Daikin 4MKD90BVM Manuel utilisateur
REMOVAL
PROCEDURE
SERVICE MANUAL
8.0/9.0 kW Class
Outdoor Unit
Inverter
Multi Type
Si12-796
Service Manual
Removal Procedure
Outdoor Unit
zCooling Only zHeat Pump
4MKD90BVM 4MXD80BVMA
4MKD90BVMA
4MKD90BVMD
Si12-796
Removal Procedure 1
Table of Contents
1. Removal of Outer Panels ........................................................................2
2. Removal of Propeller Fans......................................................................5
3. Removal of Electrical Box .......................................................................6
4. Removal of PCB....................................................................................13
5. Removal of Fan Motor...........................................................................16
6. Removal of Electronic Expansion Valve and Thermistor ......................18
7. Removal of Sound Blanket and Reactor ...............................................19
8. Removal of Shunt..................................................................................21
9. Removal of Solenoid Valve and Four Way Valve .................................22
10.Removal of Compressor .......................................................................24
Note: The illustrations may be slightly different depending on the model.
The illustrations are for heat pump models as representative.
Removal of Outer Panels Si12-796
2Removal Procedure
1. Removal of Outer Panels
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
1External appearance.
Remove the piping in the
backward direction.
2Remove 11 screws of
the top panel.
Handle
(R2208)
Outdoor air
thermistor
Piping connection slot
(R2209)
(R2210)
Si12-796 Removal of Outer Panels
Removal Procedure 3
3Unscrew 3 screws of
the right panel, slide it
downwards and release
the tabs to remove.
4The figure shows the
view of piping
connections.
5Unscrew 1 screw of the
front right panel, slide it
downwards and release
the tabs to remove.
Step Procedure Points
Right panel
(Main unit side)
Tabs
(Right panel side)
(R2211)
PC board
for servicing
Servicing port
for gas pipe
Servicing port
for fluid pipe
C port
D port
A port
B port
Insects
stopper
shield
(R2212)
Front right panel
Tabs
(R2213)
Removal of Outer Panels Si12-796
4Removal Procedure
6Unscrew 3 screws of
the front panel to
remove.
7Remove 4 screws of
the discharge outlet
grille.
8Slide the discharge
outlet grille upwards
and release 6 tabs to
remove.
Step Procedure Points
(R2214)
(R2215)
Tabs
Tabs
(R2216)
Si12-796 Removal of Propeller Fans
Removal Procedure 5
2. Removal of Propeller Fans
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
Remove the discharge
outlet grille.
1To take off propeller
fan, remove the
washer-fitted nut M8.
2Remove the propeller
fan.
For reassembling, align the
mark of the propeller fan
with the D-cut section of
motor shaft.
Mount the propeller fan while
positioning the mark to
the top.
D cut
Washer-fitted nut M8
(R2217)
mark (R2218)
Removal of Electrical Box Si12-796
6Removal Procedure
3. Removal of Electrical Box
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
Remove the outer panels
such as top and front
panels.
Match the colors of the tie
wires to A, B, C and D ports
as follows.
(1) - Black Power
(2) - White Power
(3) - Red Transmission
Wires are fixed to the
terminal board with screws.
1The figure shows the
right side view.
1. Remove the tie wire.
1Loosen the terminal
board screws, and
remove the wires at A
and B ports.
2Open the terminal
board cover, and
remove the wires at C
and D ports.
When reassembling,
reconnect the wires to C and
D ports.
PC board for servicing
Power terminal board
(L) - White
(N) - Black
Earth terminal
screw
A port B port
D port
C port
Wiring fixture
(R2219)
(R2220)
Terminal
board
cover
(R2221)
Si12-796 Removal of Electrical Box
Removal Procedure 7
3Remove the earth wire.
4Remove 1 screw of the
terminal board.
5Release the tab on the
top right of the terminal
board.
6Pull out the terminal
board and open it.
Glass tube fuse and varistor
cannot be replaced
individually because lead-
free soldering is provided.
Step Procedure Points
(R2222)
(R2223)
(R2224)
Ta b
Glass tube fuse (Soldered)
Varister
(R2225)
Removal of Electrical Box Si12-796
8Removal Procedure
2. Remove each wire harness.
1Disconnect 4
connectors of the
electronic expansion
valve lead wires.
When reconnecting, make
sure to match the wire to the
correct connector.
2Remove the four way
valve connector [S80].
The cooling only models do
not have harness for [S80].
3Remove the connector
[S93] for liquid pipe
thermistor.
Step Procedure Points
[S20]
white
[S21]
red
[S22]
blue
[S23]
yellow
(R2226)
(R2227)
Connector Electronic
expansion
valve No.
Harness
length
[S20] (White) EVA 630
[S21] (Red) EVB 730
[S22] (Blue) EVC 825
[S23]
(Yellow)
EVD 940
[S80]
(R2228)
[S93]
(R2229)
