Data Video RP-53 Manuel utilisateur

Warranty

Standard Warranty

•Datavideo equipment is guaranteed against any manufacturing defects for one year from the date of purchase.

•The original purchase invoice or other documentary evidence should be supplied at the time of any request for

repair under warranty.

•Damage caused by accident, misuse, unauthorized repairs, sand, grit or water is not covered by this warranty.

•All mail or transportation costs including insurance are at the expense of the owner.

•All other claims of any nature are not covered.

•Cables & batteries are not covered under warranty.

•Warranty only valid within the country or region of purchase.

•Your statutory rights are not affected.

Two Year Warranty

•All Datavideo products purchased after 01-Oct.-2008 qualify for a free one year extension to the standard

Warranty, providing the product is registered with Datavideo within 30 days of purchase. For information on how

to register please visit www.datavideo-tek.com or contact your local Datavideo office or authorized Distributors

•Certain parts with limited lifetime expectancy such as LCD Panels, DVD Drives, Hard Drives are only covered

for the first 10,000 hours, or 1 year (whichever comes first).

Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors

before the extended warranty expires.

Disposal

For EU Customers only - WEEE Marking

This symbol on the product indicates that it will not be treated as household waste. It must

be handed over to the applicable take back scheme for the recycling of electrical and

electronic equipment. For more detailed information about the recycling of this product,

please contact your local Datavideo office.

Packing List

1 x RP-53

4 x M5*10 screw

1 x Quick Start Guide

Assembly

The RP-53 is supplied with numbered cables for connecting to MS-3000. Please look at the following table carefully:

From left to right

Connector From/To Qty

HDR SDI out HDR-70 SDI out 2

Switcher PVW SDI out SE-3000 PVW out 1

Switcher Multi-view_1 SDI out SE-3000 Multi1 out 1

Switcher Multi-view_2 SDI out SE-3000 Multi2 out 1

Switcher AUX 2 SDI out SE-3000 AUX2 out 1

Switcher AUX 3 SDI out SE-3000 AUX3 out 1

Switcher AUX 4 SDI out SE-3000 AUX4 out 1

Multi-view Monitor SDI out Multi-view Monitor SDI by pass 1

PGM Monitor SDI out PGM monitor SDI by pass 1

Switcher Loop out SDI out SE-3000 Ref Loop out 1

Switcher Ref in SDI in SE-3000 Ref in 1

Multi-view monitor SDI in Multi view monitor SDI in 1

Use the four rack fixing screws to secure the panel into the rack.

RP- 53:

The RP-53 is supplied with numbered cables for connecting to MS-3000.
