F3300C.DV2
Owner’s Manual
1
Getting Started
Important Safety Instructions 2
Grounding Instructions 3
Description of the Vacuum 4
Assembling the Vacuum 5
Positioning the Power Cord 6
Operation
Turning the Vacuum On/Off 7
Edge Cleaning 7
Automatic Carpet Height Adjustment 7
Maintenance and Care
Replacing the Vacuum Bag 8
Removing/Reinstalling the Bottom Plate 9
Replacing the Belt 10
Resetting the Circuit Breaker 11
Replace the Headlight Bulb 12
Problem Solving Guide
Troubleshooting 13
Contact Your Local Retailer 13
Key Replacement Parts 13
For Best Performance 13
Warranty 14
CONTENTS
2
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions
should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS
APPLIANCE. FOR HOUSEHOLD USE ONLY.
IMPORTANT:
The manufacturer cannot accept responsibility for damage
caused when the appliance is not used according to the instructions, or for uses other
than those for which it was intended.
WARNING:
To reduce the risk of fire, electric shock, damage or injury:
• Do not leave appliance when plugged
in. Unplug from outlet when not in use
and before servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close
attention is necessary when used by or
near children.
• Use only as described in this manual.
• Do not use with damaged cord or plug.
If appliance is not working as it should,
has been dropped, damaged, left
outdoors, or dropped into water, return
it to your Authorized DAVID Vacuum
Retailer for service.
• Do not pull or carry by cord, use cord
as a handle, close a door on the cord, or
pull cord around sharp edges or corners.
Do not run appliance over cord. Keep
cord away from heated surfaces.
• Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with
wet hands.
• Do not put any object into openings.
Do not use with any opening blocked;
keep free of dust, lint, hair and anything
that may reduce air flow.
• Keep hair, loose clothing, fingers and all
parts of body away from openings and
moving parts.
• Do not pick up anything that is burning
or smoking, such as cigarettes, matches or
hot ashes.
• Do not use without vacuum bag in place.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or
combustible liquids such as gasoline
or use in areas where they may be present.
• Do not attempt to service the unit while
appliance is plugged in.
SAVE THESE INSTRUCTIONS
3
GROUNDING INSTRUCTIONS
Commercial Model
This vacuum cleaner must be grounded. If it should malfunction or break down,
grounding provides a path of least resistance for electric current to reduce the risk
of electric shock. This vacuum cleaner is equipped with a cord having an equipment-
grounding conductor and grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
This vacuum cleaner is for use on a nominal 120-volt circuit and has a ground plug
(see illustration). Make sure that the vacuum is connected to an outlet having the
same configuration as the plug. No adapter should be used with this vacuum.
WARNING – Improper connection of the equipment-grounding conductor can result
in the risk of electric shock. Check with a qualified electrician or service person if you
are in doubt as to whether the outlet is properly grounded. Do not modify the plug
provided with the vacuum – if it will not fit the outlet, have a proper outlet installed
by a qualified electrician.
Grounded Outlet
Grounding
Grounded Outlet
Box
4
1 Cloth Bag
2 Vacuum Nozzle
3 Headlight
4 Furniture Guard
5 Power Cord
6 Handle
1
2
3
456
DESCRIPTION OF THE VACUUM
5
Attaching the Handle to the
Vacuum
NOTE: Do not plug in the vacuum until
it is completely assembled.
The vacuum cleaner handle is packed
as a separate component that requires
assembly.
• Release the handle bracket from the
handle tube by removing the two
screws (Fig. 1).
• Place handle onto the handle tube,
aligning holes with pegs (Fig. 2).
• Place the handle bracket back into
position (Fig. 3).
• Secure with two screws removed in
step 1.
Fig. 1
Fig. 2
Fig. 3
ASSEMBLING THE VACUUM
6
ASSEMBLING THE VACUUM
Positioning the Power Cord
• Loosen, but do not remove, the screw
holding the upper cord hook (Fig. 1).
• Position the cord between the cord
hook and the vacuum tube (Fig. 2).
Re-tighten the screw.
• Once the cord is secured by the cord hook,
proceed with wrapping the cord.
• Wrap the cord clockwise around the
top and bottom cord hooks. Fasten
the plug to the wrapped cord using the
channel on the plug. When not in use,
store the vacuum indoors in a clean,
dry area where it cannot be damaged
or cause injury.
Fig. 1
Fig. 2
7
Turning the Vacuum On/Off
The switch is located on the back of the
nozzle to the left of the handle tube (Fig. 1).
Press the switch with your foot to turn
the vacuum On or Off.
The vacuum should be turned Off
before returning handle to full upright
position. Always turn the vacuum cleaner
Off before unplugging it from the
electrical outlet.
Edge Cleaning
The edge cleaning feature provides
improved cleaning near walls and
stationary furniture. For maximum edge
cleaning, place the left side of the nozzle
against the wall or stationary furniture.
Automatic Carpet Height
Adjustment
Your vacuum is designed with an automatic,
self-adjusting nozzle. No manual adjustments
are required. The height of the nozzle is
instantly and automatically adjusted to
the flooring surface. This self-adjusting
feature allows the nozzle to float evenly
over all flooring surfaces.
OPERATION
Fig. 1
8
MAINTENANCE AND CARE
Replacing the Vacuum Bag
NOTE: Unplug the vacuum cleaner from
the electrical outlet before changing the bag.
• Unzip the outer cloth bag (Fig. 1).
• Remove the used bag by pressing the
bag holder tab and pulling the bag off
the vacuum (Fig. 2). Discard the used bag.
• To install a new bag, position the
bottom of the bag collar into the bag
collar holder (Fig. 3).
• Push the top of the bag collar inward
until the collar “snaps” into place under
the bag holder tab.
• Zip the outer cloth bag closed.
Fig. 1
Fig. 2
Fig. 3
