SPL-5 MKII

Audio Limiter

Sound level logger

Manual

SPL-5 MK2_205201_V1.0UK

Due to the nature of this product and it's desi ned functionalities it is considered to be used and

installed solely by professional and certified installers and is not intended for consumer usa e or

resale. Consumer use is not supported by the manufacturer.

SPL-5 MK2_205201_V1.0UK

UK DATEQ SPL5 MK2 Manual Safety instructions 5

Safety instructions

1. All safety instructions, warnin s and operatin instructions must be read first.

2. All warnin s on the equipment must be heeded.

3. The operatin instructions must be followed.

4. Keep the operatin instructions for future reference.

5. The equipment may never be used in the immediate vicinity of water; make sure that water and

damp cannot et into the equipment.

6. The equipment may only be installed or fitted in accordance with the manufacturers

recommendations.

7. The equipment must be installed or fitted such that ood ventilation is not obstructed in any

way.

8. The equipment may never be installed in the immediate vicinity of sources of heat, such as

parts of heatin units, boilers, and other equipment that enerates heat (includin amplifiers).

9. Connect the equipment to a power supply of the correct volta e, usin only the cables

recommended by the manufacturer, as specified in the operatin instructions and/or shown on

the connection side of the equipment.

10.The equipment may only be connected to a le ally approved earthed mains power supply.

11.The power cable or power cord must be positioned such that it cannot be walked on in normal

use, and objects that mi ht dama e the cable or cord cannot be placed on it or a ainst it.

Special attention must be paid to the point at which the cable is attached to the equipment and

where the cable is connected to the power supply.

12.Ensure that forei n objects and liquids cannot et into the equipment.

13.The equipment must be cleaned usin the method recommended by the manufacturer.

14.If the equipment is not bein used for a prolon ed period, the power cable or power cord

should be disconnected from the power supply.

15.In all cases where there is a risk, followin an incident, that the equipment could be unsafe,

such as:

●if the power cable or power cord has been dama ed

●if forei n objects or liquids (includin water) have entered the equipment

●if the equipment has suffered a fall or the casin has been dama ed

if a chan e in the performance of the equipment is noticed

Appropriately qualified technical staff must check it.

16.The user may not carry out any work on the equipment other than that specified in the

operatin instructions.

Product support

For questions about the SPL series limiters, accessories or other products contact Dateq at:

Dateq Audio Technologies B.V.

De Paal 37 Phone: (036) 54 72 222

1351 JG Almere E-mail: [email protected]l

The Netherlands Internet: www.dateq.nl

ndex

Safety instructions..............................................5

Introduction........................................................7

Installation..........................................................8

Connections...................................................9

Audio inputs............................................12

Audio outputs..........................................12

External attenuator..................................12

Si nalin .................................................13

Operation.........................................................14

Technical specifications...................................16

Inputs...........................................................16

Outputs........................................................16

Common......................................................16

Audio.......................................................16

Limiter.....................................................16

Memory...................................................16

External connections...............................16

Dimensions and wei ht...........................16

Introduction confi uration.................................20

Installation........................................................21

Confi uration...............................................21

Confi uration license........................................22

Unlockin the limiter....................................22

Live..............................................................23

Limiter confi uration....................................24

Mode.......................................................24

Limiter settin s........................................24

Certification date.....................................24

Microphone settin s................................24

Timeslots.....................................................25

Bypass calender..........................................25

Display.........................................................26

Firmware update..........................................27

Settin s........................................................28

Network settin s..........................................28

Device..........................................................28

History..............................................................29

Product support................................................32

UK DATEQ SPL-5 MK2 Manual Introduction 7

ntroduction

The SPL-5 MK2 is a sound level limiter that records the sound pressure levels for at least 180

day's. Other events like power cycle, tamper detections or overload on sound level are also

recorded.

Usin the SPL-5 MK2 confi uration software the unit can be confi ured and sound sample data

can be read. On release of the SPL-5 MK2 the confi uration software is supported by windows 7

and hi her. In normal use the SPL-5 MK2 connected to the software is read only. Users can read

all settin s and decibel lo in . To chan e any settin the installer license in combination with the

installer password is required.

To connect to the SPL-5 MK2 a windows-computer with USB support is needed. When the SPL-5

MK2 is connected to a local area network or an internet connection, the software allows to connect

remotely.

The limiter uses an external measurement microphone to determine the current sound level. When

the sound level exceeds the maximum allowed level the limiter will reduce the output level to

ensure the sound level stays within it's limits.

Usin the time and bypass calendar the SPL-5 MK2 can adjust the maximum allowed sound level

automatically durin the day, week and year.

When connected, the special SRL-1 sta e relay an external warnin li ht can be connected and if

needed the power of for example a DJ booth monitor can be cut. This way the sound level is

secured without any compromises to the quality of sound.

8Installation DATEQ SPL-5 MK2 manual UK

nstallation

The limiter is installed in between the audio source (a mixin desk for example) and the speaker

amplifier.

When calibratin the system, the power amplifier has to be set to maximum output level. The

limiter will reduce the si nal as much as needed. When used at nominal level the established

sound pressure limit will not be exceeded after confi urin the limiter. However if in any case this

should happen, e. . When the mixer is used above the nominal level, the limiter will automatically

adjust the si nal to ensure the sound pressure level remains below the maximum allowed level.

Image 1: Connecting the SPL-5 MK2

UK DATEQ SPL-5 MK2 manual Installation 9

Connections

To prevent modification of the connections after calibration and sealin , the connectors of the

limiter are inaccessible after sealin of the cover plates at the front. To access the connector

board, remove the ri ht cover plate at the front panel.

Unfasten screw (A) with a torx-screwdriver (see illustration). Now remove the 4 torx-screws (B)

from the top lid. The top cover can be removed now. Gently lift the front side a little, and slowly

shift the top lid to the rear. The connector board will become visible.

The SPL-5 MK2 is equipped with balanced in- and outputs ensurin premium sound quality over

lon er distance. After installin the limiter the cover plate can be replaced, locked and sealed,

ensurin no chan es to the installation can be made. If for some reason the seal is broken, the

cover and the cover is removed, the limiter will store this action into it's memory and optionally lock

the audio path. This sanction can only be reset usin the reset key.

10 Installation DATEQ SPL-5 MK2 manual UK

Microphone input; XLR 3-pin female

Pin Function Description

1 Ground Audio round

2 Audio + Power and audio

3 Audio - Power and audio

Table 1: microphone input connections

Audio inputs left and ri ht; XLR 3-pin female

P1n Function Description

1 Ground Audio round

2 Audio + Audio in phase +

3 Audio - Audio out phase -

Table 2: Audio-input connections

Audio output left and ri ht; XLR 3-pin male

Pin Function Description

1 Ground Audio round

2 Audio + Audio phase +

3 Audio - Audio phase -

Table 3: audio-output connections

USB port; USB-B female

Pin Function Description

1 VCC + Power

2 Data – Data

3 Data + Data

4 GND Ground

Table 4: USB connections

Network port; RJ45 female

Pin Function Description

1 TX-D + Data

2 TX-D – Data

3 RX-D + Data

4 Not connected

5 Not connected

6 RX-D – Data

7 Not connected

8 Not connected

Table 5: Network connections
