Dancover Pagoda Manuel utilisateur

03-04-2013

7x7 m

Pagoda

Safety Advice

Attention

In some countries approval is needed to set up a tent larger than 75 m2.

The owner of the tent has the sole responsibility to make sure that these local

rules are followed and that the mounting is correct.

In case of bad weather conditions, it is your responsibility to ensure that people

inside are safe and that the tent does not cause damage to others.

It is always recommended that you secure your tent properly with safety straps

and augers when you put up the structure.

We recommend you to insure the tent, or check if it is covered by home con-

tents insurance, in case of unplanned events, accidents or bad weather.

Tents are meant as temporary shelter and must be evacuated under extreme

weather conditions.

always recommend to remove snow from the top.

Attention: Marquees are made for use at parties and other festive arrangements

and are as such only meant for short term temporary assembly and the follow

ing disassembly. Please note that the warranty will not apply if used in any other

way.

7x7M-2.3 PVC Pagoda INSTRUCTION

ARTS NO. Reference image 7x7m

1 1

2 12

3 12

4 4

5 4

6 4

7 4

8 4

9 24

10 8

03-04-2013

11 12

12 1

142

03-04-2013

Assemble Manual

STEP 1

Select a flat ground for the tent, unpack the

carton and check all the parts including

tubes, tent and accessories… etc. are

present as same as list.

Assemble the framework of rooftop by

joining the portion (6.7.8.) together with

poles (11).To ensure the screw fixed to

every pole tightly

STEP 2

Complete the roof structure. Strengthen

the whole roof structure by steel wires

(13.14)

STEP 3

Cover the roof on the frame, and attach it

by the bungee balls properly, take care of

the tension of the bungee balls, for if you

use too many on one side of tent, it may

too tight to tie the other side of it .

STEP 4

Attached all legs in to the connector, and

finish the groundframe to the structure

Assemble manual

STEP 5

Hang all the sidewalls

Warning:

1. In order to avoid being rusted by air, oil is covered on the surface of the pipes, before set up

the tent, please remove the oil carefully first to keep the cover clean.

2. Take note that the tent needs to be handled carefully to avoid damage.

3. Do not force the frame as they may be damage in the process.

4. Tents are meant as temporary shelter and must be evacuated under extreme weather

conditions.

5. The windows maybe a little bit sticky to each other, when you unfold the windows, please do

as softly as you can .Or the windows maybe crack during the process.

Please select a suitable site for the tent to avoid the damage to underground sprinkler systems,

water, gas or electrical lines.

Contact information

Head office:

Dancover A/S

Nordre Strandvej 119 G

3150 Hellebæk

Denmark

For more information

please visit:

www.dancovershop.com

National contact

Denmark:

denmark@dancover.com

UK:

uk@dancover.com

Spain:

espana@dancover.com

Italy:

italia@dancover.com

Germany:

germany@dancover.com

Switzerland:

schweiz@dancover.com

France:

france@dancover.com

Austria:

austria@dancover.com

Sweden:

sverige@dancover.com

Finland:

suomi@dancover.com

Nederland:

nederland@dancover.com

Poland:

polska@dancover.com

Ireland:

ireland@dancover.com

Luxembourg:

luxembourg@dancover.com

Belgium:

belgique@dancover.com

Norway:

norge@dancover.com
