.
Adaptec ASW410, Adaptec ASW1210, and Adaptec ASW1410 are trademarks of Adaptec,
Incorporated. ASPI DOS Manager is a trademark of Atlanta Signal Processors, Incorporated.
Microsoft and MS–DOS are registered trademarks and Windows is a trademark of Microsoft
Corporation. OS/2 is a registered trademark of International Business Machines Corporation.
© Digital Equipment Corporation 1992.
All Rights Reserved.
Printed in U.S.A.
This document was prepared using VAX DOCUMENT, Version 2.1.
Contents
1 Introduction
2 Package Contents
3 Preinstallation
Determining Your Adapter Type ............................... 3–1
Removing the Mode Select Jumper . . ........................... 3–3
Setting the SCSI ID Jumpers ................................. 3–4
Attaching Mounting Brackets ................................. 3–6
4 Completing the Installation
Mounting the Drive ......................................... 4–1
Providing SCSI Bus Termination ............................... 4–1
Connecting the SCSI Cable ................................... 4–6
Connecting the Power Cable .................................. 4–7
5 Installing Device Drivers
Loading Device Driver Files ................................... 5–1
Editing the CONFIG.SYS File ................................. 5–2
Editing the STARTNET.BAT File ............................... 5–3
Editing the AUTOEXEC.BAT File . . . ........................... 5–4
iii
6 Using the RRD42 CD–ROM Drive
Controls and Indicators ...................................... 6–1
Inserting a Disk into the Drive ................................ 6–3
Manually Ejecting the Caddy . . ................................ 6–7
Caring for Your Drive and Disks ............................... 6–8
A Specifications
Examples
3–1 Adaptec Device Driver Display........................ 3–6
Figures
2–1 PCXCA–AA Kit Contents ............................ 2–2
3–1 SCSI Host Adapter Boards. . . ........................ 3–2
3–2 Mode Select Jumper ................................ 3–3
3–3 Setting the SCSI ID Jumpers ........................ 3–5
4–1 SCSI Terminator at the End of the SCSI Cable ........... 4–2
4–2 Connecting the SCSI Cable with the Termination
Connector ........................................ 4–3
4–3 Removing SCSI Termination Resistors from a Hard Drive. . 4–4
4–4 Removing SCSI Termination Resistors from the Adapter
Board . . ........................................ 4–5
4–5 Inverting the SCSI Connector by Folding the Cable ....... 4–6
4–6 Connecting the Power Cable . ........................ 4–7
6–1 Front Panel of the CD–ROM Drive .................... 6–1
6–2 Opening the Caddy ................................ 6–3
6–3 Inserting a Disk into the Caddy ....................... 6–4
6–4 Closing the Caddy . ................................ 6–5
6–5 Inserting the Caddy into the Drive .................... 6–6
6–6 Manually Ejecting the Caddy . ........................ 6–7
iv
Tables
3–1 SCSI Adapter Order Numbers ........................ 3–2
5–1 Copying Device Driver Files .......................... 5–1
5–2 Adding Lines to Your CONFIG.SYS File ................ 5–2
5–3 MSCDEX.EXE Software Switches . . ................... 5–5
6–1 Front Panel Controls and Indicators ................... 6–2
A–1 RRD42 CD–ROM Drive Specifications .................. A–1
v
1
Introduction
The RRD42 disk drive is a half-height, 5¼-inch, Compact Disk – Read-Only
Memory (CD–ROM) device. It connects to your personal computer (PC) with
the Small Computer System Interconnect (SCSI) bus.
You can use the drive to play audio CDs as well as to read computer data CDs.
To listen to audio CDs, use software such as the Media Player application
included with Microsoft Windows, Version 3.1.
The drive has the following features:
• 600-MB capacity
• Data transfer rate of 150 KB per second
• Burst rate of 1.5 MB per second
• Average seek time of less than 500 milliseconds
• Audio output jacks and a headphone jack
1–1
2
Package Contents
The CD–ROM drive kit (order number PCXCA–AA) contains the following
items (Figure 2–1):
• CD–ROM drive (order number RRD42–AA)
• Caddy for a compact disk (CD) (order number RRD4X–CA/CDA for a pack
of five caddies)
• SCSI bus termination connector
• Screws for mounting the CD–ROM drive
• Diskette(s) with device driver software
2–1
Package Contents
Figure 2–1 PCXCA–AA Kit Contents
LJ-0151-FH
CD-ROM Caddy
CD-ROM Drive
SCSI Bus
Termination
Connector
Screws
Device Driver
Software
2–2
