DBS HC-3208 Manuel utilisateur
Enter Setup
Exit Setup
Version change information
V2.0 2019-5-5
1. The User Manual only for 2D Barcode Scanner
2D Barcode Scanner
User Manual
Version：v2.0
Modification date：2019.5.11
Enter Setup
Exit Setup
1
Table of Contents
Chapter 1 Factory Defaults...................................................................................3
Restore All Factory Defaults.............................................................................3
Save as Custom Defaults................................................................................. 3
Restore All Custom Defaults............................................................................ 3
Chapter 2 Product Information.............................................................................4
Chapter 3Communication Interface.................................................................... 5
USB-KBW............................................................................................................ 5
USB-COM............................................................................................................5
TTL/RS232.......................................................................................................6-8
Chapter 4 Scan Mode............................................................................................9
1. Manual Reading Mode............................................................................9-12
2. Continuous Mode...................................................................................13-17
3. Automatic mode..................................................................................... 18-22
Chapter 5 Illumination and Aiming................................................................. 23
1. Illumination....................................................................................................23
2. Aiming............................................................................................................ 23
Chapter 6 Output Remind...................................................................................24
1. Indicator...................................................................................................24-25
2. Read Beep.................................................................................................... 26
（1）All Indicator......................................................................................26-27
（2）Successful sound remind............................................................. 27-28
（3）Beep Frequency...................................................................................28
（4）Good Read Beep time.................................................................. 29-30
3. Decoding status Remind............................................................................ 30
4.Keyboard Language............................................................................... 30-34
5. Set virtual keyboard.................................................................................... 35
6.CapsLock................................................................................................. 35-36
7. Data encoding format............................................................................36-37
8. VAT invoice automatic identification output function........................37-38
9. Image Flipping..............................................................................................38
Chapter 7 Data editing........................................................................................ 39
1. Data editing Enable/Disable...................................................................... 39
2. Symbol name display..................................................................................39
3. Symbol length display........................................................................... 39-40
4. CODE ID................................................................................................. 40-41
5. Terminal Character................................................................................ 41-42
6. Prefix/suffix setting................................................................................ 42-43
Enter Setup
Exit Setup
2
Chapter 8 Symbologies edding and enable/disable configuration.............. 44
Enable All Symbologies............................................................................ 44
Enable 1D symbologies................................................................................ 44
Enable 2D symbologies................................................................................ 44
EAN-8...........................................................................................................45-47
EAN-13.........................................................................................................47-50
UPC-E.......................................................................................................... 51-54
UPC-A.......................................................................................................... 54-56
CODE 128......................................................................................................... 57
GS1-128............................................................................................................ 58
AIM-128............................................................................................................. 59
ISBT-128............................................................................................................60
Interleaved 2 of 5........................................................................................61-62
China Post 2 of 5........................................................................................63-64
Matrix 2 of 5.................................................................................................65-66
Industrial 2 of 5........................................................................................... 67-68
IATA 2 of 5................................................................................................... 69-70
ITF-14.................................................................................................................71
DP-12................................................................................................................. 72
DP14.................................................................................................................. 73
MSI................................................................................................................74-75
Code11......................................................................................................... 76-77
Code 39....................................................................................................... 77-79
Code 32............................................................................................................. 79
Code 93............................................................................................................. 80
Codabar....................................................................................................... 81-83
PLESSEY.................................................................................................... 84-85
RSS-14.........................................................................................................85-86
RSS-Limited................................................................................................ 86-87
PDF-417.......................................................................................................87-88
QR Code...................................................................................................... 89-90
Data Matrix.................................................................................................. 91-92
Aztec code.........................................................................................................93
Maxi code.......................................................................................................... 94
Appendix 1：Set Digital Code.................................................................... 95
Appendix 2：ASCII Table...................................................................... 96-97
ASCII Table 3 Defaults Table...................................................................... 98
Enter Setup
Exit Setup
3
Chapter 1: Factory Defaults
Scan“Restore All Factory Defaults”Code ，Restores all Settings to factory default ，
Setup code include“ * ”is the factory default setting.
Restore All Factory Defaults
Users can set it according to the corresponding requirements，then scan and save the
current default as the custom defaults.
Save as Custom Defaults
Scan“Custom Defaults”code，can Restore All Custom Defaults.
Restore All Custom Defaults
Enter Setup
Exit Setup
4
Chapter 2: Product Information
Query Firmware Version
Query Manufacturer Information
Query Model Number
Query products Serial Number
Query Production Batch
Query Production date
Enter Setup
Exit Setup
5
Chapter 3: Communication Interface
When connect USB，scan“USB-KBW”code to configure for standard keyboard output
* USB-KBW
When connect USB，scan“USB-COM”code to configure for virtual serial output
USB-COM
When connect Serial Line，scan“TTL/RS232”code to configure for serial output,Serial
port related default configuration is：9600bps，8bits，No parity bit，1 stop bit.
TTL/RS 232
Enter Setup
Exit Setup
6
TTL232/RS232
1200 bps
2400 bps
4800 bps
* 9600bps
19200 bps
38400 bps
Enter Setup
Exit Setup
7
57600 bps
115200 bps
7-N-1
7-N-2
* 8-N-1
7-E-1
7-E-2
Enter Setup
Exit Setup
8
8-E-1
7-O-1
7-O-2
8-O-1
