Instruction CF-RU Repeater Unit
Instruktion CF-RU Signalverstärker
Vejledning CF-RU Repeaterenhed
Instruction Réémetteur CF-RU
Bruksanvisning CF-RU Repeater-enhet

2
Instruction CF-RU Repeater Unit
VI.UH.N3.80 Produced by Danfoss Floor Heating Hydronics 01.2006
Instruction ................................................... 3
Instruktion ................................................... 9
Vejledning...................................................16
Instruction ..................................................22
Bruksanvisning..............................................28
SE

3
Instruction CF-RU Repeater Unit
VI.UH.N3.80 Produced by Danfoss Floor Heating Hydronics 01.2006
1. Functional Overview.................................................................................. 4
2. Installation................................................................................................... 5
3. Placing and Mounting............................................................................... 6
4. Transmission Test........................................................................................ 7
5. Uninstallation.............................................................................................. 7
6. Specications.............................................................................................. 8
7. Troubleshooting ......................................................................................... 8
8. Figures and illustrations............................................................................ A
Index

4
Instruction CF-RU Repeater Unit
VI.UH.N3.80 Produced by Danfoss Floor Heating Hydronics 01.2006
1. Functional Overview
Front – g. 1
Front cover
Red LED (behind the cover)
Transformer/Power supply plug
LED modes
• Permanent light ON
• No light OFF
• Slow ashing Flashes
• Fast ashing Flickers
Back – g. 2
Back plate
Front cover release
Back plate lock/unlock (turn 90°)
Screw hole for wall mounting
Screw and wall plug
Mounting with screws

5
Instruction CF-RU Repeater Unit
VI.UH.N3.80 Produced by Danfoss Floor Heating Hydronics 01.2006
Front Cover – g. 3
Front cover release
Push Button – g. 4
Push button (for installation/transmission test)
2. Installation
Note: The Repeater Unit is installed when system enlargement (transmission distance) is
required, or when other system components cannot reach the Master Controller (link test is
unsatisfactory).
Temporarily connect the Repeater Unit to a 230V power supply outlet no further from the
Master Controller than you can operate both products.
Activate Install mode on Master Controller – g. 4
• Use the menu selection button to select the Install mode. Install LED
ashes
• Activate Install mode by pressing OK . Install LED goes ON
Activate Install mode on Repeater Unit
• Release the front cover, see g. 3
• Press the push button . LED and icker during communication
Repeater Unit installation status
• Satisfactory - LED goes OFF
• Not satisfactory - LED ashes 5 times

6
Instruction CF-RU Repeater Unit
VI.UH.N3.80 Produced by Danfoss Floor Heating Hydronics 01.2006
3. Placing and Mounting
The Repeater Unit has been assigned
When the Repeater Unit has been assigned to the Master Controller, discon-
nect it from the temporary 230V power supply outlet
• Place it somewhere between the Master Controller and the Room
Thermstat (with the unsatisfactory link test) – see g. 5 – and connect it to
a 230V power supply outlet
• Verify the transmission to the Master Controller by making a link test from
the Repeater Unit – see 4
• Perform another link test from the Room Thermostat with 1) the
unsatisfactory link test or 2) where system enlargement is required
Note: Extending the transmission range of the CF2 system
• Up to three Repeater Units can be installed in a chain – see g. 5
• Several chains of Repeater Units can be added to one Master Controller
– see g. 5

7
Instruction CF-RU Repeater Unit
VI.UH.N3.80 Produced by Danfoss Floor Heating Hydronics 01.2006
Initiate transmission test on the Repeater Unit – g. 4
• Press the push button
• LED goes ON
Link test is satisfactory
• LED goes OFF
• Mount the front cover again
Link test is unsatisfactory
• LED ashes 5 times
No transmission to room / Repeater Unit
• Try to relocate the Repeater Unit
• Or install one or up to three Repeater Units and place them
between the Master Controller and Room Thermostat
4. Transmission Test
Factory reset
•Disconnect the Repeater Unit from the power supply
•Release the front cover – see g. 3
•Press and hold down the push button
•Meanwhile plug in the power supply again
•Release the push button when the LED goes ON and OFF
5. Uninstallation

8
Instruction CF-RU Repeater Unit
VI.UH.N3.80 Produced by Danfoss Floor Heating Hydronics 01.2006
6. Specications
Cable lenght (power supply) 3m
Transmission frequency 868.42MHz
Transmission range in buildings
(up to)
30m
Number of Repeater Units in a
chain (up to)
3
Transmission power <1mW
Supply voltage 230V a.c./3V
Ambient temperature 0-50°C
IP class 21
Error indication Possible Causes
The LED ashes 5 times Installation/Link Test is
unsatisfactory
7. Troubleshooting

Instruktion CF-RU Signalverstärker
9
VI.UH.N3.80 Hergestellt von Danfoss Floor Heating Hydronics 01.2006
1. Funktionsübersicht.................................................................................... 10
2. InstallationInstallation................................................................................................... 11
3. Platzierung und Montage......................................................................... 12
4. Funk - VerbindungstestFunk - Verbindungstest ............................................................................ 13
5. Deinstallation.............................................................................................. 14
6. Technische Daten ....................................................................................... 15
7. Fehlersuche ................................................................................................. 15
8. Bilder und Zeichnungen ........................................................................... A
Inhaltsverzeichnis

Instruktion CF-RU Signalverstärker
10 VI.UH.N3.80 Hergestellt von Danfoss Floor Heating Hydronics 01.2006
1. Funktionsübersicht
Vorderseite – Fig. 1
Vordere Abdeckung
Rote LED (hinter der Abdeckung)
Transformator/Netzstecker
LED-Anzeige
• Dauerlicht EIN
• Kein Licht AUS
• Langsames Blinken Blinkt
• Schnelles Blinken Flackert
Rückseite – Fig. 2
Hintere Abdeckung
Lösevorrichtung der vorderen Abdeckung
Hintere Abdeckung verriegeln/ entriegeln (um 90° drehen)
Schraubenloch für Wandmontage
Schraube und Dübel
Montage mit Schrauben
Table des matières
Langues :
Autres manuels Danfoss Répétiteur
