Danby DDEF02213BD13 Manuel utilisateur
DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840
www.Danby.com
*
2022.10.04
ELECTRIC FIREPLACE WITH HEATER
Owner’s Manual.............................1 - 14
FOYER ELECTRIQUE AVEC CHAUFFAGE
Manuel du propriétaire.................15 - 28
CHIMENEA ELÉCTRICA CON CALENTADOR
Manual del propietario.................29 - 42
MODEL •MODÈLE •MODELO
DDEF02213BD13
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
• WARNING: Read and understand this entire owner’s manual,
including all safety information, before plugging in or using this
fireplace. Failure to do so could result in fire, electric shock or serious
personal injury.
• CAUTION: Keep this owner’s manual for future reference.
• CAUTION: Risk of electric shock. Do not open or try to repair the
fireplace yourself.
• This fireplace may get hot when in use. To avoid burns, do not let
bare skin touch hot surfaces.
• Keep combustible materials, such as furniture, pillows, bedding,
paper, clothes and curtains at least 3 feet from the front of the
fireplace and keep them away from the sides, top and rear. Do not
place towels or other objects on the fireplace.
• Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
• The fireplace is not intended for use in bathrooms, laundry areas,
showers or swimming pools and similar locations. Never locate the
fireplace where it may fall into a bathtub or other water container. To
protect against electrical hazards, do not immerse the power cord in
water or other liquids.
• Do not touch the control panel or plug with a wet hand.
• Always use on a dry, level surface.
• Do not use outdoors.
• Always use in an upright position.
• Do not attempt to repair or adjust any electrical or mechanical
functions on this fireplace. Doing so will void your warranty. The
inside of the fireplace does not contain any user serviceable parts.
• Do not insert or allow foreign objects to enter any ventilation or
exhaust opening as this may cause an electric shock or fire or
damage to the fireplace.
1
2
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
• WARNING: To reduce the risk of fire or electric shock, do not use this
fireplace with any solid-state speed control devices.
• Do not operate any fireplace with a damaged power cord or after
the fireplace malfunctions, has been dropped or damaged in any
manner. Return the fireplace to an authorized service facility for
examination, electrical or mechanical adjustment or repair.
• Do not run the power cord under carpeting. Do not cover the power
cord with throw rugs, runners or similar coverings. Arrange the
power cord away from traffic area where it will not be tripped over.
• To prevent possible fire, do not block the air intakes or exhaust in any
manner. Do not use the fireplace on soft surfaces like a bed or thick
carpeting where the air intakes may become blocked.
• This fireplace has hot and arcing or sparking parts inside. Do not
use the fireplace in areas where gasoline, paint, explosive and/or
flammable liquids are used or stored. Keep the fireplace away from
heated surfaces and open flames.
• To avoid fire or shock hazard, plug the fireplace directly into a 120 V
AC electrical outlet. Never use an extension cord or power strip.
• To disconnect the fireplace, turn the controls to off and then remove
the plug from the outlet. Pull firmly on the plug, do not unplug by
pulling on the cord.
• Always unplug the fireplace before moving or cleaning it. Unplug the
fireplace when it is not in use.
• Use only for intended household use as described in this manual.
Any other use not recommended by the manufacturer may cause
fire, electric shock or injury to persons. The use of attachments is not
recommended.
3
OVERHEAT SAFETY FEATURE
This fireplace is equipped with an overheat safety feature. When the
fireplace’s internal components reach a certain temperature that could
cause overheating and possible fire, the fireplace will automatically shut
off. Operation can only resume when the user resets the fireplace.
To reset the fireplace, ensure the power is turned off, unplug the unit and
wait 15 to 20 minutes for the internal components to cool down.
Follow the instructions for use to return the fireplace to normal
functioning.
WARNING: It is normal for the power cord to feel warm to the touch;
however, a loose fit between the outlet and the plug may cause
overheating of the plug. If this occurs, try inserting the plug into a
different outlet. Contact a qualified electrician to inspect the original
outlet for damage.
INCLUDED ACCESSORIES
• Electric fireplace with heater
• Remote control
• Clear crystals
• Wall hanging bracket
• Wall hanging bracket hardware:
• 4 x 45 mm screws x3
• Three screw expansion brackets
• 4 x 12 mm screws x2
• Two feet
• 4 x 16 mm screws x8 (to assemble feet)
OPERATING INSTRUCTIONS
4
FEATURES
1. Glass
2. Air outlet
3. Wall hanging bracket holder
4. Ember bed
5. Free standing feet
1
2
3
4
5
IMPORTANT WARNING
Do not leave this appliance unattended in a space where people
or animals who cannot react to a malfunction are located. A
malfunction can cause extreme overheating or death in an
enclosed, unattended space.
OPERATING INSTRUCTIONS
5
CONTROL PANEL
1. Power indicator light: Illuminates to
show the fireplace is turned on.
2. 1/2 hour timer indicator light
3. 1 hour timer indicator light
4. 2 hour timer indicator light
5. 4 hour timer indicator light
6. Low heat indicator light: Illuminates
when low heat mode is set.
7. High heat indicator light: Illuminates
when high heat mode is set.
8. Power button: Press to turn the
fireplace on or off.
9. Flame button: Press to turn the flame
on or off and to change the flame
colour. There are 10 flame colours.
Press and hold for 5 seconds to set
the colours to cycle continuously.
10.Ember bed button: Press to turn
the carbon bed on or off and to
change the colour. There are 10
ember colours. Press and hold for
5 seconds to set the colours to cycle
continuously.
11.Light button: Press to adjust the flame
brightness. There are 5 brightness
levels.
12.Heater button: Press repeatedly to
select low or high heat mode. The
adjacent indicator light will illuminate
to display the chosen mode.
13.Timer button: Press repeatedly to
set the timer. The timer will turn
the fireplace off after the chosen
time. The timer can be set in 1/2
hour increments up to 7.5 hours.
The adjacent indicator lights will
illuminate to display the chosen
setting.
14.Thermostat button: Turn to set the
temperature. The thermostat can only
be set from the control panel on the
fireplace.
1/2H
1H
2H
4H
1
2
3
4
5
6
7
8
9
10
11
12
13
14
OPERATING INSTRUCTIONS
6
REMOTE CONTROL
1. Power button: Press to turn the fireplace and flame on or off.
2. Heater button: Press repeatedly to select low or high heat mode.
3. Flame button: Press to turn the flame on or off and to change the
flame colour.
4. Ember bed button: Press to turn the carbon bed on or off and to
change the colour.
5. Timer button: Press repeatedly to set the timer. The timer will turn the
fireplace off after the chosen time. The timer can be set in 1/2 hour
increments up to 7.5 hours.
6. Light button: Press to adjust the flame brightness. There are 5
brightness levels.
12
3
56
4
OPERATING INSTRUCTIONS
7
REMOTE CONTROL BATTERY
This remote control uses one CR2025
battery.
To remove the battery, push the latch
on the battery compartment upwards
and then pull the battery tray out.
To replace the battery, place the new
battery in the battery tray and push it
gently into the remote control until it
clicks into place.
WARNING: Never dispose of
batteries in fire. Failure to observe this
precaution may result in an explosion.
Dispose of batteries at your local
hazardous material processing center.
If the fireplace will not be used for
a long time, remove the batteries to
prevent corrosion. Store the remote
control in a safe place.
Remove the insulating film from the
battery compartment before using the
remote control.
WARNING:
• Keep batteries out of childrens’
reach. Discard them carefully.
• Do not allow children to play with
batteries.
• Never put button batteries in or
near your mouth for any reason,
they are slippery and easy to
swallow accidentally.
OPERATING INSTRUCTIONS
8
OPERATING INSTRUCTIONS
INSTRUCTIONS FOR USE
1. Remove the insulating film from the remote control battery
compartment.
2. Ensure the power is turned off.
3. Decide which installation method to use and install the fireplace as
directed.
4. Plug the fireplace directly into a 120V AC electrical outlet.
5. Turn the fireplace on by pressing the power button.
6. Press the heater button to set low or high heat mode.
7. Turn the thermostat dial to set the desired temperature. The fireplace
will remain on until the set temperature is reached and it will then
cycle on and off to maintain the set temperature.
8. Turn the fireplace off by pressing the power button. When the power
is turned off the heating element will stop working immediately but
the fan will continue to run for 30 seconds or until the fireplace has
cooled.
Important
When the heat feature is used for the first time, a slight odor may be
present. This is normal and should not occur again unless the fireplace is
not used for an extended period of time.
It is normal for the fireplace to cycle on and off as it maintains the set
temperature.
For the fireplace to function properly, the set temperature must be higher
than the ambient temperature in the room. If the fireplace does not
seem to be heating, increase the set temperature to engage the heating
element.
9
PREPARATION
WARNING: This product includes glass. Always use extreme caution
when handling glass. Failure to do so could result in personal injury or
property damage.
Remove all parts and hardware from the carton and place them on a
clean, soft, dry surface.
WARNING: Make sure all parts are dry and the power cord and plug
are not damaged. See the Important Instructions section.
The fireplace can be wall-mounted or placed on a solid, level surface
when the free standing feet are assembled. The fireplace must be
plugged into a 120V 60Hz electrical outlet.
FREE STANDING FOOT ASSEMBLY
Place the fireplace carefully on its back. Place the fireplace on a blanket
or soft surface to avoid scratching the unit or flooring.
Attach the free standing feet using eight 4 x 16 mm screws as shown.
Place upright on a solid, level surface and plug into a 120V 60Hz
electrical outlet.
Note: If you attach the solid feet for freestanding installation, you do not
need to install the wall bracket onto the back of the fireplace.
INSTALLATION INSTRUCTIONS
