Data Video BC-200T Manuel utilisateur

BC-200T

4K HDBaseT BLOCK

CAMERA

Instruction Manual

Table of Contents

FCC COMPLIANCE STATEMENT...................................... 4

WARNINGS AND PRECAUTIONS .................................... 4

WARRANTY................................................................... 6

STANDARD WARRANTY ......................................................6

THREE YEAR WARRANTY.....................................................6

DISPOSAL ...................................................................... 7

1. INTRODUCTION......................................................... 8

FEATURES ........................................................................8

2. SYSTEM DIAGRAM .................................................. 10

3. CONNECTIONS......................................................... 11

CAMERA FRONT VIEW......................................................11

CAMERA REAR PANEL ......................................................12

RECEIVER BOX FRONT PANEL.............................................15

RECEIVER BOX REAR PANEL...............................................16

4. IR REMOTE CONTROL .............................................. 17

5. OSD MENU OPTIONS............................................... 22

6. DIP SWITCH SETTINGS ............................................. 30

7. DVIP CONFIGURATION TOOL................................... 31

DVIP CONFIGURATION TOOL SETTING ................................31

User Interface.........................................................31

Device Search .........................................................32

Clearing Device List ................................................33

Detailed Device Network Information....................34

Modify Device Information and Write to Device....34

Switch to Other Network Interface ........................35

Language Selection ................................................36

8. RMC-180 CAMERA CONTROL UNIT.......................... 37

DIRECT CONNECTION TO CAMERA ......................................37

CONNECTION TO CAMERA VIA HBT-11 ...............................38

9. FIRMWARE UPGRADE ............................................. 39

10. DIMENSIONS ......................................................... 40

11. SPECIFICATIONS .................................................... 42

SERVICE AND SUPPORT ............................................... 44

Disclaimer of Product & Services

The information offered in this instruction manual is intended as a guide only. At all

times, Datavideo Technologies will try to give correct, complete and suitable

information. However, Datavideo Technologies cannot exclude that some information in

this manual, from time to time, may not be correct or may be incomplete. This manual

may contain typing errors, omissions or incorrect information. Datavideo Technologies

always recommend that you double check the information in this document for

accuracy before making any purchase decision or using the product. Datavideo

Technologies is not responsible for any omissions or errors, or for any subsequent loss

or damage caused by using the information contained within this manual. Further

advice on the content of this manual or on the product can be obtained by contacting

your local Datavideo Office or dealer.

FCC Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject

to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including

interference that may cause undesired operation.

Warnings and Precautions

1. Read all of these warnings and save them for later

reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use

liquid or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit

may fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are

provided for ventilation. To ensure safe and reliable operation of

this unit, and to protect it from overheating, do not block or cover

these openings. Do not place this unit on a bed, sofa, rug, or similar

surface, as the ventilation openings on the bottom of the cabinet

will be blocked. This unit should never be placed near or over a

heat register or radiator. This unit should not be placed in a built-in

installation unless proper ventilation is provided.

7. This product should only be operated from the type of power

source indicated on the marking label of the AC adapter. If you are

not sure of the type of power available, consult your Datavideo

dealer or your local power company.

8. Do not allow anything to rest on the power cord. Do not locate this

unit where the power cord will be walked on, rolled over, or

otherwise stressed.

9. If an extension cord must be used with this unit, make sure that the

total of the ampere ratings on the products plugged into the

extension cord do not exceed the extension cord rating.

10. Make sure that the total amperes of all the units that are plugged

into a single wall outlet do not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet

ventilation slots, as they may touch dangerous voltage points or

short out parts that could result in risk of fire or electric shock.

Never spill liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not

attempt to service this product yourself. Opening or removing

covers that are marked “Do Not Remove” may expose you to

dangerous voltage points or other risks, and will void your

warranty. Refer all service issues to qualified service personnel.

13. Unplug this product from the wall outlet and refer to qualified

service personnel under the following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;

d. When the product does not operate normally under normal

operating conditions. Adjust only those controls that are covered

by the operating instructions in this manual; improper

adjustment of other controls may result in damage to the unit

and may often require extensive work by a qualified technician

to restore the unit to normal operation;

e. When the product has been dropped or the cabinet has been

damaged;

f. When the product exhibits a distinct change in performance,

indicating a need for service.

Warranty

Standard Warranty

•Datavideo equipment are guaranteed against any manufacturing

defects for one year from the date of purchase.

•The original purchase invoice or other documentary evidence should

be supplied at the time of any request for repair under warranty.

•The product warranty period begins on the purchase date. If the

purchase date is unknown, the product warranty period begins on

the thirtieth day after shipment from a Datavideo office.

•Damage caused by accident, misuse, unauthorized repairs, sand, grit

or water is not covered under warranty.

•Viruses and malware infections on the computer systems are not

covered under warranty.

•Any errors that are caused by unauthorized third-party software

installations, which are not required by our computer systems, are

not covered under warranty.

•All mail or transportation costs including insurance are at the

expense of the owner.

•All other claims of any nature are not covered.

•All accessories including headphones, cables, and batteries are not

covered under warranty.

•Warranty only valid in the country or region of purchase.

•Your statutory rights are not affected.

Three Year Warranty

•All Datavideo products purchased after July 1st,

2017 are qualified for a free two years extension

to the standard warranty, providing the product

is registered with Datavideo within 30 days of

purchase.

•Certain parts with limited lifetime expectancy such as LCD panels,

DVD drives, Hard Drive, Solid State Drive, SD Card, USB Thumb Drive,

Lighting, Camera module, PCIe Card are covered for 1 year.

•The three-year warranty must be registered on Datavideo's official

website or with your local Datavideo office or one of its authorized

distributors within 30 days of purchase.

Disposal

For EU Customers only - WEEE Marking

This symbol on the product or on its packaging

indicates that this product must not be disposed of

with your other household waste. Instead, it is your

responsibility to dispose of your waste equipment

by handing it over to a designated collection point

for the recycling of waste electrical and electronic

equipment. The separate collection and recycling of your waste

equipment at the time of disposal will help to conserve natural

resources and ensure that it is recycled in a manner that protects

human health and the environment. For more information about where

you can drop off your waste equipment for recycling, please contact

your local city office, your household waste disposal service or the shop

where you purchased the product.

CE Marking is the symbol as shown on the left of

this page. The letters "CE" are the abbreviation of

French phrase "Conformité Européene" which

literally means "European Conformity". The term

initially used was "EC Mark" and it was officially

replaced by "CE Marking" in the Directive 93/68/EEC in 1993. "CE

Marking" is now used in all EU official documents.

1. Introduction

The BC-200T Block Camera is a 4K (3840x2160, UHD) camera with an

infra-red remote control. It can be used for UHD high quality shooting

in an environment where space is limited. The BC-200T equips the

HDBaseT technology to achieve long-distance ultra-high video/audio,

power, control, and Ethernet signals transmission over a single Ethernet

cable. The video resolutions supported are 2160p29.97 and 2160p25.

The BC-200T provides 12x optical focus and one HDMI video output

interface. A tally light indicator sits above the BC-200T camera lens. The

BC-200T also provides an HDBaseT receiver box, HBT-11, for users to

control the BC-200T remotely with one Ethernet cable only.

The BC-200T supports SONY VISCA control protocol so that the camera

can be controlled via RS-422 or DVIP interface.

Features

•Lens: 1/2.3” type Exmor R CMOS

•12x optical zoom, f = 3.9 mm (Wide) to 46.8 mm (Tele), F1.8 to

F2.0

•Supported 4K formats: (3,840 x 2,160, UHD)

2160p/29.97, 2160p/25

•Supported HD formats:

1080p59.94/50, 1080i59.94/50, 720p59.94/50

•Video Output: HDMI 1.4 x 1

•Digital Noise Reduction (DNR) to reduce the noise and enable

clearer image under low light condition.

•Tally LED Design (RS-422/ DVIP Operation)

•Supports SONY VISCA Protocol

•Supports DVIP and RS-422 Control Protocol

•Supports HDBaseT

•Users can save up to 10 preset camera settings for future use.

•Users can control up to 28 BC-200T devices simultaneously via the

RMC-180 PTZ camera remote control unit (including White

Balance, Focus, Iris, Shutter Speed, Zoom, Zoom Speed, Save

Preset, Recall Preset)

P.S. Shutter speed function must be set by the RMC-180 menu.

2. System Diagram

Table des matières

Autres manuels Data Video Caméra de sécurité

Data Video

Data Video PTC-140 Manuel utilisateur

Data Video

Data Video PTC-305 Manuel utilisateur

Data Video

Data Video PTC-200W Manuel utilisateur

Data Video

Data Video PTC-150TL Manuel utilisateur

Data Video

Data Video PTC-140T Manuel utilisateur

Data Video

Data Video ptc-200 Manuel utilisateur

Data Video

Data Video PTC-285 Manuel utilisateur

Data Video

Data Video PTC-150T Manuel utilisateur

Data Video

Data Video PTC-150W Manuel utilisateur

Data Video

Data Video PTC-305NDI Manuel utilisateur

Data Video

Data Video PTC-140NDIW Manuel utilisateur

Data Video

Data Video PTC-140W Manuel utilisateur

Data Video

Data Video PTC-280 Manuel utilisateur

Data Video

Data Video PTC-140T Manuel utilisateur

Data Video

Data Video PTC-150T Manuel utilisateur

Data Video

Data Video PTC-140NDI Manuel utilisateur

Data Video

Data Video PTC-305T Manuel utilisateur

Data Video

Data Video PTC-285T Manuel utilisateur

Data Video

Data Video PTC-150TW Manuel utilisateur

Data Video

Data Video PTC-285W Manuel utilisateur

Data Video

Data Video BC 80 Manuel utilisateur

Data Video

Data Video PTC-150TL Manuel utilisateur

Data Video

Data Video PTC-150 Manuel utilisateur

Data Video

Data Video PTC-285NDI Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
