Dahua PVR210 Manuel utilisateur

PVR210 User’s Manual

Version 1.3

Table of Contents

1General Introduction ..............................................................................................................7

1.1 Features ....................................................................................................................7

1.2 Specifications............................................................................................................7

2Framework ..............................................................................................................................9

2.1 General Structure.....................................................................................................9

2.2 Front Panel................................................................................................................9

2.3 Port...........................................................................................................................10

2.4 Cable Control Introduction....................................................................................10

3PVR Interface and Operation.............................................................................................12

3.1 Boot up and Shutdown..........................................................................................12

3.2 Standby and Wake up...........................................................................................12

3.3 Lock/Unlock ............................................................................................................12

3.4 System Monitor and Management Interface......................................................13

3.5 Record Operation...................................................................................................15

3.6 Main Menu ..............................................................................................................16

3.6.1 Playback ...........................................................................................................16

3.6.2 Snapshot ..........................................................................................................19

3.6.3 Parameter Setup .............................................................................................20

3.6.4 Format...............................................................................................................32

3.6.5 Shut Down........................................................................................................33

Appendix Toxic or Hazardous Materials or Elements ...........................................................34

Welcome

Thank you for purchasing our PVR210 series product!

This user’s manual is designed to be a reference tool for the installation and operation of your

system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Safeguard and Warnings

1．Electrical safety

zAll the installation and operations here should conform to your local electric safety rules.

zWe assume no liability or responsibility for all the fires or electrical shock caused by

unauthorized handling or installation.

2. Environments

zAlways transport, storage and install the device in the specified temperature and humidity

environments.

zDo not leave the PVR device in corrosive environment such as chemical factory.

3. Transportation and Installation

zPlease handle PVR device carefully

zThis device shall avoid strike or strong vibration. PVR device may be damaged if you use or

storage improperly.

4. Accessories

zBe sure to use all the accessories recommended by the manufacturer.

zDo not expose the camera to strong light for a long time. It may damage the sensitive

components such as the CMOS.

5. SD card

zPlease pay attention to SD card installation direction. Otherwise it may result in SD card

damage or PVR damage!

zDo not remove the SD card when you implement the SD card operation such as record,

playback, format, delete, upgrade and etc. Otherwise it may result in SD card file damage!

zWhen system is upgrading, please make sure the battery power capacity is sufficient. Please

connect the device to the power charger if possible. During the whole upgrade process; do not

remove the SD card! Otherwise it may result in upgrade failure and system can not restore to

the proper running status!

zPlease make sure PVR device connection is right before you begin recording.

Warning

zDo not dismantle PVR device without authorization!

zImproper battery use may result in fire, explosion, or personal injury!

zWhen replace the battery, please make sure you are using the same model!

Some functions listed in this user’s manual are optional. Please make sure you purchased

model supports current function before your operation!

1General Introduction

1.1 Features

This portable video recorder (PVR) is law enforcement equipment for individual suitable for special

industries such as police force, army force. It can completely record the law enforcement process

and provide on-site audio record, video record, playback function. It is portable and is compatible

with semi-stational use. PVR is very convenient to carry and is easy to operate.

1.2 Specifications

Name PVR210

Record resolution Max 1024*768

Video Compression algorithm H.264

Audio Compression mode AAC

Battery working period

(Main unit only)

For the general device, it is about 4.5 hours.

For the device of the network module, it is 2-3

hours.

Battery capacity

threshold alarm

When battery left power capacity is less than

10 minutes, the buzzer begins beeping

regularly to alert you to recharge.

LCD power management System can automatically shut down LCD

power after the PVR stopped operation for

specified time such as ten seconds

(adjustable).

Battery

Standby time About 40 hours

Mini USB port USB2.0 high-speed port

1394b port Connect the main unit to the cable control

module.

Recharge port To recharge the device.

SD card One SD card port

Unit Port

Key Nine keys (Including one on/off button and

eight special keys.)

Storage SD card Support SD1.0, SD1.1, and SD2.0 standard.

SD card alarm When the card is about to full (about five-

minutes recording time left), you can hear

buzzer beeps to alert you to replace a SD card.

Status Indication

Light

Cable control light zMonitor status: Cable control light flashes

once in every three seconds.

zRecord status：Cable control light is on.

zPause status: Cable control light flashes

once per second.

zStandby or stop status: Cable control lights

all become off.

zShut down mode: Cable control lights all

become off.

Working temperature 0℃－＋55℃

Working humidity 10%－90%

Dimensions (L*W*H) 105mm×75mm×34mm

General

Parameter

Weight 0.14Kg(excluding battery and cable control )

2Framework

2.1 General Structure

Please refer to Figure 2-1 for general structure.

Figure 2-1

2.2 Front Panel

Please refer to Figure 2-2 for external keys.

There are nine keys. It includes one power button and eight special keys.

Figure 2-2

Cable control slot

Function key

接口侧盖

Port side cover

Chassis

bottom cover

Battery cover

Chassis up cover

Record

Snapshot

OK Right

Left

Down

Cancel

2.3 Port

Please refer to Figure 2-3 for external ports.

zCable control port：Here you can input cable control to provide audio and video signal, the

key control signal input and status indication light.

zSD card port：Input ordinary SD card. Please pay attention to SD card installation direction.

It supports SD1.0, SD1.1 and SD 2.0 standard.

zExternal power port (it is round and has a socket in the middle.): It is to provide power to the

device.

zMini USB port: You can connect the device to the PC via this port.

Figure 2-3

2.4 Cable Control Introduction

Please refer to Figure 2-4 for cable control information.

Cable control sub-system includes one camera, one microphone, two control keys and one

status indication light. System provides analog audio and video signal input and keystroke control

signal input. Status indication light can represent various statuses (On/Off/Flash. Please refer to

Chapter 1.2 Specifications for detailed information)

External power port

Mini USB port

ort

Power button

Cable control port
