Dahua CA-DBW481BP Manuel utilisateur

700 TVL IR Vandal Proof Analog Dome Camera

User’s Manual

Version 1.0.0

Table of Contents

1General Introduction ..................................................................................................................1

1.1 Overview........................................................................................................................1

1.2 Features.........................................................................................................................1

1.3 Functions .......................................................................................................................1

1.4 Specifications................................................................................................................2

2Framework...................................................................................................................................5

2.1 Dimensions....................................................................................................................5

2.2 Structure ........................................................................................................................5

3Installation ...................................................................................................................................7

4Menu...........................................................................................................................................11

4.1 Main Menu List ...........................................................................................................11

4.2 Menu Note ...................................................................................................................11

Appendix Toxic or Hazardous Materials or Elements ...............................................................13

Welcome

Thank you for purchasing our analog camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

iii

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conform to your local electrical safety codes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC (24V AC) in the IEC60950-1.

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

If this product is installed in the ceiling, please make sure the installation position can sustain the min

50N.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series camera should be installed in a cool, dry place away from direct sunlight or strong light,

inflammable, explosive substances and etc.

The working temperature ranges from -30℃~ to +60℃. Please keep it away from the electromagnetic

radiation object and environment.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

6. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

7. Daily Maintenance

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

Use the dry soft cloth to clean the device.

If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean

the device. Finally use the dry cloth to clean the device.

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

1General Introduction

1.1 Overview

This series analog camera adopts the high sensitivity CCD and advanced circuit design. It is

featuring the high quality video, the lowest distortion, low noise and etc. This series product is

suitable to be used in surveillance system and video process system.

1.2 Features

zHigh-performance SONY CCD, high resolution, 700TVL, vivid and impressive video.

zSupport auto white balance, ANTI CR (anti-color roll), manual control, push lock, and etc.

Restore high definition and vivid video.

zSupport privacy mask function. Set zone color, transparent, mosaic and etc.

zSupport motion detect function. Set zone sensitivity, block display and etc.

zSupport backlight compensation, high light compensation, close and etc according to the

actual environments.

zSupport ATR (digital WDR) function.

zSupport auto electronic gain control, self-adaptive brightness.

zSupport OSD (on-screen display), suitable for user self-defined setup.

zSupport various languages such as English.

zSupport IR function.

zSupport RS-485 communication protocol.

1.3 Functions

High Definition

700 TVL

540TVL 700TVL

ATR and ATR-EX

ATR (Adaptive Tone-curve Reproduction) function allows the camera to digitally calculate the

video color again and then adjust the brightness to enhance the video quality. This function

can effectively enhance the color and black zone of the video when there is sharp light contrast

in the environments.

General Camera ATR Camera

IR function

This series product can use the IR light to allow you to see the object or realize the monitor in

the low illumination environment.

General Camera IR Camera

1.4 Specifications

Please refer to the following sheet for specification.

700 TVL IR Vandal Proof Dome Camera

Model

Parameter CA-DBW480BP/N(-A) CA-DBW481BP/N(-A)

Video Processor 1/3" SONY EXview HAD CCD Ⅱ

Video Format PAL/NTSC

Effective Pixel

PAL:

976(H)*582（V）

NTSC:

976(H)×494（V）

Resolution 700TVL

Min Illumination Color: 0.005Lux/F1.4（0Lux IR light on.）

PAL

Auto: 1/50s~1/100,000s

Manual: 1/50s,1/120s,1/250s,1/500,1/1000s,1/2000s,

1/4000s,1/10,000s

Electronic Shutter

NTSC

Auto: 1/60s~1/100,000s

Manual: 1/60s,1/100s,1/250s,1/500,1/1000s,1/2000s,

1/4000s,1/10,000s

Lens Type φ14 port 2.8-12mm zoom auto aperture lens andφ14 port 4-9mm zoom auto

aperture lens.

Day/Night Switch Auto

Video Output 1Vp-p Composite Output (75 Ohm/BNC)

SNR Above 65 dB(AGC OFF)

Max IR Distance 20m.

OSD Menu Control Support

LENS Auto/Manual

SHUTTER/AGC Auto/Manual

BACKLIGHT

(BLC)

Off/BLC/HLC(High light compensation )

WHITE

BALANCE

ATW / ANTI CR /manual/push lock/push/user 1/user 2

DAY/NIGHT

MODE

Auto/black and white/color


ADJUST

Mirror/brightness/contrast/sharpness/hue/gain

ATR Off/luminance/contrast

MOTION

DETECT

Detect sensitivity/block display/area selection

PRIVACY

MASK

Area selection/color/transparent/mosaic

NR Level/Y level/C level

SYNC INT

Camera ID Character/position

OSD

Language English/Japanese and etc

Communication Port RS-485

Protection Level IP66

Working Temperature -30 ~+60℃℃

Power DC12V±10%

(-A) series product support AC24V±10% ⁄DC12V±10%.

Power Consumption 4W Max

Dimension(mm) φ160×118.5

Weight 980g(-A:1000g)

2Framework

2.1 Dimensions

Please refer to the following figure for the dimension information. The unit is mm. See Figure

2-1.

Figure 2-1

2.2 Structure

Please refer to the following figure for detailed information. See Figure 2-2.

Figure 2-2

Please refer to the following sheet for detailed information.

SN Component

Name Function

1 Device lens /

2 IR Light It is to send out the IR compensation light to enhance the

night vision.
