LARA AND LARA-SUB

RIGGING MANUAL

LARA manual / LARA - SUB

INDEX

OPCION 1

SAFETY PRECAUTIONS

Assembly of a LARA unit on its platform. Disassembly 4

Assembly of a LARA-SUB unit on its platform. Disassembly 6

Assembly of GS-PL-LARA. Splay angle settings in LARA units. 7

Stability, max. and min. angles and maximum number of units

Assembly of 4 LARA units with TOP-PL-LARA on platform 10

Storage of platforms with TOP-PL-LARA during a show 14

AX-LARA introduction: FRAME + PICK-UP unboxing 15

Assembly of AX-LARA on a LARA unit. Max. Number of units. LARA units 16

with AX-LARA (ying / transport mode). Ease Focus coverage gure

AX-LARA on LARA units with inverted Pick-up (tilt up). 21

Ease Focus coverage gure.

Assembly of AX-LARA on a LARA-SUB unit. Max number of units 23

Assembly and use of V-AX-LARA 25

Assembly and use of AX-PULL-LARA 26

Assembly of JP-LARA on a LARA-SUB unit for stacking LARA units on top 27

Flying a cluster of 2 or 3 LARA-SUB units after transport platform is removed 32

FUN-4-LARA installation. With and without AX-LARA 35

FUN-2-LARA-SUB and FUN-3-LARA-SUB installation 37

Using the FUN-2-LARA-SUB or FUN-3-LARA-SUB during a show 38

(stacked usage)

LARA manual / LARA - SUB

SAFETY PRECAUTIONS

 Thismanualoffersallthenecessaryinformationforying

DAS Audio systems. This document contains safety precautions

and a description of the elements to be used.

 TocarryoutanyoperationsrelatedtoyingaDASAudio

system,itisrecommendedtoreadthepresentdocumentrst

and comply with the warnings and advice given. The goal is

to allow the user to become familiar with the mechanical

elements required to y the acoustic system, as well as the

safetymeasurestobetakenduringandafterassembly.

 Onlyexperiencedinstallerswithadequateknowledgeof

theequipmentandlocalsafetyregulationsshouldyspeaker

boxes. It is the user´s responsibility to ensure that the systems

tobeown(includingyingaccessories)complywithstateand

localregulations.

 The working load limits in this manual are the results

of tests carried out by independent laboratories. It is the

user´s responsibility to follow and comply with safety factors,

resistance values, periodical supervisions and warnings given

in this manual. Product improvement through research and

development is on going at DAS Audio, specications are

subjecttochangewithoutnotice.

It is common practice to apply 5:1 safety factors for

enclosures and static elements. For slings and elements

exposed to material fatigue due to friction and load variation

thefollowingratiosmustbemet;5:1forsteelcableslings;4:1for

steelchainslingsand7:1forpolyesterslings.Thus,anelement

withabreakingloadlimitof1000kgmaybestaticallyloaded

with200kg(5:1safetyfactor)anddynamicallyloadedwith142

kg(7:1safetyfactor).

 When a system is own, the working load must be

lowerthantheresistanceofeachindividualyingpointinthe

enclosure, as well as each box.

 Rigging hardware should be regularly inspected and

defectiveunitsreplaceddiscarded.Itishighlyrecommended

that you implement an equipment inspection and maintenance

program, including reports to be lled out by the inspectors.

Localregulationsmayexistthat,incaseofaccident,mayrequire

you to submit evidence of inspection reports and corrective

actions carried out after defects were found.

 Absolutelynorisksshouldbetakenwithregardstopublic

safety.

 When ying enclosures from the ceiling or other

structures, extreme care should be taken to assure the load

bearingcapabilitiesofthestructuressothattheinstallationis

absolutely safe. Do not y enclosures from unsafe structures.

Consult a certied professional if needed. Use gloves and all

necessaryprotectiveequipmenttoavoidpersonalinjuries.

 AllyingaccessoriesthatarenotsuppliedbyDASAudio

are the user´s responsibility. Use at your own risk.

LARA manual / LARA - SUB

2.-Assembly of LARA unit on its transport platform.

Disassembly

Fig.1

Removethetwofrontsecuritypins

from the LARA unit and release the

connectingrods.

Gentlyplacetheunitinsertingthe

connectingrodsintothededicatedslots

of the transport platform.

Fig.2

To attach the LARA unit to the transport

platform, insert the security pins into the

front holes of the platform as shown in

thegure.

Fig.3

Now, it is time to attach the back of the

unit.

Fig.4

Removethepinthatlockstherear

connectingrod.

Lowertheconnectingrodandplace

it between the two rear plates of the

transport platform, as shown in the

gure.Attachtheconnectingrodtothe

platforminsertingthesecuritypinas

showninthegure.

Fordisassembly,proceedinreverseorder

tothatdescribedinthestepsabove.

Fig.1 Fig. 2

Fig.3 Fig.4

LARA manual / LARA - SUB

2.- Video-tutorial

Click or scan the code

Stack four LARA on top of PL-LARA

LARA manual / LARA - SUB

3.- Assembly of a LARA-SUB unit on its transport platform.

Disassembly

Fig.1

Only use the PL-LARA-SUB accessory

(WLL400kgf)showninthegureto

stack and transport up to 3 units of

LARA-SUB.

Fig.2

Place the LARA-SUB unit on the

platformaligningitsfeetwiththemarks

on the platform.

Fig.3 y 4

Notethattherstunitisnotattachedto

theplatformwithsecuritypins,however,

subsequent units need to be attached

to each other. Once a unit has been

stacked on top of another unit, insert

the security pins on both sides at the

front,asshowningure3.

Fig.5, 6 y 7

Next,removethesecuritypinfromthe

rearplates,lowertherearconnecting

rodandattachitwiththepreviously

removedsecuritypin,asshowninthe

gure.Theresultcanbeseeningure7.

*To stack a third unit, follow the same

steps

**Todisassemble,followthestepsabove

inreverseorder.

Fig.1 Fig. 2

Fig.3 y 4 Fig. 5, 6 y 7

LARA manual / LARA - SUB

4.- Assembly of GS-PL-LARA. Play angle settings

in LARA units. Stability, max. and min. angle and

maximum number of units

Fig.1

ThegureshowsthePL-LARA

(WLL=400kgf)accessory.

Fig.2

The GS-PL-LARA accessory can be at-

tachedtothePL-LARAtoprovideaddi-

tionalstabilityingroundstackedLARA

(WLL=400kgf)applications.

Fig.3

Thegureshowshowthedifferentparts

oftheaccessorytintothecorrespond-

ingslots,releasingthesecuritylatches

included. Note that the elbow piecess

are mounted at the front of the platform,

whiletheremainingpiecesgoatthe

back.

Fig.4

Note that the maximum number of units

thatcanbegroundstackedremains4.

PL-LARA platforms and their GS-PL-LARA

accessoryaredesignedformaximum

stabilitywitha±14°tiltabovethehorizon-

tal,regardlessofthesplayanglebetween

the4LARAunitsthatcanbestackedon

them.

WhenusingtheGS-PL-LARA,makesure

the platform and accessoryy are mount-

edonarmsurface.

PL-LARA

WORKING LOAD LIMIT

DAS Audio Group, S.L. (Valencia) Made in Spain

400Kg

MODEL: S/N:

Fig. 2

Fig. 1

Fig.3 Fig. 4

LARA manual / LARA - SUB

Fig.5

Asshowninthegure,thesplayangles

between two adjacent LARA units can

rangefrom0to7degreesmaximum(the

numbers on the rear plates of the LARA

unitsindicatethesplayanglesinde-

grees).

When shipped from the factory, the units

haveasecuritypinstowedinthe“PIN

HOLDER”position,insertedontheright

side of their rear plate, and another pin

stowedinthe“STORELINK”position,

insertedontheleft.Inserttherstpinin

thedesiredsplayangleandinsertthe

otherpintolocktheconnectingrodin

thechosenangleplus1.Thatis,ifthe

desiredangleis4degrees,insertthe“PIN

HOLDER”pininhole“4”andthe“STORE

LINK”pininhole“5”.Whenthedesired

angleis7degrees,insertthe“PINHOLD-

ER”pininhole“7”,andthe“STORELINK”

pinintheholemarked“7+1”.Makesure

theconnectingrodfromtheunitontop

isttedbetweentherearplatesofthe

unit below to ensure the two units are

securely attached.

4.- Assembly of GS-PL-LARA. Play angle settings

in LARA units. Stability, max. and min. angle and

maximum number of units

LARA manual / LARA - SUB

4.- Video-tutorial

Click or scan the code

GS-LARA installation

LARA manual / LARA - SUB

5.- Assembly of 4 LARA units with TOP-PL-LARA on platform

Fig.1

StacktherstLARAunitontheplatform

aspreviouslydescribedinthismanual.

Toattachthefollowingunit,removethe

top security pins of the bottom unit.

Alignthetwounitsandremovethetwo

bottom security pins of the upper unit.

Lowertheconnectingrodsandmake

suretheholesarealignedcorrectly.

Fig.2

Re-insert the four security pins to attach

the two LARA units at the front.

Fig.3

Now, it is time to attach the back of the

unit.

Fig.4

Removethesecuritypinthatlocks

therearconnectingrodandlowerthe

connectingrodfromtheupperunit.

Fig.5

Attachtheconnectingrodwiththe

securitypinandremovethesecuritypin

from the bottom unit.

Fig.6

Insertthispinintothefollowinghole

usedbytherstpin,asshowninthe

gure.

Fig.1 Fig. 2

Fig.3 Fig.4 Fig.5 Fig.6
