Wireless Door Detector
User's Manual
ZHEJIANG DAHUA VISION TECHNOLOGY CO.LTD V1.0.0
User's Manual
I
Foreword
General
This manual introduces the functions and operations of the wireless door detector (hereinafter
referred to as the "door detector").
Safety Instructions
The following categorized signal words with defined meaning might appear in the manual.
Signal Words
Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
TIPS Provides methods to help you solve a problem or save you time.
NOTE Provides additional information as the emphasis and supplement to
the text.
Revision History
Version Revision Content Release Time
V1.0.0 First release. January 2021
About the Manual
●The manual is for reference only. If there is inconsistency between the manual and the actual
product, the actual product shall prevail.
●We are not liable for any loss caused by the operations that do not comply with the manual.
●The manual would be updated according to the latest laws and regulations of related regions.
For detailed information, see the paper manual, CD-ROM, QR code or our official website. If there
is inconsistency between paper manual and the electronic version, the electronic version shall
prevail.
●All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the manual. Please
contact the customer service for the latest program and supplementary documentation.
●There still might be deviation in technical data, functions and operations description, or errors in
print. If there is any doubt or dispute, please refer to our final explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and the company names in the manual are the properties
User's Manual
II
of their respective owners.
●Please visit our website, contact the supplier or customer service if there is any problem occurred
when using the device.
●If there is any uncertainty or controversy, please refer to our final explanation.
User's Manual
III
Important Safeguards and Warnings
The following description is the correct application of the device. Please read the manual carefully
before use to prevent danger and property loss. Strictly conform to the manual during application
and keep it properly after reading.
Operating Requirements
●Do not install the device in a humid, dusty or fuliginous area.
●Keep its horizontal installation, or install it at stable places, and prevent it from falling.
●Do not drip or splash liquids onto the device; do not put on the device anything filled with liquids
to prevent liquids from flowing into the device.
●Do not dismantle the device arbitrarily.
●Transport, use and store the device within allowed humidity and temperature range.
●Do not place the accessory in the places close to radio interference sources, such as metal
objects.
Power Requirement
●Use batteries according to requirements; otherwise, it might result in fire, explosion or burning of
batteries.
●To replace batteries, use the same type of batteries.
●Use standard power adapter matched with this device. Otherwise, the user must undertake
resulting personnel injuries or device damages.
●Use power supply that meets SELV (safety extra low voltage) requirements, and supply power
with rated voltage that conforms to Limited Power Source in IEC60950-1. For specific power
supply requirements, refer to device labels.
●Products with category I structure shall be connected to grid power output socket, which is
equipped with protective grounding.
●Appliance coupler is a disconnecting device. During normal use, please keep an angle that
facilitates operation.
●Use the accessories regulated by the manufacturer. The device must be maintained by
professionals.
User's Manual
IV
Table of Contents
Foreword ........................................................................................................................................................................................................I
Important Safeguards and Warnings............................................................................................................................................ III
1 Introduction ............................................................................................................................................................................................1
2 Checklist....................................................................................................................................................................................................2
3 Design.........................................................................................................................................................................................................3
3.1 Appearance...................................................................................................................................................................................3
3.2 Dimensions ...................................................................................................................................................................................4
4 Connecting to the Hub.......................................................................................................................................................................5
5 Installation...............................................................................................................................................................................................6
6 Door Detector Configuration .........................................................................................................................................................7
6.1 Configuring the Door Detector...........................................................................................................................................7
6.2 Viewing Status of the Door Detector...............................................................................................................................8
Appendix 1 Cybersecurity Recommendations........................................................................................................................10
User's Manual
1
1 Introduction
Door detector is a wireless detector consisting of a sensor and a magnet that can send a signal to the
hub and trigger an alarm when an armed door is opened. It can be set up via the DMSS App for iOS
and Android phones.
User's Manual
2
2 Checklist
Figure 2-1 Checklist
Table 2-1 Checklist
No. Item Name Quantity No. Item Name Quantity
1 Door detector 1 4 User's manual 1
2 Double-sided
adhesive tape 1 5 Legal and regulatory
information 1
3 Cable 1 6 Screw package 2
User’s manual Legal and regulatory
information
12 3
456
User's Manual
3
3 Design
3.1 Appearance
Figure 3-1 Appearance
Table 3-1 Structure
No. Name Description
1 Indicator
●Flashes green quickly: Pairing mode.
●Solid green: Alarm event is triggered.
2 Peripheral port Connect the peripheral with the alarm cable.
3 On/O button Turn on or turn o the door detector.
4 Tamper button The tamper mode of the accessory, which reacts to the
detachment of the body.
5 Lid
●Normal status: Lid closed.
●Abnormal status: Lid open.
1
2
3
4
5
User's Manual
4
3.2 Dimensions
Figure 3-2 Dimensions (mm[inch])
100.2 [3.95]
21.0 [0.83]
21.3 [0.84]
User's Manual
5
4 Connecting to the Hub
Prior to connection with the hub, install the DMSS App on your phone. Make sure that you have
installed the latest version of the App. Interfaces and functions might vary with different added
devices, and the actual interface shall prevail. This manual takes iOS as an example.
●Make sure that you have already created an account, and added hub to the application.
●Make sure that the hub has stable internet connection.
●Make sure that the hub is disarmed.
Step 1 Go to the hub interface, and then tap to add the detector.
Step 2 Tap to scan the QR code at the bottom of the door detector, and then tap Next.
Step 3 Tap Next after the door detector has been found.
Step 4 Follow on-screen instructions and switch the door detector to on, and then tap Next.
Step 5 Wait for the pairing.
Step 6 Customize the name of the door detector and select the area, and then tap Completed.
