DAEWOO SECURITY Alarm system accessories
QUICK INSTALLATION GUIDE
EN /
OUTDOOR SIREN
WOS301
PACKAGE CONTENTS
WOS301
x1
Screws
User guide
x1
APPEARANCE DESIGN
FRONT
1
3
BACK
4
6
7
2
5
8
1. Loud speaker
2. Deterrent red light
3. Power supply
4. Mounting bracket
5. Backup battery
6. ON/OFF button
7. Pairing button
8. Anti-tamper system
SPECIFICATIONS
• Wireless Frequency : 433 MHz
• Sound volume : 120dB
• Input voltage : AC 100-240V 50/60Mhz
LED INDICATIONS
• System armed : LED 2 and 3 light on
• System disarmed : all LED lights off
• Home alarm : LED light 2 and light 3 flash
PRODUCT DESCRIPTION
This siren is wired, with a backup battery.
It can be used as a deterrent siren for an alarm system
(AM301) and works with other devices. It cannot be used
alone.
When an alarm system detector is triggered and if the
system is armed then your outdoor siren will also be
triggered. Its powerful 120dB will warn your entire
neighborhood and thus deter a potential intrusion.
In addition to the audible warning, the siren emits
flashing red warning lights.
INSTALLATION FROM YOUR AM301 CENTRAL
To install the WOS301 siren
- Go to the AM301 central
- Click on the wheel at the bottom left
- Click Security
- Type the code (1234 by default)
- Click on Alarm and activate Siren Alarm and
Siren beep
- Go back to the main page, click on Menu--Accessory
then on Siren
- Turn on the siren using the on/off button
- Press the pairing button on the back 1 times, then press
OK on the control unit
The siren will beep, then press the pairing button and
the installation is complete.
INSTALLATION ON STANDS
You will find the mounting bracket on the back of the
device.
After attaching your screws to the wall, slide the siren
over the screws to secure it.
Be careful, the support is connected to the anti-tamper
system.
This manipulation can trigger the alarm if the siren is on.
Do not hesitate to consult the assistance page of our
website to answer the problems encountered
with this device or find the complet user manuel.
www.daewoo-security.fr
Our technical department can be contacted by e-mail
at the following address :
You have not found the answer to your question ?
MAINTENANCE
This product bears the selective sorting symbol for waste
electrical and electronic equipment (WEEE). This means
that this product must be handled pursuant to European
Directive 2012/19/EU in order to be recycled or
dismantled to minimize its impact on the environment.
For further information, please contact your local or
regional authorities. Electronic products not included in
the selective sorting process are potentially dangerous
of hazardous substances.
In compliance with European Laws. This product is in
the essential requierements and other relevant
provisions of Directive 2014/53/EU ( RED ) substances
This product was designed and manufactured in
compliance with Directive 2011/65/EU of the European
Parliament and of the Council on the restriction of use
of certain hazardous substances in electrical and
electronic equipement ( RoHS Directive - RoHS ) and
is deemed to comply with the maximum
concentration values set by the European Technical
Adaptation Committee ( TAC )
Manufactured in China
STANDARS
DAEWOO SECURITY Alarm system accessories
GUIDE D’INSTALLATION RAPIDE
FR /
SIRÈNE EXTÉRIEURE
WOS301
CONTENU DE LA BOITE
WOS301
x1
VIS
MANUEL
x1
VOTRE SIRÈNE EXTÉRIEURE
AVANT
1
3
ARRIÈRE
4
5
6
7
2
8
1. Haut-parleur
2. Lumière LED rouge dissuasive
3. Alimentation
4. Support de fixation
5. Batterie de secours
6. Bouton ON/OFF
7. Bouton d'appairage
8. Système anti-sabotage
CARACTÉRISTIQUES
• Fréquence sans fil : 433 MHz
•Volume sonore: 120dB
• Tension d'entrée : AC 100-240V 50/60Mhz
INDICATIONS LED
• Système armé : LED 2 et 3 allumées
•Système désarmé: toutes les LED sont éteintes
• Alarme maison : Le voyant 2 et le voyant 3 clignotent
