Datapath IQS4 Manuel utilisateur
Engineering the world’s best visual solutions
User Guide
4K Quad Splitter
CONTENTS
FCC COMPLIANCE IQS4 3
DECLARATION OF CONFORMITY 4
INTRODUCTION 5
Specication 5
IQS4 4K Quad Splitter 5
UNPACKING 6
INSTALLATION 7
System Requirements 7
Mounting Options 7
Procedure and Connections 8
Front LED 9
DISPLAY DRIVER CONFIGURATION TOOL (DDCT) 10
DATAPATH LIMITED 12
Technical Support 12
Copyright Statement 13
INDEX 14
2
IQS4 4K Quad Splitter User Guide
FCC COMPLIANCE IQS4
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
commercial, industrial or business environment. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the manufacturer’s instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures.
Re-orient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to an outlet on a circuit dierent from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Reprinted from the Code of Federal Regulations #47, part 15.193.1993. Washington
DC: Oce of the Federal Register, National Archives and Records Administration,
US Government Printing Oce.
Warning! Any changes or modications to this product not
expressly approved by the manufacturer could void any
assurances of safety or performance and could result in
violation of Part 15 of the FCC Rules.
3
IQS4 4K Quad Splitter User Guide
DECLARATION OF CONFORMITY
Per FCC Part 15.107 and 15.109 Class A
Responsible Party Name: Datapath Limited
Address: Bemrose Park, Wayzgoose Drive, Derby
Phone: +44 (0) 1332 294 441
Hereby declares the product: IQS4
Product Name: Quad output splitter
Model Number: IQS4 (DGC222)
Conforms to the following specications:
FCC Part 15.107 and 15.109 Class A Digital Device
Supplementary Information:
This device has been shown to be in compliance with and was tested in accordance with the measurement
procedures specied in the Standards & Specications listed above and as indicated in the measurement
report number: TRA-051311-44-01A.
Representative Persons Name: Tony Jones, Operations Director.
4
IQS4 4K Quad Splitter User Guide
INTRODUCTION
The IQS4 is Datapath’s 4K splitter solution engineered specically for large, multi-output
video wall applications. Paired with Datapath’s Image4K graphics cards, the IQS4 delivers a
cost-eective solution for powering video walls of up to 96 HD screens.
Specication:
IQS4 4K Quad Splitter
The IQS4 takes one single 4K output from an Image2K/ Image4K and splits it into four HD outputs.
Using IQS4 units reduces the overall number of graphics cards needed in the video wall controller, which
streamlines the system, reducing load and optimizing capacity.
Works with Datapath Image4K and Image2K graphics cards with no conguration needed.
Splitting and placement of ‘quadrants’is easy with the graphical setup wizard.
Works with the output of an Image4K or Image2K graphics card with support for HDCP 2.2.
Splits and routes the input signal to all four outputs with a maximum delay of a single line.
Multiple mounting options:
5U that will support up to 10 IQS4 units with RPSU.
1U rack mount kit to house two IQS4 units with RPSU.
VESA compliant for mounting a single IQS4 unit behind a screen.
Standalone - Place on any at surface.
Distribute video in 4K and split local to screens to reduce long distance cabling requirements.
Video output connections 4 x HDMI 1.4 (1920 x 1080@60Hz)
Video input connections 1 x HDMI 2.0 (7680 x 1080@60Hz)
Power requirements 12 Watts
Operating temperature 0°C to 35°C / 32°F to 96°F
Storage temperature -20°C to 70°C / -4°F to 158°F
Relative humidity 5% to 90% non-condensing
Size 205mm (l) x 161mm (w) x 31mm (h)
Warranty 3 years (Optional 5 years)
5
IQS4 4K Quad Splitter User Guide
UNPACKING
Your packing box contains the following items:
Your IQS4 4K Quad Splitter.
Power Supply Unit.
5x HDMI Locks.
4x M4 35mm screws.
Note: All electronic products are static sensitive and packed in antistatic
materials. Please keep the IQS4 in its packaging until you are ready to install.
It is recommended that you do not discard the packing box until you are
completely satised with the IQS4 Quad Splitter and it is fully installed and
working correctly. We also recommend that you make note of the serial
number of the device. This should hasten any query, should you need to
contact our Technical Support Department. The serial number is displayed on
the bottom of the splitter.
6
IQS4 4K Quad Splitter User Guide
INSTALLATION
This section deals with the installation of the splitters working in conjunction with the
graphics cards to spread the Windows desktop across all the screens.
System Requirements
An Image2K/Image4K graphics card from Datapath.
Mounting Options
The IQS4 features multiple mounting options:
1Using VESA mount behind the screens.
Each IQS4 has a VESA mount which enables the unit to be xed to the rear of a display.
3Stand alone.
The IQS4 can also be installed standalone on any at surface.
2
Using additional rack mount.
An additional kit allows the splitter to be rack mounted in conjunction with the video wall
controller and any other equipment.
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
inthe
UK
Each VESA mounted IQS drives four HD screens
Input from a
Datapath
Image2K or
Image4K
Power is
required for
each IQS4 unit
Rack mount kits house two IQS4 units
in 1U or up to 10 IQS4 units in 5U
Power is required for each rack mount
kit (dual connections for redundancy) Input from a Datapath
Image2K or Image4K
Each IQS4 drives four HD screens
7
IQS4 4K Quad Splitter User Guide
3
2
1
Procedure and Connections
Note: Always use Premium Certied HDMI cables, capable of 4K @60 resolution, see www.HDMI.org
1
Connect the output of the graphics card to the input socket on the rear of the IQS4 using
an HDMI cable. Ensure the cable is secured into the IQS4 input connector. If possible, use
the supplied cable lock.
2Connect the outputs on the IQS4 to the displays. Ensure the cables are secured.
3Connect power supply and switch on.
4Right click on the desktop and select the Display Driver Conguration Tool (DDCT) from
the menu.
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
in the
UK
Power
Link
Video
Power
O/On
12V DC
4 3 2 1 USB
HDMI Input
HDMI Outputs
Power
Made
in the
UK
12V DC
4 3 2 1 USBHDMI InputHDMI Outputs
Power
Made
in the
UK
12V DC
4 3 2 1
USBHDMI Input
HDMI Outputs
Power
Made
in the
UK
8
IQS4 4K Quad Splitter User Guide
2 1 3
4
Front LED
The IQS4 includes three front panel LEDs for device status INFO
1POWER – RED for power connected / GREEN for device ON.
2LINK – ON when an input is detected.
3VIDEO – ON when video is being output.
Power
Link
Video
Power
O/On
Power
Link
Video
Power
O/On
9
IQS4 4K Quad Splitter User Guide
1
2
3
When enabled, each output of the graphics card added to the wall are allocated as four quadrants per output.
Four HD quadrants allocated for each output of the graphics card.
Labelled A to D (e.g. 3:B is the second quadrant of output 3 on the graphics card).
Note: It is not necessary to use all four available quadrants on each output.
DISPLAY DRIVER
CONFIGURATION TOOL (DDCT)
The conguration and setup of the IQS4 is done
through the Display Driver Conguration Tool
(DDCT), the same tool is used for the design,
conguration and creation of the video wall.
To access the DDCT right click on your desktop, select
Display Driver Conguration then select the Set Up
Wizard.
Note: The complete guide for this tool can be found
on the Image2K/Image4K user guide and in the
application help le.
A new ‘Use Split Outputs’ toggle option is available
from driver v6.0 when using Image2K/Image4K.
10
IQS4 4K Quad Splitter User Guide
