Datapath VisionRGB-E2S Manuel utilisateur

Datapath Limited claims copyright on this

documentation. No part of this documentation may be

reproduced, released, disclosed, stored in any electronic

format, or used in whole or in part for any purpose other

than stated herein without the express permission of

Datapath Limited.

Whilst every eort is made to ensure that the

information contained in this documentation is correct,

Datapath Limited make no representations or warranties

with respect to the contents thereof, and do not accept

liability for any errors or omissions.

Datapath reserves the right to change specication

without prior notice and cannot assume responsibility for

the use made of the information supplied.

Datapath Limited acknowledges all registered

trademarks used within this documentation.

Dual Channel Capture Card

VisionRGB-E2S

UK Headquarters

Datapath Ltd.,

Bemrose House, Bemrose Park,

Wayzgoose Drive,

Derby,

DE21 6XQ,

United Kingdom

Tel: +44 (0) 1332 294441

Fax: +44 (0) 1332 290667

US Oce

Datapath North America

2550 Blvd of the Generals

Suite 30

Norristown, PA 19403

USA

Tel: +1 484 679 1553

Email: [email protected]

Web: www.datapath.co.uk

Product VisionRGB-E2S Quick Start Guide

Classication Released

Version Number V2.0.0

Your packing box should contain the following items

The VisionRGB-E2S dual channel capture card.

2 x DVI-VGA, 1 x DVI/Component and 1 x DVI/HDMI

Adapters.

(For latest drivers go to www.datapath.co.uk).

NOTE:

All plug-in cards are static sensitive and are packed in

antistatic materials. Please keep the card in its

packaging until you are ready to install.

You are likely to need a at blade and a Phillips head

screwdriver for the installation of the VisionRGB-E2S card;

it would be useful to have these to hand before you begin.

Power down the PC (including peripherals), switch o at

the mains and disconnect all the cables connected to the

computer, noting the positions for accurate reconnection

Remove the PC cover.

Locate a vacant PCIe slot (x4 or higher) on the motherboard

and remove the backing plate (retain all screws).

If in doubt consult your motherboard documentation to

correctly identify a PCIe (PCI Express) slot.

Remove theVisionRGB-E2S card from its packaging and

secure it rmly into the empty PCIe slot.

Reconnect all cables to the PC then connect the cable

distributing the RGB or DVI signals to the connectors on the

VisionRGB-E2S card located on the back panel.

Power up the PC and commence the software installation.

Screw the VisionRGB-E2S bracket to the back panel of the

PC and replace the cover.

Connect the cable(s) distributing the RGB or DVI signals to

the connectors on the VisionRGB-E2S card located on the

back panel. Reconnect all cables to the PC.

PACKING LIST HARDWARE INSTALLATION SOFTWARE INSTALLATION

Download the the required driver install.exe from the

Support pages on the Datapath website and follow the

Installation Wizard instructions as prompted.

We suggest that you regularly visit the Datapath web site

for information on updated drivers.

www.datapath.co.uk

It is strongly recommended that you read the detailed

help instructions on completion of the installation. Each

help topic may be printed for ease of use.
