DAS AUDIO INTEGRAL-VC1 Manuel utilisateur
INTEGRAL-VC1
User manual
www.dasaudio.com
2INTEGRAL-VC1 Manual
INTEGRAL
Overview
DAS Audio is a unique brand. We
create sound solutions for businesses,
always adapted to the different needs
of our clients.
The Integral Series is the heart and brain of our installation
solutions. It comprises of a series of devices that in addition
to feeding and processing the signal of our speakers,
allow an absolute control to our users, guaranteeing the
protection and quality of the equipment.
You are about to discover what it means to work with our
brand, and this is just the beginning. You will have access
to quality training materials on our website, where you will
discover specific business solutions and learn how to use
them: dasaudio.com/en/training/
This user manual is designed to guide you, swiftly and
smoothly, during the installation of our equipment, but
in case you have any questions or doubts, do not hesitate
to contact our technical support team by writing directly
to [email protected]om or, if you prefer, through our
website, contacting your nearest office at dasaudio.com/
contact
3INTEGRAL-VC1 Manual
INTEGRAL
Description and features
INTEGRAL-VC1 is a 100V volume control capable of han-
dling power up to 120W. The volume is adjustable with a
rotatable selector in 5 steps of -6dB each. It is equipped
with a relay and separated input for the reception of 24V
priority signals. When a priority signal is sent to the con-
troller, the volume will be automatically switched to the
maximum level. This is a very useful tool for emergency
and evacuation purposes.
• To be used with 100V / 70V lines
• Maximum Power Handling 120W
• 24V relay included for priority / emergency messages
• Rotatory 5 position selector (minimum = OFF)
• 86 x 86 mm electrical box included
4INTEGRAL-VC1 Manual
INTEGRAL
Front panel
1Rotatory selector. 5 positions:
1.1 OFF
1.2 -18dB
1.3 -12dB
1.4 -6dB
1.5 0dB
1
5INTEGRAL-VC1 Manual
120W
INTEGRAL
Rear panel
1Main Connector. Pin Assignment:
1.1
1.2
1.3
2120W transformer
Input terminals (+,-) to connect cabling
from amplifier´s output
Output terminals (+,-) to connect the
line of speakers
24V terminals to activate the emer-
gency relay
1
2
6INTEGRAL-VC1 Manual
120W
INTEGRAL
Connections
Shown in the following image an INTEGRAL-VC1
controller connected to an INTEGRAL-Axxx amplifier
delivering on bridge mode 100Volts. In this case the VC1
has been connected to 4 x Arco-24T systems, each one
configured at 30W.
INTEGRAL A404
DAS AUDIO
LE VE L BLE VE L A
S IGNAL / CLIP
ON SIGNAL / CLI P SI
INTEGRAL-Axxx or MAxxx models
100V / 70V (Amp Bridged Outputs)
7INTEGRAL-VC1 Manual
INTEGRAL
Connec-
tions
A more complex system is shown in the following im-
age. There is a paging microphone connected to an IN-
TEGRAL-MAxxxx model with priority selection. A back-
ground music program is provided by the INTEGRAL-AS2
audio source.
CH A + B CH C + D
ON
SIGNAL/LIMIT
PROTECT
COMMS
ENTER
BACK
UP
DOWN
INTEGRAL MA1004
DAS AUDIO
DAS AUDIO - INTEGRAL AS2
USB
VOL+ NEXT SKIP+
USB
F+ PLAY/PAUSE STOPE JECT MODE
VOL- PREV SKIP- F- PROG MUTE REPEAT DISPLAY IR
VOL+ NEXT PRESET CHOICE MODE
VOL- PREV ENTERM ENU PRESET MUTE INFO AUTO SCAN
STANDBY
8INTEGRAL-VC1 Manual
INTEGRAL
Installation
With each unit an electrical 86 x 86 mm box is included.
Contact a professional installer or authorized dealer for
the mounting process.
• Cut a squared hole in the wall to place the electrical
box.
• Place the electrical box and fix it to the wall. Previously
all cabling has been installed in the wall with sufficient
length to provide proper stress relief. Use flexible
cables.
• Run the cables out of the wall thru the electrical box.
• Connect the cables to the screw connector located
at the back plate of the VC1 following the pin out
previously described.
• Fix the unit it to the electrical box with the provided
M4x25 screws.
9INTEGRAL-VC1 Manual
INTEGRAL
Specifications
Power Handling
Frequency Response
Attenuation
Dimensions (H x W x D)
Weight
120W
20Hz – 20kHz
OFF
-18dB
-12dB
-6dB
0dB
86 x 86 x 52mm
(3.38 x 3.38 x 2 in)
530g (1,16845 lb)
W
H
D
