Insert the 2 female crimped pins of DAS cable (fig.9.1fig.9.1 DCABMQS-RCA)
inside the black 12P housing and then in white Fakra cover. In case these
connectors are already available in the unit, just connect the pins in the pin-
out position recommended below.
Insert the wire with label ++ in pin 27pin 27 (positive signal).
If the pin 27 is already used by rear camera, connect to pin 26
Insert the wire with label -- inside the pin 24pin 24 (negative signal).
If the pin 24 is already used by rear camera connect pin 25
Black 12P
White cover
