DayTronic 4000 Series Manuel utilisateur

MODEL

4040

SINGLE-CHANNEL

FREQUENCY INPUT

INSTRUMENT

SB.2

4000

Instrument Series

INSTRUCTION MANUAL

No part of this document may be reprinted, reproduced, or used in any form or by

any electronic, mechanical, or other means, including photocopying and recording,

or in any information storage and retrieval system, without permission in writing

from Daytronic Corporation. All specifications are subject to change without notice.

MODEL

4040

SINGLE-CHANNEL

FREQUENCY INPUT INSTRUMENT

INSTRUCTION MANUAL

Model 4040 Instruction Manual, v. SB.2

Pub. No. 4040M.2, Issued 10/96

Part No. 91631

Daytronic Corporation

Dayton, OH

www.daytronic.com

1. Introduction

a. Description and Specifications ............................................. 1.1

b. Physical Layout .................................................................... 1.6

c. Panel Mounting .................................................................... 1.8

d. Standard Channel Configuration ..........................................1.9

e. Standard Logic Configuration .............................................1.10

f. Using the Front-Panel Setup Buttons .................................1.12

g. Low Battery Warning .......................................................... 1.18

2. Setup

a. Transducer Cabling ............................................................. 2.1

b. Powerup .............................................................................. 2.5

c. Adjusting LCD Viewing Angle .............................................. 2.7

d. Selecting a Channel for Display .......................................... 2.8

e. Channel Calibration ............................................................. 2.9

f. Setting Channel Filter ........................................................ 2.11

g. Scaling the Bargraph Display ............................................ 2.12

h. Defining Limit Zones .......................................................... 2.14

i. Logic I/O Connections ....................................................... 2.15

j. Analog Output Connections .............................................. 2.17

3. Operation: Use of Front-Panel Buttons ................................ 3.1

Appendix A: Complete Standard Configuration ......................... A.1

Appendix B: 4040/Computer RS-232-C Connections ............... B.1

Appendix C: Legend and Indicator Annunciation ...................... C.1

Appendix D: Setting Input Range and Sensitivity ...................... D.1

Appendix E: Setting Analog Filter Response ............................. E.1

Appendix F: "Absolute" and "Computed" Calibration .................. F.1

Appendix G: Changing the Battery ............................................ G.1

Contents

Section Page

1.a Model 4040 Description and Specifications

1.1

A to D

Conversion

Real-Time

Math

Processing

Signal

Conditioning

Communi-

cations &

Memory

Process

Control

Displays &

Buttons

Transducer

Input(s)

General 4040 Features

•+ – x ÷ √

•Digital Max/Min

•Constants

•Limits (7 zones,

including "Safety"; can

be used to generate

logic control outputs or

to trigger predefined

command sequences

automatically)

•Tare offset

•Scalable 51-segment

bargraph with end-

point indication

•Backlit 0.6-inch LCD

with adjustable viewing

angle and limit-

triggered flashing

•Independently settable

dual-limit displays

•RS-232-C I/O

•Port for optional

keyboard

•Simple step-through

configuration setup

and review via front

panel

•Battery-backed data

and configuration

storage

•Scalable 10-V analog

output for strip-chart

recording, etc.

•8 TTL-level logic I/O's

for annunciation,

process control, and

automatic command

execution

•16-bit (±32000 count)

•optional internal

linearization (up to 15

variable-length

segments)

•Excitation

•"y = mx + b" scaling

•Analog and digital

filtering

The Model 4040 is a single-channel conditioner for measurement of

flow, rpm

, and other phenomena that can be sensed by pulse trans-

former transducers with two-wire isolated windings (tachometer

pickups, turbine flowmeters, etc.), transistor or logic-circuit drivers,

"zero-velocity" (true digital output) sensors, and similar frequency-

generating transducers. A "tare" function is preprogrammed for the

frequency input, and may be activated by a front-panel push button.

Via front-panel buttons, you can also display and reset MAXIMUM,

MINIMUM, and "MAX minus MIN" values for the "tared" analog input.

Unless otherwise specified at the time of order, your Model 4040 has

been set, prior to shipment, to a

standard configuration

. THIS CON-

FIGURATION IS FULLY ADEQUATE FOR MOST APPLICATIONS,

AND LETS YOU CONTROL BASIC INSTRUMENT SETUP AND

OPERATION SOLELY BY MEANS OF THE SIX FRONT-PANEL PUSH

BUTTONS AND THE EIGHT REAR-PANEL LOGIC I/O. A full listing of

your 4040's standard configuration is given in Appendix A.

Like all 4000 Series instruments, however, the 4040 can be rapidly and

easily reprogrammed in the field, to provide a variety of unique

application solutions. For such reprogramming you can use either

• an optional Model 10P80D Extended Keyboard that plugs directly

into the rear of the 4040 unit, or

• the optional StartPAC 100 Software (Model GS-SP100).* This

software applies to ALL Daytronic RS-485 networkable instru-

ments, and offers a number of valuable utilities for terminal

emulation, node configuration, network monitoring, data display

and logging, etc. IT IS SUPPLIED FREE OF CHARGE WITH ALL

4000 SERIES MODELS. For details on the installation and

operation of StartPAC 100, see the

StartPAC 100 Instruction

Manual

StartPAC 100 lets a connected computer serve as a "dumb" terminal

for entry of the specific MNEMONIC COMMANDS required to repro-

gram the 4040. These commands may also be issued directly to the

4040 via the optional Extended Keyboard. Commands which are

common to all 4000 Series models are described in detail in the

1.2

Model 4040 Description and Specifications 1.a

* Alternatively, you can use any of a number of commercially available

terminal emulation programs

to issue commands directly to the 4040.

optional 4000 Series

System Instruction Manual

. IT IS RECOM-

MENDED THAT YOU STUDY THE

SYSTEM INSTRUCTION

MANUAL

BEFORE YOU ATTEMPT ANY RECONFIGURATION OF

YOUR MODEL 4040 BEYOND THAT DISCUSSED IN THE

APPENDICES OF THE PRESENT MANUAL.

See Appendix B of the present manual for direct RS-232-C connections

between the 4040 and a computer or printer.

The 4040's "live" input is initially configured for a full-scale transducer

range of

32000 Hz

and an input sensitivity range of

100 mV to 15 V.

you require a different transducer-range or sensitivity-range setting for

your 4040, see Appendix D. INPUT AND SENSITIVITY RANGES

SHOULD BE SET

BEFORE TRANSDUCERS ARE CONNECTED.

Note too that the active low-pass filter for the 4040's "live" analog input

is initially set for the response characteristics given as "3" under

Specifications, below. To change this response, see Appendix E.

Unless otherwise specified, every 4040 comes with the standard

engineering-unit legends

and

button-function indicators

shown in Fig. 1.

Different legend/indicator films may be optionally obtained. Via optional

keyboard or computer, you can instruct the 4040 to light any one or a

combination of given legends and indicators. See Appendix C for

"Legend and Indicator Annunciation." Note that under the "standard

configuration," the "F2" indicator will

always

be on when the 4040 is in

"RUN-TIME" mode.

When using the 4040 to measure

frequency itself

, you can apply a

simple "ABSOLUTE" CALIBRATION technique via the SCALING

FACTOR (EMM) command. The procedure is given in Appendix F,

which also describes an alternative "COMPUTED" CALIBRATION

method using the FREQUENCY CALIBRATION (FRQ) command.

NOTE: WITH THE EXCEPTION OF APPENDICES C THROUGH F,

THE PRESENT MANUAL WILL ONLY TREAT PROCEDURES AND

CONSIDERATIONS WHICH ARE RELEVANT TO THE 4040 "STAN-

DARD CONFIGURATION" AND WHICH DO NOT REQUIRE A

CONNECTED COMPUTER OR KEYBOARD. FOR INFORMATION

ON THE FULL FUNCTIONALITY OF YOUR MODEL 4040, SEE THE

OPTIONAL

SYSTEM INSTRUCTION MANUAL

1.a Model 4040 Description and Specifications

1.3

MODEL 4040 SPECIFICATIONS (for general 4000 Series Physical,

Electrical, and Environmental specifications—including Logic

I/O—see Appendix A of the 4000 Series

System Instruction

Manual)

Input:

Type: Any AC or unipolar pulse signal, grounded or floating,

irrespective of waveform

Threshold Level: Selectable via SENSITIVITY (SEN) command to

accommodate signals from 100 mV to 100 V. NOTE: The sensiti-

vity range of 100 mV to 15 V is "standard"; if another sensitivity

range is required, see Appendix D.

Frequency Range: From 10% to 100% of 250, 500, 1000, 2000,

4000, 8000, 16000, or 32000 Hz, selectable via RANGE (RNG)

command. NOTE: The 32000-Hz range is "standard"; if another

input range is required, see Appendix D.

Excitation (for "Zero-Velocity" sensors): Nominal 10 (i.e., ±5) V-DC;

±50 mA, maximum

Measurement Characteristics:

Normal-Mode Range: ±100 V operating; ±200 V without instrument

damage

Common-Mode Range: ±100 V operating and without instrument

damage

Common-Mode Rejection Ratio: at 60 Hz: -120 dB; at 1 kHz: -60

Input Impedance: Differential: 400 kilohms; Common-Mode: 100

kilohms

Offset: Initial: ±0.05% of full scale; vs. temperature: ±25 ppm/°C; vs.

time: ±20 ppm/month

Gain Accuracy: ±0.02% of full scale

Gain Stability: vs. temperature: ±40 ppm/°C; vs. time: ±20

ppm/month

Filter: 5-pole modified Butterworth, with characteristics selectable as

"1," "2," or "3," as follows:

1.4

Model 4040 Description and Specifications 1.a

Number Filter Characteristics

1•3 dB down at 10 Hz; 60 dB down at 75 Hz

•Step Response Settling Time (Full-Scale Output):

To 1% of final value: 40 ms

To 0.1% of final value: 90 ms

To 0.02% of final value: 150 ms

•Ripple and Noise: Readings are within the stated

accuracy from 30% to 100% of the frequency

range in use

2•3 dB down at 5 Hz; 60 dB down at 35 Hz

•Step Response Settling Time (Full-Scale Output):

To 1% of final value: 65 ms

To 0.1% of final value: 135 ms

To 0.02% of final value: 220 ms

•Ripple and Noise: Readings are within the stated

accuracy from 15% to 100% of the frequency

range in use

3•3 dB down at 2.5 Hz; 60 dB down at 20 Hz

•Step Response Settling Time (Full-Scale Output):

To 1% of final value: 150 ms

To 0.1% of final value: 350 ms

To 0.02% of final value: 450 ms

•Ripple and Noise: Readings are within the stated

accuracy from 10% to 100% of the frequency

range in use

NOTE: The filter characteristics given as "3" are "standard"; if another

set of characteristics is required, see Appendix E.

Analog Output: ±10 V, microprocessor driven and scaled, ±1 mV

resolution

Accuracy: 0.05% of current voltage reading ± 2 mV

Output Bandwidth: 40 Hz max

1.a Model 4040 Description and Specifications

1.5

Autres manuels pour 4000 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels DayTronic Contrôleurs

DayTronic

DayTronic 3700 Series Manuel utilisateur

DayTronic

DayTronic 3700 Series Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
