Daewoo DTR Series Manuel utilisateur

MODEL No.

DTR-14D3 / 14D3VG / 14D3VGW

20D3 / 20D3VG / 20D3VGW

21D3 / 21D3VG / 21D3VGW

21D4 / 21D4VG / 21D4VGW

14D5 / 14D5VG / 14D5VGW

20D5 / 20D5VG / 20D5VGW

21D5 / 21D5VG / 21D5VGW

14D7 / 14D7VG / 14D7VGW

20D7 / 20D7VG / 20D7VGW

Instruction

Manual

Instruction

Manual

IDENTITY OF FEATURES ON LOCALAND REMOTE CONTROL

LOCAL CONTROL

REMOTE CONTROL

MAIN

POWER

BUTTON VIDEO 2

INPUT RL

(MONO) HEAD

PHONE STAND-BY

INDICATOR REMOTE

SENSOR MENU

BUTTON

VOLUME

DOWN/UP

BUTTONS

PROGRAMME

DOWN/UP

BUTTONS

TV/VIDEO

FRONT

VIDEO 1

IN MONITOR

OUT

VIDEO

(MONO)

BACK

CONTENTS

* Identity of features on Local and Remote Control 1

* Important safeguards 2

* Installation 3

After moving the set 3

Inserting Batteries into the Remote Control Unit 3

Aerial connection 3

Mains connection 3

Switching the set on and off 3

Tuning the TV Channels 4

Manual Channel Setting 5

* Daily use 6

Selecting a Programme Number 6

Volume and Picture control 6

Timer 7

Sleep 7

Recall 8

Child Lock 8

Mode 8

16:9, ZOOM function 8

Local control key Mode 9

*Connecting the External Equipment 9

*GAME MODE 10

IMPORTANT SAFEGUARDS

Water / Moisture: Never install the set in the following places: in the bathroom, in a wet base-

ment.

Do not place any containers with liquid (e.g. flower vases) on the set.

Heat: Never place the set near heat sources (e.g. radiator).

Ventilation: Do not cover the ventilation openings in the cabinet.

Never place the set in a confined space such as a bookcase or built-in cab-

inet, unless proper ventilation is provided.

Object Entry: Do not insert foreign objects, such as needles and coins, into the ventila-

tion openings.

Lightning Striking: You should disconnect your set from the mains and the aerial system dur-

ing thunderstorms.

Cleaning: Unplug the set from the mains before cleaning.

INSTALLATION

AFTER MOVING THE SET

If the used set is moved or placed in a different direction, the

MAIN POWER button must be switched off for at least 15 min-

utes in order to take out a colour strain on the screen.

INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT

Press down the battery compartment grip and slide the cover.

Insert the batteries supplied (two 1.5V, type AA).

Make sure that the polarity matches with the (+) and (-) marks

inside of the battery compartment.

Used batteries should be disposed properly.

AERIAL CONNECTION

For better picture and sound quality, an effective aerial installa-

tion is the most important.

If you are located in a relatively strong area, you will be able to

use the indoor aerial.

When using an outdoor aerial, it is usually connected to the set

by means of 75 ohm coaxial cable.

MAINS CONNECTION

Plug the mains cable into the power socket with

100-250V~,50/60Hz.

SWITCHING THE SET ON AND OFF

Switching On

Switch the set on with the MAIN POWER button in front of the

receiver. The set will turn on.

If not, press either : - PR UP or DOWN button on the front of

set - or POWER button or the UP/DOWN button or one of the

NUMBER button 0..9 on the remote controller.

The STAND-BY INDICATOR will flicker during 5 times and a

picture will appear on the screen.

Switching Off

Press POWER button on the remote controller to return the set

to its stand-by mode.

The STAND-BY INDICATOR will be on.

If you don't use the set for extended period of time, turn it off

with MAIN POWER button in front of the receiver.

TUNING THE TV CHANNELS

MAIN MENU

Press the MENU button to call up the MAIN MENU.

The MAIN MENU consists of 5 SUB-MENUs:

PICTURE, WOOFER(option), TIMER, LANGUAGE, PRESET

To enter the MENU you must press OK button with the cursor

on that MENU.

LANGUAGE SELECTION

Select a LANGUAGE with the UP/DOWN buttons.

Press the MENU button to return to the MAIN MENU.

AUTOMATIC TUNING SYSTEM

Select the PRESET in the MAIN MENU which consists of

MANUAL, AUTO, and FINE TUNE.

Press the LEFT/RIGHT buttons with the cursor located on the

AUTO SUB MENU. The channel will be searched from the

VHF1, then VHF3 and UHF.

♦

Main Menu

♦


Woofer (option)

Timer

Language

Preset

♦

Preset

♦

Manual

▲

▼

Auto

Fine Tune

▲

▼

Station : P01 - - - -

PO1 VHF1 ➩ ➩

MANUAL CHANNEL SETTING

SEARCHING A CHANNEL

At first, the sound and colour system have to be set according the

broadcasting system.(ex. B/D,AUTO-----). Enter a PRESET in the

MAIN MENU.

With the cursor located on the MANUAL, press the RIGHT/LEFT

button. Then the color of V/Wwill be changed from white to red.

Press UP/DOWN buttons.

The channel will be searched from the frequency of the current PR

upward or downward depending on UP/DOWN buttons.

FINE TUNING

If you are unable to get a good picture or sound because of a poor

broadcasting signal, it can be solved to some extent using the FINE

TUNE. Enter the PRESET in the MAIN MENU. With the cursor

located on the FINE TUNE, press the RIGHT/LEFT buttons. With

the color of V/Wred press UP/DOWN buttons until the improved

picture or sound is obtained. The changed frequency will be

assigned to the current PR.And the osd color of the fine tuned PR.

will be changed from white to cyan.

TO STORE PROGRAMME IN MEMORY

Enter PRESET in the MAIN MENU.

After moving the cursor to the STATION with CH. UP/DOWN but-

tons, locate it on the PROGRAM No. with RIGHT/LEFT buttons.

Select the proper PR. by pressing UP/DOWN and press OK but-

ton.

INPUT A STATION NAME

Enter PRESET in the MAIN MENU.

After moving the cursor to the STATION with the UP/DOWN but-

tons, locate it on the first blank line with the RIGHT button. Using

the CH. UP/DOWN buttons you can input the proper alphabet and

digit. After completing press OK button.

TO SKIP PROGRAMME

By pressing the SKIP button on the remote control unit, you can

skip the channel.

If you press the SKIP button the PROGRAM and SYSTEM OSD

will be displayed on your screen.

If you press the button once more before the OSD disappears, the

channel will be in the skip state.

The color of the PROGRAM OSD will be changed to the red when

the program is in the skip state.

♦

Preset

♦

Manual V/W

Auto

Fine Tune V/W

Station : P01 - - - -

PO1 VHF1

♦

Preset

♦

Manual V/W

Auto

Fine Tune V/W

Station : P01 - - - -

PO1 VHF1

♦

Preset

♦

Manual V/W

Auto

Fine Tune V/W

Station : P01 - - - -

➩ ➩

VOLUME CONTROL

Adjust the volume with the VOLUME DOWN/UP buttons on the

front of the set, or with the LEFT/RIGHT buttons on the remote

control.

*In the case you have a TV set with WOOFER function, if you

want to hear bass-toned trembling sound which focuses on

lower voice, in the main MENU move the cursor to WOOFER,

press OK button and adjust the volume.

MUTE

Pressing the MUTE button once turns the sound off.

The sound returns if the button is pressed once more or VOL-

UME key is pressed.

NORMAL PICTURE SELECTION

When you press the OK button repeatedly you can call up

three picture settings:

for NORMAL I(hard picture), NORMAL II(soft picture),

FAVORITE (adjustable picture).

PICTURE CONTROL

Enter picture in the main menu.

You can select each function with the UP/DOWN buttons. Use

the LEFT/RIGHT buttons to adjust each function. Explanation

about the each function will be displayed in the lower screen

whenever you select the function.

*Yon can set BB function ON/OFF by using LEFT/RIGHT but-

tons. If you set BB function ON, you can see the blue-colored

screen when the TV receives no signal.

*The TINT is active only in NTSC system.

The last set value is automatically stored in FAVORITE mode.

DAILY USE

SELECTING A PROGRAMME NUMBER

The set has a total of 100 programme numbers, 0..99.

The NUMBER buttons 0..9 are used for direct programme

selection.

In order to select two-digit programme, press the second num-

bered button within two seconds.

Switch through the programme number step by step with the

UP/DOWN buttons.

VOLUME AND PICTURE CONTROL

♦


♦

BB On

Enter TIMER in the MAIN MENU.

SETTING THE CLOCK

With the cursor located on the CLOCK using UP/DOWN buttons,

move it to first digit line with RIGHT/LEFT buttons. You can adjust the

time by selecting the proper digit with UP/DOWN buttons. The set time

is memorized when you press the RIGHT button after you set the time.

SETTING THE ON TIME

First, with the cursor located on ON TIME, adjust the time.Then move

the cursor to PROGRAMME NO. With the UP/DOWN buttons select

the program you want. To activate this function move the cursor to

YES/NO and select YES with UP/DOWN buttons.

SETTING THE OFF TIME

You can adjust the OFF TIME the same way as SETTING THE ON

TIME above except selecting the PROGRAMME No.

TIMER

♦

Timer

♦

Clock - - : - -

On Time - - : - -

P02 Yes

Off Time - - : - -

Yes

SLEEP

By pressing the SLEEP button repeatedly, you can select one of the

following settings:

OFF->30min. ->60min.->90min.->120min.

OFF

The set will be turned off after time you select.

Automatic Switch-Off in No broadcast Signal

If a broadcasting signal is not present for about 30 minutes, the set will

be automatically turned off.

In AV mode, however, this function does not operate.

RECALL

The RECALL button is used to display the current status: programme

number, station name, clock.(left above), and system(right below).

This display will appear for about 3 seconds unless any button is

pressed.

CHILD LOCK

You can prevent the use of the TV set without the remote control.

Press the ? button. The “Lock : ?” osd will be displayed with the PRO-

GRAM No. and STATION. With the osd displayed on the screen press

? button once more. Then the program will be CHILD-LOCK.

The set can be switched back using only remote control. You can

resolve the child lock by pressing ? button in the CHILD LOCKED

CHANNEL.

16 :9, ZOOM FUNCTION

Each time you press the MOVE button the size of the picture changes

from normal 4:3 to 16:9, ZOOM, and the original 4:3 in turn.

MODE

If you want to select the proper COLOR and SOUND system press

MODE button. With the cursor located on the COLOR press VOL.

UP/DOWN keys.

The system consists ofAUTO, PAL, SECAM, N3, N4, and N5. Choose

the proper color system.

For the SOUND, with the cursor located on the SOUND press the

VOL. UP/DOWN buttons.

Your choice is B/D and I/M. Select the proper sound system.

LOCAL CONTROL KEY MODE

You can call up the MAIN MENU without the remote con-

trol.

You can enter the MAIN MENU directly by pushing the

MENU button. If you press the MENU button, the MAIN

MENU will be displayed on the screen. Move the cursor to

the SUB MENU you want by using the VOL UP/DOWN but-

ton and press the TV/VIDEO (

)

button, then the

SUB MENU will be displayed on the screen. When the SUB

MENU is displayed on the screen you can set it by using

the VOL UP/DOWN or the CH UP/DOWN button. If you

want to return to the last menu, press the

button.

HEADPHONE JACK

Insert the headphone plug (3.5mmØ) into the headphone socket. The

sound from the speaker will be cut off. In case you have a TV set with

WOOFER function the sound is heard, although you insert head-

phone plug into the headphone socket.

So you must adjust WOOFER VOLUME to minimum when you hear

the sound through the headphone.

FRONT/BACK AV JACK, BACK SCART JACK

Press the VIDEO( )button on the remote control unit or TV/VIDEO

selector button( )on the front of the receiver to select the

VIDEO1 or VIDEO2 mode. “ 1” or “ 2” will appear on the screen.

If you use A/V socket in the front mask, you must select VIDEO 2

mode and if you useA/V or SCARTsocket in the back cover, you must

select VIDEO 1 mode. When you want to return to TV mode, if your

current selection is VIDEO 1 you must press the AV button on the

remote control unit or the TV/VIDEO button on the front mask twice

which makes the mode go through VIDEO 2 to TV mode. If your cur-

rent selection is VIDEO 2 you have to press the AV button on the

remote control unit or the TV/VIDEO button on the front mask only one

time to return to the TV mode

CONNECTING THE EXTERNAL EQUIPMENT

NOTE

1. If you have a mono VCR, video disk

player, video game or camcorder, con-

nect the Audio out line of the external

equipment to the L(MONO) socket of

the TVAUDIO IN and theAUDIO IN line

of the external equipment to the

L(MONO) socket of the TV AUDIO

OUT.

2. The back AV JACK and SCART

JACK are common. If you use one of

them disconnect the other with the

external equipment.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Daewoo TV

Daewoo

Daewoo CM25101S Manuel utilisateur

Daewoo

Daewoo DTC-14D9T Manuel utilisateur

Daewoo

Daewoo DSC-3210E Manuel utilisateur

Daewoo

Daewoo DTM-29U7Z SERIES Manuel utilisateur

Daewoo

Daewoo Super Vision 14A5 Manuel utilisateur

Daewoo

Daewoo 2594ST Manuel utilisateur

Daewoo

Daewoo DTE-29G3ZZR Manuel utilisateur

Daewoo

Daewoo KR14E5/DTA-14V3VM Manuel utilisateur

Daewoo

Daewoo DTP-28B1 Manuel utilisateur

Daewoo

Daewoo DTM-2930MP Manuel utilisateur

Daewoo

Daewoo DTY-2896 TF Manuel utilisateur

Daewoo

Daewoo DUB-2850DT Manuel utilisateur

Daewoo

Daewoo KR29M5-MT Manuel utilisateur

Daewoo

Daewoo DLT-26C2, DLT-26C3, DLT-32C1, Manuel utilisateur

Daewoo

Daewoo DTD-21H9 Manuel utilisateur

Daewoo

Daewoo DTC-2987 Manuel utilisateur

Daewoo

Daewoo DTQ-29S3FC Manuel utilisateur

Daewoo

Daewoo DTK-28 Series Manuel utilisateur

Daewoo

Daewoo DTA-14C4TFF Manuel utilisateur

Daewoo

Daewoo DTB-21S7 Manuel utilisateur

Daewoo

Daewoo CM21S7 Series Manuel utilisateur

Daewoo

Daewoo DTT-2193TU Manuel utilisateur

Daewoo

Daewoo DTH-21S7NAV Manuel utilisateur

Daewoo

Daewoo DTF-2950-100D Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
