Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
2
Limited Warranty
The warranty policy applies to those cases where the new seller vehicle unloaded from its shipping container,
set up and delivered by authorized dealer and under normal use and service is found to have defects in parts
or workmanship under the following terms and conditions. This warranty covers the engine and engine
related components for a period of 180 days.
This warranty does not apply to any parts that in the seller’s opinion were defective because of improper
maintenance, improper assembly, alterations, abuse, negligence or accidents.
Should warranty service be required on your vehicle during the 180-day warranty period, please contact your
nearest authorized DAZON dealer for repairs.
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
3
What is not covered under this warranty?
This warranty does not cover any seller vehicles that have been subjected to:
a. Renting;
b. Disassembly, adjusting or repairing of the vehicle in any way so as to adversely affect its safety or
reliability;
c. Competition or racing.
The warranty does not cover any losses of the seller vehicle use, any losses of time, any inconveniences, or
any other consequential damages which include, but are not limited to the losses or damages to any persons,
property or expenses of returning damaged units to the vehicle distributor or any DAZON authorized
dealers.
DAZON has the right to make changes without prior notice.
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
4
Contents
1. Foreword----------------------------------------------------------------------------------------------------------------5
2. A Few Words about Safety-------------------------------------------------------------------------------------------6
3. Important Safety Information----------------------------------------------------------------------------------------8
4. Safety Labels----------------------------------------------------------------------------------------------------------12
5. Are You Ready to Drive?--------------------------------------------------------------------------- ----------------13
6. Is Your Vehicle Ready to Drive?-----------------------------------------------------------------------------------17
7. Safe Driving Precautions---------------------------------------------------------------------------------------------21
8. Operation-------------------------------------------------------------------------------------------------- ------------24
9. Service Instructions---------------------------------------------------------------------------------------------------39
10. Repairs----------------------------------------------------------------------------------------------------------------47
11. Periodical Checks and Services------------------------------------------------------------------------------------48
12 Specifications---------------------------------------------------------------------------------------------------------49
13 Wiring Diagram ------------------------------------------------------------------------------------------------------54
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
5
FOREWORD
Thank you for choosing our double/single-seat Raider Max 175 which is approved by EEC for on-road
use. We hope you will have fun with it. Before starting operate this vehicle, please read through this Owner's
Manual carefully as it contains important safety and maintenance information. Failure to follow the warnings
contained in this manual can result in serious injuries.
Be sure to follow the recommended maintenance schedule and service your vehicle accordingly. Preventive
maintenance is extremely important to the longevity of your EEC-approved Raider Max 175.
Beginners should drive this vehicle in a large open area to practice handling it. Wear protective gears all the
time when driving or riding this vehicle.
We hope you will have a pleasant experience with our products and thanks again for choosing DAZON
EEC-approved Raider Max 175.
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
6
A FEW WORDS ABOUT SAFETY
In order to keep everyone safe, you must take responsibility for the safe operation of your EEC-approved
Raider Max 175. To help you make informed decisions about safety, we have provided operating
procedures and other information on labels in this manual. This information alerts you to potential hazards
that could hurt you or others.
It is not practical or possible to warn you against all hazards associated with operating or maintaining your
EEC-approved Raider Max 175, so you must use your own good judgments.
You will find important safety information in a variety of forms, including:
!Safety Labels ------on the vehicle;
!Safety Messages ------ preceded by a safety alert symbol and one of the two signal
words “WARNING” or “CAUTION”;
!The meaning of these signal words:
WARNING ------Physical harm may result from the failure to follow the instructions that are described
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
7
within the labels;
CAUTION------ Damages to your vehicle and possible subsequent personal injuries or death could result
from the failure to take proper precautions described within the labels;
!Safety Headings------such as Important Safety Reminders or Important Safety Precautions;
!Safety Sections------such as EEC-approved Raider Max 175 Safety;
!Instructions------about how to use this vehicle correctly and safely.
The whole manual is filled with important safety information, so please read it carefully.
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
8
IMPORTANT SAFETY INFORMATION
Your EEC-approved Raider Max 175 will provide you with many years of service and pleasure, providing
you take responsibility for your own safety and understand the challenges you will meet while driving.
There is much that you can do to protect yourself when driving your vehicle. You'll find many helpful
recommendations throughout this manual. The following are a few of the most important ones.
Follow the Age Recommendation
It is strongly recommended that no one under age of 16 be permitted to drive this EEC-approved Raider
Max 175 without adult supervision.
Always Wear a Helmet
Facts have proven that helmets can significantly reduce the quantity and severity of head injuries, so when
you drive your EEC-approved Raider Max 175, please always wear an approved motorcycle helmet. We
also recommend that you wear approved goggles, sturdy boots, durable gloves and other protective gear.
Take Time to Learn & Practice
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
9
Even if you have driven other buggies, you still should take time to become familiar with how this vehicle
works. Practice in a safe area until you have built your skills and gotten accustomed to this vehicle’s size and
weight.
Because many accidents have involved inexperienced or untrained drivers, we urge all drivers to take a
training course approved by the Buggy Safety Institute. Check with your dealer for more information on the
training course.
Be Alert to Hazards
The terrain can present a variety of challenges when you drive. Continually "read" the terrain for unexpected
turns, drop-offs, rocks, ruts and any other hazards. Always keep your speed low enough to allow time for
seeing and reacting to hazards.
Drive within Your Limits
Pushing limits is another major cause of EEC-approved Raider Max 175 accidents. Never drive beyond
your personal abilities or faster than conditions warrant. Remember that alcohol, drugs, fatigue and
inattention can significantly reduce your ability to make good judgments and to drive safely.
Raider Max 175 (single-seat & double-seat): Owner’s Manual EEC Version:1.0 Sep. 2004
10
Don't Drink and Drive
Alcohol and drive never mix. Even one drink can reduce your ability of responding to changing conditions,
and every additional drink can lengthen and worsen your reaction time. So don't drink and drive, and don't
let your friends drink and drive either.
Never Drive Indoors
The exhaust from the engine contains a tasteless, odorless but poisonous gas called carbon monoxide. For
the health of your family, please don’t drive your EEC-approved Raider Max 175 in your lovely house.
Keep away from Moving Parts
You should never place your hands or any other parts of your body near any moving parts of your vehicle.
Failure to adhere to this warning will cause physical harm to your body.
Avoid Skidding or Sliding
The terrain surface can be a major factor affecting turns. Skidding or sliding a turn is more likely to occur on
slippery surfaces such as snow, ice, mud and loose gravel. If you skid or slide on ice, you may lose all
directional controls. To avoid skidding or sliding on slippery terrain surfaces, you should keep your speed
low and drive carefully.
