DaytonAudio Reference Series Manuel utilisateur

Passive Reference 8" Mini Subwoofer Kit

Thank you for purchasing the Passive Dayton Audio Reference 8" mini subwoofer kit. The

enclosure for this speaker kit was precision cut using CNC machinery for a tight fit to

make it easy to finish. With a little time and patience, your finished product will provide

years of enjoyment. Please follow these instructions for the best possible results.

Suggested tools and consumables:

Drill Rag or paper towels

Screwdriver Solder

Wood clamps (you can never have too many of these) Wire stripper/crimper

Sanding block and/or electric finishing sander #8 Wood Screws

Wood glue Polyurethane glue (Gorilla Glue)

Package contents:

First, empty the contents of the package and review parts to ensure everything has been

included and is in good condition. If any parts are missing or damaged, please contact our

customer service department at 1-800-338-0531.

Driver:

A) Dayton Audio RSS210HO-4 8" Reference Series HO Subwoofer 4 Ohm

Enclosure Components:

B) Baffle

C) 2 x Side Panel

D) Back Panel

E) 2 x Top/Bottom Panel

F) Brace

Enclosure Assembly:

1) First, before gluing anything, do a dry fit of the enclosure to familiarize yourself

with the parts and assembly. This will also give you a chance to ensure that all pieces have

been cut properly.

2) Next, set the enclosure parts out on a flat level surface and ensure that all pieces are

free of dust and debris.

3) Start with the Back Panel (B) lying flat with the rabbeted side up, as shown.

4) Apply a small bead of glue to the inside of all joining surfaces of the Back Panel (B) and

one Top/Bottom panel (E). Then set in place applying enough pressure to ensure glue is spread

through each joint (some glue squeeze-out can be expected).

5) Apply a small bead of glue to the inside of all joining surfaces of one Side Panel (F) and

the back and top/bottom panel assembly. Then set in place applying enough pressure to ensure

glue is spread through each joint (some glue squeeze-out can be expected).

6) Apply a small bead of glue to the inside of all joining surfaces of the Brace (E) and the

back, top/bottom, and side panel assembly. Then slide in place applying enough pressure to

ensure glue is spread through each joint (some glue squeeze-out can be expected).

7) Apply a small bead of glue to the inside of all joining surfaces of the other Side Panel (F)

and the enclosure assembly. Then set in place applying enough pressure to ensure glue is spread

through each joint (some glue squeeze-out can be expected).

8) Apply a small bead of glue to the inside of all joining surfaces of the other Top/Bottom

Panel (E) and the enclosure assembly. Then set in place applying enough pressure to ensure glue

is spread through each joint (some glue squeeze-out can be expected).

9) Apply a small bead of glue to the inside of all joining surfaces of the Baffle (E) and the

enclosure assembly. Then set in place applying enough pressure to ensure glue is spread through

each joint (some glue squeeze-out can be expected).

10) Make sure that all edges are flush and securely apply clamps from side to side, top to

bottom, and front to back. Apply ample pressure to ensure glue is spread evenly through each

joint (some glue squeeze-out can be expected). Visually inspect all seams to make sure they are

all closed tightly, you may need to relocate clamps (or add more clamps) to get a perfect fit. In

most cases only 6 clamps will be needed for an enclosure this size.

11) Wipe away any glue squeeze-out on the outside of the enclosure with a damp rag or paper

towel (excess glue on the inside is fine). Allow to dry according to the glue manufacturer's

recommendations and remove clamps.

12) Finally, fill any open seams with wood filler or a mixture of sawdust and wood glue.

Then sand all surfaces and seams until smooth. Finish enclosure to your liking. See our web page

for ideas and examples.

Final Assembly:

13) Locate and install your preferred power terminals (Spring terminals, binding posts,

speakON connector, etc…) and internal wiring.

14) Connect the speaker wires to the appropriate terminals on the Dayton Audio

RSS210HO-4 8" Reference Series HO Subwoofer (A).

15) Carefully set the driver into the cutout and secure using the fastener of your choice.

You are now ready to enjoy your finished Passive Reference 8" Mini Subwoofer!
