Danbit KAM-U-DOM2MP-E Manuel utilisateur
1/47
IPC Fast Operation User Manual
Directory
1. Interface introduction.........................................................3
1.1 Box IP Camera(IPC-XXXX-E series) interface.................3
1.2 Waterproof(B cable) interface.............................................4
1.3 Waterproof(P cable) Interface.............................................5
1.4 Robot IP camera Interface ..................................................5
1.5 Cube IP Camera Interface...................................................6
1.6 Interface Function Instruction.............................................7
2. Network Operation.............................................................9
2.1 IE Operation........................................................................9
2.2 Client Software Operation ................................................14
2.3 Monitor the device by WAN(cloud server).......................17
2.4 HVR user manual..............................................................24
3. POE Power supply ..........................................................28
4. Mobile monitor..................................................................30
5. Common Questions.........................................................41
2/47
3/47
Features:
1. Reliability and compatibility
2. Advanced H.264 High prole compression
3. Low streams and high resolution image
4. Support local BNC output
5. Support several servers, IP address,DDNS,cloud
6. Support two-way audio
7. Support dual stream,cloud technology.
8. Support iPhone,Windows
Mobile,BlackBerry,Symbian, Android remote monitor.
9. Support all kinds of browsers, IE, Chrome,Firefox
and Safari
10. Support WIFI/3G
11. Support connect to HVR/NVR
12. Support ONVIF2.0,please refer to IP camera user
manual in the CD
1. Interface introduction
1.1 Box IP Camera(IPC-XXXX-E series) interface
Picture 1.1 HD Box IP camera
4/47
5/47
1.2 Water proof (B cable) interface
Picture 1.2 IR Waterproof IP Camera
1.3Water proof (Pcable) Interface
Picture1.3 IR Waterproof IP Camera
1.4 Robot IP camera Interfa
Picture 1.4 Robot IP camera
6/47
7/47
1.5 Cube IP Camera Interface
Picture 1.5 Cube IP Camera
1.6 Interface Function Instruction
DC12/5V Power Supply：12/5V DC power
supply,wrong power supply will make the device broken
Indication Light: It's working status of device, when
power on is red, nish startup is green, local record is
green icker, alarm activated is red icker
8/47
9/47
Alarm Input: Default - Normal open
Alarm Output: Use for alarm activated
RS485: Connected with PTZ or other RS485 devices
RESET: Keep pressing 5seconds to restore to factory
setting,include IP setting
Audio Input: Connected to audio picker
Audio Output: Connect to Speaker
Video Output: Connect to TV for debugging focal
length
Antenna: Use for WIFI/3G
2. Network Operation
2.1 IE Operation
2.1.1 Use correct power supply
2.1.2 After startup, connect the device with switch or
router, see below picture
Picture2.1 Network structure
2.1.3 Make sure the device ip address is in the same
LAN of router, default IP address is 192.168.1.10
2.1.4 Go to CD->English->Software to nd UpgradeTool
10/47
11/47
and install it
2.1.5 Run UpgradeTool, Clock “IP Search”,you will nd
the device ip,see below picture
Picture2.2 IP Congure
2.1.6 Select the device to cong IP, see below picture
Picture2.3 IP Congure
2.1.7 Factory default IP setting:
IP address: 192.168.1.10
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.1
User name: admin
Password: no password
12/47
13/47
Picture 2.4 Local BNC output
Note: Local BNC output is for debugging lens and look
over IP settings(only keep 30seconds ,then disappear),
see above picture
2.1.8 Open IE,type IP address,login with user name
and password,see below picture
Picture 2.5 WEB GUI After login,enter into below picture
Picture2.6 WEB GUI after login
14/47
15/47
2.2 Client Software Operation
2.2.1 Go to CD->English->Software, nd CMS
2.2.2 Install CMS, run it, default user name: super, no
password
Picture 2.7 CMS Interface
2.2.3 Device manage: System->Device manage,see
below picture
Picture2.8 Device manage
2.2.4 Add Device, see below picture
Picture 2.9 Add device
16/47
17/47
add device modes: IP address, domain name,serial
number and MAC address.
Add IP address ---- IP search and manually add IP
address
IP search: Click “IP search” and select the DVR IP
address to add device
Manually add IP address: Click “add device”,then fill
with IP address,TCP port,user name, password
2.2.5 Device connection: double click the device
name,then choose main stream or extra stream, see
below picture
Picture 2.10 Connect device successfully
2.3 Monitor the device by WAN(cloud server)
2.3.1 If this is the rst time for you to visit it,pls read it
（1）Login XM Cloud http://xmeye.net
（2）User guide,see below picture.
（3）Click "Next", then search IP address, see below
picture:
18/47
19/47
（4）Click "Next", see below picture
（5）Click "Next", see below picture.
（6）Click "Next", enter to user registration page, see
below picture.
（7）Click "Next", it's shown device serial number and
another name,see below picture.
