Dante BEATRICE Series Manuel utilisateur

BEATRICE

B1 & B2

Ultra-compact Dante network intercom

PRODUCT DETAILS

6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662

Visit our Website at www.glensound.com FAX: +44 (0) 1622 762330

Page 2of 28

Glensound Electronics Ltd

Thank you for choosing a new Glensound product.

Information contained in this manual is subject to change without notice, if

in doubt please contact us for the latest product information.

If you need any help with the product then we can be contacted at:

Glensound Electronics Ltd

1 –6 Brooks Place

Maidstone

Kent

ME14 1HE

United Kingdom

Telephone: +44 (0) 1622 753662

Fax: +44 (0) 1622 762330

EMAIL ADDRESSES

General enquires: office@glensound.co.uk

Technical enquires: techinfo@glensound.co.uk

Sales enquires: sales@glensound.co.uk

Page 3of 28

PRODUCT WARRANTY

All equipment is fully tested before dispatch and carefully designed to

provide you with trouble free use for many years.

We have a policy of supporting products for as long as possible and

guarantee to be able to support your product for a minimum of 10 years.

For a period of one year after the goods have been despatched the

Company will guarantee the goods against any defect developing after

proper use providing such defects arise solely from faulty materials or

workmanship and that the Customer shall return the goods to the

Company’s works or their local dealer.

All non-wear parts are guaranteed for 2 years after despatch and any

defect developing after proper use from faulty materials or workmanship

will be repaired under this warranty providing the Customer returns the

goods to the Company's works or their local dealer.

SAFETY WARNING

This product can produce high sound levels via the headphone output.

Please take caution when operating this product as listening to

excessively high peak or sustained levels of volume may permanently

damage human hearing.

Page 4of 28

EU DECLARATION OF CONFORMITY

GS-BEATRICE B1 & B2

Ultra-compact Dante intercom

This declaration of conformity is issued under the sole responsibility of

the manufacturer.

This equipment is manufactured by Glensound Electronics Ltd of Brooks

Place Maidstone Kent ME14 1HE is marked and conforms to the

following Union harmonisation legislation:

Emissions: BS EN55032:2015

Immunity: BS EN55035:2017

Signed for and on behalf of Glensound Electronics Ltd.

Gavin Davis, Managing Director

Maidstone, Kent, England

Date: 12/10/2018

Page 5of 28

RoHS DIRECTIVE

RoHS 2 Directive 2011/65/EU restricts the use of the hazardous

substances listed below in electrical and electronic equipment.

This product conforms to the above directive and for these purposes, the

maximum concentration values of the restricted substances by weight in

homogenous materials are:

Lead

0.1%

Mercury

0.1%

Hexavalent Chromium

0.1%

Polybrominated Biphenyls

0.1%

Polybrominated Diphenyl

Ethers

0.1%

Cadmium

0.01%

Page 6of 28

WASTE ELECTRICAL AND ELECTRONIC

EQUIPMENT REGULATIONS 2006 (WEEE)

Glensound Electronics Ltd is registered for business to business sales of

WEEE in the UK our registration number is:

WEE/JJ0074UR

Page 7of 28

GLENSOUND BEATRICE B1 & B2
HANDBOOK CONTENTS
Issue 4
Description Page No.
Contents
PRODUCT WARRANTY.........................................................................................................................3
EU DECLARATION OF CONFORMITY .................................................................................................4
RoHS DIRECTIVE ..................................................................................................................................5
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE)...................6
HANDBOOK CONTENTS.......................................................................................................................7
OVERVIEW.............................................................................................................................................8
B1 & B2 FRONT PANEL LAYOUT .........................................................................................................9
B1 & B2 REAR PANEL LAYOUT..........................................................................................................10
SIDE PANEL LAYOUT..........................................................................................................................11
CONFIG MODE ....................................................................................................................................12
CALLING OTHER BEATRICE DEVICES.............................................................................................14
AUDIO BLOCK DIAGRAM (analogue representation of digital circuits) ..............................................15
Audio Circuits TO and FROM Dante/ AES67....................................................................................15
CONNECTING THE BEATRICE UNITS TO A DANTE NETWORK.....................................................15
Getting Dante Controller....................................................................................................................16
Connecting Beatrice D8 To the Network...........................................................................................16
Audio Over IP Network......................................................................................................................16
Running Dante Controller..................................................................................................................17
Dante Controller TIP..........................................................................................................................17
Device not showing up in Dante Controller .......................................................................................18
AES67 MODE .......................................................................................................................................19
Turning On AES67 Mode ..................................................................................................................19
Sending AES67 Audio.......................................................................................................................20
Receiving AES67 Audio ....................................................................................................................21
AES67 Restrictions............................................................................................................................21
UPDATING FIRMWARE.......................................................................................................................22
Equipment needed ............................................................................................................................22
Instructions ........................................................................................................................................22
UPDATING THE ULTIMO CHIPSET....................................................................................................27
Finding Out Current Installed Version...............................................................................................27
Finding Out What The Latest Available Version Is............................................................................27
Updating the device...........................................................................................................................27
WIRING INFORMATION.......................................................................................................................28
XLR & JACK Wiring...........................................................................................................................28


Page 8of 28

OVERVIEW

The BEATRICE range of IP intercoms was designed for broadcast, theatre and

professional audio applications.

Our Beatrice intercom system utilises the reliable and proven DanteTM network audio

transmission protocol to allow real time distribution of uncompressed audio across

standard networks. As such the BEATRICE B1 & B2 units are also fully compatible

with other manufacturers’ equipment using the DanteTM protocol. The Beatrice B1 &

B2 are also both AES67 compliant.

All units in the system are designed to be very easy to use for the operator and

simple to setup for the technician. They includes all the basic functionality required

for small intercom systems and none of the overly complex installation requirements

normally associated with large systems.

The name Beatrice was chosen for our intercom range as she was the love of Dante

Alighieri:

‘Dante had fallen in love with another, Beatrice Portinari (known as Bice),

whom he first met when he was only nine.’ Source Wikipedia.

Page 9of 28

B1 & B2 FRONT PANEL LAYOUT

1. Talk switch

The front panel speak switches allow the operator to talk to the outgoing talk

circuits and hear sidetone. These lever switches can latch on permanently or

be momentarily activated depending on which orientation they are held,

therefore giving the operator immediate tactile feedback regarding the state of

their mic activation.

The speak lever keys also double as call switches, whereby a fast double

click of the speak lever will send a call signal to the network.

The keys are also used during config mode to toggle different features.

2. Incoming level adjust

This pot adjusts the volume of the incoming Dante audio for the headphones

mix. This pot also controls other parameters when the device is in config

mode.

3. Mic activity LED

This Red/Green LED indicates the level of the mic connected to the headset

and other parameters in config mode. It will only illuminate during config

mode.

4. Call LED

The Call LED(s) indicates the presence of an incoming audio from the Dante

network by illuminating solidly when the audio goes above a threshold of -

30dBFS. The Call LED(s) will flash for a few seconds upon receiving a call.

The Call LED(s) will also flash during config mode to indicate the state of the

config mode.

5. Power LED

This LED indicated the power status of the device. This LED also doubles to

indicate the status of the config mode.

5. Power LED

3. Mic activity LED

2. Incoming level adjust

1. Talk switch

4. Call LED

Page 10 of 28

B1 & B2 REAR PANEL LAYOUT

1. Network RJ45

The Neutrik Ethercon network socket can connect to both Neutrik Ethercon

and standard RJ45 cables. It is a 100M/bit standard IP network connection. The

status LED flashes to show when data is being correctly communicated

with the attached switch.

This is also how the device is powered using a Power Over Ethernet (PoE)

source. The PoE source can be a mid-span source or a network switch with PoE.

2. Headset connector

Headphone output

This 5 or 4 pin XLR socket accepts headphones from 30 to 1000 Ohms.

It has a unique headphone amplifier that allows it to provide the correct output

level regardless of the headphone impedance and it can also have mono

headphone jacks connected with no adverse effect.

Microphone Input

This is a balanced microphone input sharing the connector with the headphone

output. It can accept dynamic and condenser microphones and phantom power

(12v).

Refer to the end of this manual for wiring information.

3. Phantom power LED

This green LED will illuminate to indicate if +12v phantom power is active or

disabled.

3. Phantom power indicator

1. Network RJ45

2. Headset connector
