Dcybel Smart Manuel utilisateur
BLUETOOTH SPEAKER
ENCEINTE BLUETOOTH
BLUETOOTH-LUIDSPREKER
ALTAVOZ BLUETOOTH
MODEL/ MODÈLE/ MODEL/ MODELO :
Smart
INSTRUCTION MANUAL
NOTICE D’UTILISATION
GEBRUIKSAANWIJZING
MANUAL DE INSTRUCCIONES
Downloaded from www.vandenborre.be
WARNINGS
This appliance is intended for domestic household
use only and should not be used for any other
purpose or in any other application, such as for non
domestic use or in a commercial environment.
Ventilation
Allow at least a 10 cm gap all around the product.
The ventilation should not be impeded by covering
the ventilation openings with items, such as
newspapers, table-cloths, curtains, etc.
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
This apparatus is not suitable for use in a tropical
climate.
To protect the environment, use local recycling
facilities for battery disposal.
Batteries (battery pack or batteries installed) shall
not be exposed to excessive heat such as sunshine,
fire or the like.
IMPORTANT SAFETY INSTRUCTIONS
Keep the unit away from high temperature exposure
and high humidity.
En-1
Downloaded from www.vandenborre.be
Do not disassemble, modify or attempt to repair the
unit.
Symbol
This mark is applied to show the
equipment conforms to European
safety and electro-magnetic
compatibility standards.
Battery handling and usage
The product is supplied with one
rechargeable Lithium 3.7V
1050mAh battery incorporated in
the product which is not accessible
and cannot be replaced. Therefore
when the product reaches the end
of its useful life it must be disposed of at a recycling
centre.
En-2
Downloaded from www.vandenborre.be
PARTS
Top V iew
Rear View
1.
Play/Pause/Call button
2. AUX IN jack
3. DC 5V charging port
4.
Multifunction control
knob.
•Press and hold the knob
to turn on or off the
unit.
•Press and turn the knob
to the left or right to
decrease or increase the
volume.
•Turn the knob to the left
or right to select the
previous or next track.
Accessories
Micro USB cable 3.5 mm audio cable
When the USB cable is used as the disconnect
device, the disconnect device shall remain
EN-3
Downloaded from www.vandenborre.be
readily operable.
The marking plate is located at the bottom of the
apparatus.
CHARGING THE SPEAKER
The speaker has a built-in Lithium battery. It is
recommended to charge the internal battery for
about 3 hours before using the speaker.
The fully-charged battery can give up to 5-hour
playing time depending on genres of music and
volume.
1. Connect the small end of the supplied micro USB
cable into the charging port of the speaker.
Connect the other end of the cable into the USB
port on your computer.
zThe indicator light will illuminate red.
2.When the battery is fully charged, the red indicator
light will go out.
3.After charging, remove the micro USB cable.
Low battery warning: When you hear beeps, please
recharge the speaker.
PARING WITH A BLUETOOTH-
ENABLED DEVICE
1. Press and hold for about 3
seconds to turn on the speaker.
zThe speaker will enter Bluetooth mode and
EN-4
Downloaded from www.vandenborre.be
the indicator light will flash red and blue
alternatively.
zIf the speaker is not paired within 5 minutes,
it will automatically turn off.
2. To pair, go to Bluetooth settings on your
Bluetooth enabled device and connect to
“Smart”.
Mode Status
Bluetooth
pairing
The indicator light will flash
red and blue alternately.
Paired You will hear sound and the
indicator light will illuminate
blue.
NOTE:
Once the Bluetooth device is
connected for the first time,
the speaker will remember the
paired setting and will
automatically reconnect to the
same Bluetooth device the
next time they are in range.
LISTENING TO MUSIC
Once the speaker has been successfully paired to
your music device, you can listen to music by using
the button and control
knob.
Adjust the volume as desired by pressing and turning
the control knob to the left or right.
Select the desired track to play by turning the
EN-5
Downloaded from www.vandenborre.be
control knob to the left or right.
To pause, press . To resume play, press
again.
NOTE: When you want to playback from another
Bluetooth device, disconnect the speaker
from the Bluetooth device already in use.
HANDS-FREE FUNCTION
To receive an incoming call, press . During a
call, press again to hang up the call.
To reject an incoming call, press and hold
for about 2 seconds.
To redial the last number, press twice.
AUX IN
In Bluetooth mode, connect the supplied audio
cable from an auxiliary audio device to the AUX
IN jack of the unit.
The system will automatically exit the Bluetooth
mode and the indicator light will flash blue.
The volume can be adjusted by pressing and
turning the control knob
to the left or right. To pause,
press . To resume play, press
again.
Operate other functions on the external device as
usual.
EN-6
Downloaded from www.vandenborre.be
To enter Bluetooth mode again, disconnect the
audio cable from the unit.
CLEANING AND MAINTENANCE
Clean the unit with a slightly damp cloth and wipe it
with a dry cloth.
Never immerse it in water.
Do not use abrasive or chemical cleaning agents.
Store the unit in a cool, dry place, away from the
dust or dirt.
SPECIFICATIONS
Rechargeable battery: 3.7V 1050mAh
Power output (RMS): 3W x 2
Transmission distance: ≤10 m (It varies when
the environmental
factors and the
connected Bluetooth
devices are different)
DISPOSAL
As a responsible retailer we care about the
environment. As such we urge you to follow the
correct disposal procedure for the product,
packaging materials and if applicable, accessories
and batteries. This will help Conserve natural
resources and ensure that the materials are
EN-7
Downloaded from www.vandenborre.be
recycled in a manner that protects health and the
environment.
You must follow laws and regulations about
disposal. Waste electrical products and batteries
must be disposed of separately from household
waste when the product reaches the end of its life.
Contact the store where you bought the product
and your local authority to learn about disposal
and recycling.
The batteries must be disposed of at your local
recycling point.
We apologise for any inconvenience caused by
minor inconsistencies in these instructions, which
may occur as a result of product improvement and
development.
Darty Holdings SNC © Bondy 93140 France
15 / 04 / 2015
EN-8
Downloaded from www.vandenborre.be
AVERTISSEMENTS
Cet appareil est destiné à un usage domestique
uniquement. Toute utilisation autre que celle prévue
pour cet appareil, ou pour une autre application que
celle prévue, par exemple une application
commerciale, est interdite.
Aération
Prévoyez un espace libre d'au moins 10 cm tout
autour du produit.
Il convient que l’aération ne soit pas gênee par
l’obstruction des ouvertures d’aération par des objets
tels que journaux, nappes, rideaux, etc.
Il convient de ne pas placer sur l’appareil de sources
de flammes nues, telles que des bougies allumées.
Cet appareil n'est pas destiné à être utilisé sous un
climat tropical.
Déposez vos piles usagées auprès d'installation de
recyclage pour protéger notre environnement.
Les piles (piles installées) ne doivent pas être
exposées à une chaleur excessive telle que celle
du soleil, d'un feu ou d'origine similaire.
CONSIGNES DE SÉCURITÉ
IMPORTANTES
Maintenez l’appareil éloigné de toute exposition à
FR-1
