Datalogic DS6500 Series Manuel

DS6500

INSTALLATION QUICK REFERENCE

CONTENTS

DS6500-100-010 MASTER/SLAVE MODEL ...........................................................................................................1

DS6500-100-011 PROFIBUS MODEL.....................................................................................................................8

DS6500-100-012 ETHERNET MODEL ..................................................................................................................13

DS6500-100-015 DEVICENET MODEL.................................................................................................................18

DS6500-105-0XX OSCILLATING MIRROR MODEL.............................................................................................23

COMMON FEATURES ..........................................................................................................................................25

NOTE

For further details on product installation, see the complete Reference Manual available on the

configuration CD-ROM included with this product.

DS6500 MASTER/SLAVE MODEL

DS6500-100-010 MASTER/SLAVE MODEL

Figure A

Laser Beam Output Window

Figure B

Programming Keypad

Phase On LED (Yellow)

TX Data LED (Green)

Power On LED (Red)

LCD Display

Figure C

Main/Aux. Interface 25-pin D-sub Male Connector

Lonworks 9-pin Male Connector

Lonworks 9-pin Female Connector

5 12

Available Models:

Optical Model

0 = Standard

5 = Oscillating Mirror

Decoder Model

10 = Master/Slave

11 = Profibus

12 = Ethernet

15 = Devicenet

DS6500 - X0X - 0YY

Focalization

1 = Medium Version

2 = Long Version

Technical Features:

ELECTRICAL FEATURES OPTICAL FEATURES

Supply Voltage 15 - 30 Vdc Light Receiver Avalanche photodiode

Wavelength 630 to 680 nm

Power

Consumption

15 W typical

20 W Max. (including startup current)

Main (isolated) Baud Rate

Safety Class Class 2-EN 60825-1;

Class II-CDRH

RS232

RS485 full-duplex

Laser Control Security system to turn laser

off in case of motor slow down

RS485 half-duplex

1200 to 115200

READING FEATURES

20 mA C.L. (INT-30

with C-BOX 100 only) 19200 Scan Rate 600-1200 scans/s

Auxiliary

RS232 1200 to 115200

Other

Communication

Interfaces

Lonworks 1,25 Mb/s

Inputs

Max. Resolution

Max. Read. Distance

Max. Read. Width

Max. Depth of Field

(see reading diagram)

USER INTERFACE

Ext. Trigger 1,

3 aux. digital

inputs

(opt coupled NPN or PNP)

LCD Display 2 lines by 16 characters LCD

Outputs Keypad 3 keys

LED Indicators

3 software

programmable

digital outputs (optocoupled)

Power ON (red color)

Phase ON (yellow color)

TX Data (green color)

DS6500 MASTER/SLAVE MODEL

SOFTWARE FEATURES ENVIRONMENTAL FEATURES

Interleaved 2/5

Readable Codes

Code 39 standard

Operating

Temperature 0° to +40 °C (+32 to +104 °F)

Codabar

Code 128

Storage

Temperature -20° to +70 °C (-4° to +158 °F)

EAN 128 Humidity 90% non condensing

Code 93 (Standard & Full ASCII) Ambient Light

EAN/UPC (including Add-on 2 Immunity 3500 lux

And Add-on 5) Vibration Resistance 14 mm @ 2 to 10 Hz

Code Selection IEC 68-2-6 test FC 1.5 mm @ 13 to 55 Hz

Up to 10 codes during one

reading phase 2 hours on each axis 2 g @ 70 to 200 Hz

Headers and Shock Resistance

Terminators

Up to 128-byte headers and

128-byte terminators IEC 68-2-27 test EA

On Line, Automatic, Test, 3 shocks on each axis

30 g; 11 ms

Operating Modes

PackTrack™ Protection Class IP64

Config. Mode Genius™ utility program PHYSICAL FEATURES

Std Models Oscill. Mirror

Dimensions mm

(inch)

110x113x99

(4.33x4.45x3.9)

113x180x104.5

(4.45x7.08x4.11)

Parameter Storage Non-volatile internal FLASH

Weight 1.5 kg (3.3 lb) 2.0 kg (4.4 lb)

Accessories:

Name Description Part Number

CAB-6001 Cable to C-BOX100 1 m 93A051190

CAB-6002 Cable to C-BOX100 2 m 93A051200

CAB-6005 Cable to C-BOX100 5 m 93A051210

CAB-6010 Cable to C-BOX100 10 m 93A051271

CAB-6101 Cable master/slave 1 m 93A051220

CAB-6102 Cable master/slave 2 m 93A051230

CAB-6105 Cable master/slave 5 m 93A051240

CAB-6112 Cable master/slave no power 2 m 93A051224

CAB-6115 Cable master/slave no power 5 m 93A051225

CAB-6305 Power cable Fam 6k 5 m 93ACC1768

CAB-6310 Power cable Fam 6k 10 m 93ACC1752

C-BOX 100 Passive connection box 93ACC1510

INT-30 20 mA C.L. interface board for C-BOX 100 93A151022

GFC-60 90° mirror 93A201100

GFC-600 90° mirror close distance 93A201102

PWR-120 Power unit 110/230 V AC - 24 V DC 93ACC1530

BTK-6000 Terminator kit (5 pcs) 93ACC1710

PG6002 Single unit power supply – US 93ACC1718

PG6001 Single unit power supply – UK 93ACC1719

PG6000 Single unit power supply – EU 93ACC1720

FBK-6000 Fast bracket kit (2 pcs) 93ACC1721

US-60 Mounting bracket kit (5 pcs) for multisided stations 890001020

MEP-542 Photocell kit – PNP 93ACC1727

MEP-543 Photocell kit – NPN 93ACC1728

OEK-2 Optical encoder (10 m cable + spring) 93ACC1770

OEK-1 Optical encoder kit + 10 m cable 93ACC1600

Electrical Connections:

The DS6500 reader provides a 25-pin male D-sub connector for connection to power supply, Host interface (Main

and Aux), and input/output signals.

Two 9-pin connectors provide access to the scanner’s local Lonworks network used for both input and output

connections to build a multi-sided or omni-station system.

DS6500 MASTER/SLAVE MODEL

The details of the connector pins are indicated in the following table:

25-pin D-Sub Connector Pinout

Pin Name Function

Chassis - internally connected to GND

1 CHASSIS Cable shield connected to chassis

20 RXAUX Receive data of auxiliary RS232 (referred to GND)

21 TXAUX Transmit data of auxiliary RS232 (referred to GND)

8 OUT 1+ Configurable digital output 1 – positive pin

22 OUT 1- Configurable digital output 1 – negative pin

11 OUT 2+ Configurable digital output 2 – positive pin

12 OUT 2- Configurable digital output 2 – negative pin

16 OUT 3A Configurable digital output 3 – polarity insensitive

17 OUT 3B Configurable digital output 3 – polarity insensitive

18 EXT_TRIG/PS A External trigger (polarity insensitive) for PS

19 EXT_TRIG/PS B External trigger (polarity insensitive) for PS

6 IN2/ENC A Input signal 2 (polarity insensitive) for Encoder

10 IN2/ENC B Input signal 2 (polarity insensitive) for Encoder

14 IN3A Input signal 3 (polarity insensitive)

15 IN4A Input signal 4 (polarity insensitive)

24 IN_REF Common reference of IN3 and IN4 (polarity insensitive)

9, 13 VS Supply voltage – positive pin

23, 25 GND Supply voltage – negative pin

25-pin male D-sub Connector

Pin RS232 RS485 Full-Duplex RS485 Half-Duplex 20 mA C.L.

(INT-30 with C-BOX 100 only)

2 TX TX485+ RTX485+

3 RX RX485+

4 RTS TX485- RTX485- see INT-30 instructions

5 CTS RX485-

7 GND_ISO GND_ISO GND_ISO

* For 20 mA C.L. connections, GND is the same of the scanner power supply.

9-pin Lonworks Connector Pinout

Pin Name Function

Cable shield internally connected

1 CHASSIS by capacitor to chassis

9 VS Supply voltage – positive pin

2 GND Supply voltage – negative pin

6 VS_I/O Supply voltage of I/O circuit

3 Ref_I/O Reference voltage of I/O circuit

4 SYS_ENC_I/O System signal

5 SYS_I/O System signal

7 LON A Lonworks line (polarity insensitive)

8 LON B Lonworks line (polarity insensitive)

Female

Male

9-pin Local Lonworks Connectors

Network Termination:

When building a local Lonworks system the network must be properly terminated by positioning a BTK-6000

terminator on the DS6500 master reader (BTK-6000 female side) and on the last slave reader (BTK-6000 male

side).

to Master

9-pin female

to Slave

9-pin male

BTK-6000 Network Terminator

DS6500 MASTER/SLAVE MODEL

Connectivity:

Point-to-Point Layout

DS6500

CAB-600X C-BOX 100

Local Host

*P.S.

PG6000

* P.S. (Presence Sensor) connected to External Trigger/PS input.

Pass Through Layout

ENT

*P.S.

Gryphon

DS4600A

DS6500

CAB-600X

C-BOX 100 C-BOX 100

C-BOX 100

MAIN

*P.S.

2 2

Local Host

PWR-120

1 2

Main Serial Interface

uxiliary Serial Interface

* P.S. (Presence Sensor) connected to External Trigger/PS input.

DS6500 MASTER/SLAVE MODEL

Multiplexer Layout

ENT

*P.S.

DS4600A

DS6500 PWR-120

CAB-600X

C-BOX 100 C-BOX 100

C-BOX 100 MX4000

#0 1

#31 #1

Local Host

1 RS485 HD Main Interface

* P.S. (Presence Sensor) connected to External Trigger/PS input.

RS232 Master/Slave Layout

ENT

DS6500

Master CAB-600X C-BOX 100

DS4600A

Slave 1

*P.S. Local Host

C-BOX 100

DS4600A

Slave 2 PWR-120

C-BOX 100

1 2

Main Serial Interface

uxiliary Serial Interface

* P.S. (Presence Sensor) connected to External Trigger/PS input.

DS6500 MASTER/SLAVE MODEL

Local Lonworks Network

CAB-60XX

CAB-610X

BTK-6000 C-BOX 100**

Master

Encoder***

BTK-6000 Slave 1

*P.S.

Local Host

CAB-63XX

PWR-120

Small Synchronized Network with 2 Readers

* P.S. (Presence Sensor) connected to External Trigger/PS input.

** C-BOX 100 modified to accept scanner power.

*** Encoder connected to IN2/ENC input.

Local Lonworks Network

Slave 2 Slave 1 Master

C-BOX 100**

BTK-6000

CAB-610X

CAB-600X

*P.S.

CAB-610X Encoder***

Host

CAB-610X

CAB-63XX

BTK-6000

Slave 4 Slave 3

Slave 5

PWR-240

CAB-63XX

Small Synchornized Network with more than 2 Readers and Single Power Unit

* P.S. (Presence Sensor) connected to External Trigger/PS input.

** C-BOX 100 modified to accept scanner power.

*** Encoder connected to IN2/ENC input.

DS6500 MASTER/SLAVE MODEL

Large Synchronized Network

* P.S. (Presence Sensor) connected to External Trigger/PS input.

** Encoder connected to IN2/ENC input.

Large Synchronized Network with DX6X00 and DS6XXX Scanners

DS6500 PROFIBUS MODEL

DS6500-100-011 PROFIBUS MODEL

Figure A

Laser Beam Output Window

Figure B

Programming Keypad

Phase On LED (Yellow)

TX Data LED (Green)

Power On LED (Red)

LCD Display

Figure C

Profibus 9-pin Female Connector (white)

Lonworks 9-pin Female Connector

Main/Aux. Interface 26-pin D-Sub Male Connector

Available Models:

Optical Model

0 = Standard

5 = Oscillating Mirror

Decoder Model

10 = Master/Slave

11 = Profibus

12 = Ethernet

15 = Devicenet

DS6500 - X0X - 0YY

Focalization

1 = Medium Version

2 = Long Version

Technical Features:

ELECTRICAL FEATURES OPTICAL FEATURES

Supply Voltage 15 - 30 Vdc Light Receiver Avalanche photodiode

Wavelength 630 to 680 nm

Power

Consumption

15 W typical

20 W Max. (including startup current)

Main (isolated) Baud Rate

Safety Class Class 2-EN 60825-1;

Class II-CDRH

RS232 Laser Control Security system to turn laser

RS485 full-duplex off in case of motor slow down

RS485 half-duplex

1200 to 115200

READING FEATURES

20 mA C.L. (INT-30

with C-BOX 100 only) 19200 Scan Rate 600-1200 scans/s

Auxiliary

RS232 1200 to 115200

Other

Lonworks 1,25 Mb/s

Communication

Interfaces

Profibus 12 Mb/s

Inputs

Max. Resolution

Max. Read. Distance

Max. Read. Width

Max. Depth of Field

(see reading diagram)

USER INTERFACE

Ext. Trigger 1,

3 aux. digital

inputs

(optocoupled NPN or PNP)

LCD Display 2 lines by 16 characters LCD

Outputs Keypad 3 keys

LED Indicators

3 software

programmable

digital outputs (optocoupled)

Power ON (red color)

Phase ON (yellow color)

TX Data (green color)

Autres manuels pour DS6500 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Datalogic Lecteur de codes-barres

Datalogic

Datalogic QuickScan QBT2430 Manuel utilisateur

Datalogic

Datalogic Gryphon GM44 Series Manuel utilisateur

Datalogic

Datalogic DRAGONM131 Manuel utilisateur

Datalogic

Datalogic Magellan 9300i Manuel utilisateur

Datalogic

Datalogic QuickScan QS2500 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon I GD4132 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon GFS4100 Manuel d'installation et d'exploitation

Datalogic

Datalogic Magellan 1100i Manuel utilisateur

Datalogic

Datalogic QuickScan QS2500 Manuel utilisateur

Datalogic

Datalogic MAGELLAN 1400I Manuel utilisateur

Datalogic

Datalogic Gryphon I GD4100 Manuel d'installation et d'exploitation

Datalogic

Datalogic DS5100-X200 Manuel utilisateur

Datalogic

Datalogic Heron D150 Manuel utilisateur

Datalogic

Datalogic QuickScan QM2430 Manuel utilisateur

Datalogic

Datalogic QuickScan QD2590 Manuel d'installation et d'exploitation

Datalogic

Datalogic QuickScan QD2430 Manuel utilisateur

Datalogic

Datalogic QuickScan BC2030 Manuel utilisateur

Datalogic

Datalogic Touch TD1100 Family Manuel utilisateur

Datalogic

Datalogic Gryphon I GFE4500 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon I GM4100 guide Manuel utilisateur

Datalogic

Datalogic POWERSCAN PBT7100 guide Manuel utilisateur

Datalogic

Datalogic MAGELLAN 1000I Manuel d'installation et d'exploitation

Datalogic

Datalogic QuickScan QD24 series Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon I GBT4400 Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur

Atid

Atid AT188N Plus Manuel utilisateur
