Daewoo BR-350 Manuel utilisateur

REFRIGERATOR

INSTRUCTION MANUAL

■Thank you for selecting this refrigerator.

■Before using the refrigerator, please read this manual carefully.

Code: 3133-46

BR-350

FEATURE CHART

ICE TRAY

F SHELF (MOVABLE)

FREEZER TEMPERATURE

CONTROL KNOB

ICE BOX

CHILLED CASE DOOR

CHILLED CASE

REFRIGERATOR

TEMPERATURE

CONTROL SWITCH

R SHELF (MOVABLE)

LAMP COVER

VEGETABLE CASE COVER

VEGETABLE CASE

FREEZER POCKET(SMALL)

FREEZER

POCKET(MIDDLE)

EGG CASE

UTILITY

POCKET(SMALL/SMALL)

UTILITY

POCKET(SMALL/MIDDLE)

BOTTLE

POCKET(LARGE/LARGE)

BOTTLE

POCKET(MIDDLE/LARGE)

Here are the features of your new refrigerator.

Take a moment to know all the features designed for the convenience of

the user.

■Ice Tray

Fill 3/4 of the ice tray with water, as the volume expands when the water is

frozen. Place the tray in the freezer compartment. To release ice cubes, twist

the ice tray slightly. Ice cubes will be easier to remove if it is held for a short

while under running water.

■Movable refrigerator and freezer shelves

Storage shelves should be adjusted depending on the height of the food

stored. To do this, pull the shelves slightly forward.

■Defrost-drain Vessel

Since dust accumulated on the drain case decreases the evaporation

efficiency, you should clean the drain case at regular intervals.

■Lamp cover

To remove the lamp cover

1. Push up the bottom end of lamp cover gently,

then pull out.

2.Reverse procedure to join together.

■Vegetable case

May be used for fruit and vegetable storage. Both

the vegetable case and its cover shelf are

removable for easy cleaning. Simply slide forward to

remove.

■Utility Pocket (Top)

The Egg Case in this pocket can be turned upside down for the storage of

small size goods.

■For lock installed refrigerators only.

When you put or take out food from the refrigerator, be careful not to

hit your head on the lock as there is a protrusion on the door of your

refrigerator.

1.Check your voltage before inserting the power supply cord into the socket.

2. Contact the earthing conductor to this unit with an attachment earthing

screw.

3. Do not spill liquid on this unit.

4.Do not use flammable spray, such as painting, near this unit.

5. Do not place ignitable material, such as benzine, L.P. gas, alcohol etc., into

this unit.

6. Take precautions against leakage of any gas equipment near this unit.

7. Keep children from hanging on the door of this unit.

8.Do not reinsert the power supply cord within 5 minutes after releasing it from

the socket. If not, there may be problems with the compressor.

METHODS OF SAFE INSTALLATION

SAFE INSTALLATION PLACE FOR YOUR REFRIGERATOR

•Place the refrigerator on

a strong and level floor.

Unstable installation can

produce noise and

vibration.

•Place your refrigerator

where there is no heat

source nearby.

High atmosphere

temperature will lower

cooling efficiency and

increase your electricity

bill.

•Place the refrigerator in

an area where the

humidity level is low.

Splashing water on the

refrigerator or installing

the unit in a humid area

may cause short circuit

and rust.

•Avoid places that are

exposed to coal gas or

smoke, or discoloring

may occur on the

refrigerator.

•For good ventilation,

keep enough space

between the sidewalls

and your.

This helps to cool

efficiently and lowers the

electricity bill.

•Putting the refrigerator

on the carpet may cause

temperature rise and

result in the discoloring

of the carpet due to the

compressor heat.

In such a case, place a

hard wooden board or a

rubber mat between the

carpet and the unit.

2. INSTALLATION STEPS

•Select a safe place to

install your refrigerator. •Level the refrigerator by

using the adjustable feet. •Install the parts in their

own place.

•Check if the doors are

completely closed. •Check the voltage.

Then wait about an hour

before plugging the

power cord into the

outlet.

•Put food in the

refrigerator after running

the refrigerator for 2~3

hours.

3. WHAT YOU NEED TO KNOW BEFORE MOVING

OR RELOCATING THE REFRIGERATOR!

•Unplung the power cord. •Detach the grille and the

defrost-drain vessel from

the refrigerator with ⊕

driver and then remove

water from the defrost-

drain vessel located at

the rear of the

refrigerator.

•Take food out of the

refrigerator.

•Fasten the interior

components with

adhesive tape.

•Have two people carry

the refrigerator to move

safely.

•Fasten the doors with

adhesive tape to prevent

from opening while

moving.

4. CLEANING YOUR REFRIGERATOR

•Before you clean the

refrigerator, unplug the

power cord. To clean,

use a soft piece of cloth.

Wash with warm, soapy

water rinse and dry.

•The refrigerator may

smell during the initial

operation, but the odour

will fade away when the

refrigerator is cooled

sufficiently.

•Use a soft cloth for

cleaning the interior and

exterior of the

refrigerator.

•Do not sprinkle water

directly on the

refrigerator itself.

•Put the parts back in

their original positions

after cleaning.

HOW TO INSTALL

Location

Install the refrigerator in a convenient location away from extreme heat and

cold. Allow at least 6cm clearance between the refrigerator and side wall so

that the door may open for a fully usable interior and the refrigerator may

have good air circulation. The refrigerator is not designed for recessed

installation.

■ Select a strong and level floor.

■Keep 6cm of space between

the refrigerator and the walls.

Leveling

Level the refrigerator so that it rests solidly on the floor without rocking.

There are two leveling feet at each front corner. Turn to the left to raise a

corner, to the right to lower it. Use shims under the rear corners, if

necessary.

■If you want the refrigerator door to close naturally, adjust the leveling feet so

that the front of the refrigerator is raised by 5mm.

■If you want the refrigerator to remain motionless when open, adjust the leveling

feet so that all four corners are leveled with each other.

All packing materials used to ensure safety during transport should be

removed. You must remove the transport safty packing and wipe off any

possible adhesive tape residues with a petroleum-based cleaner or similar

solvent.

HOW TO OPERATE

Temperature is controlled by thermostat automatically.

The Temperature Control inside the refrigerator controls the degree of

cooling for each compartment.

1. Clean the refrigerator thoroughly. Wipe the outside with a dry cloth, and the inside

with a damp cloth.

2. Set the temperature control knob at normal position.

3. Connect the power supply cord.

Freezer Temperature Control

The control has four settings form

MIN to WINTER. The WINTER

mode is available only if atmosphere

temperature is below 10°C.

Refrigerator Temperature Control

The control has the four settings from

MIN to WINTER. The WINTER mode

is available only if atmosphere

temperature is below 10°C.

Starting your new refrigerator

1. TEMPERATURE CONTROL

1211

To control temperature

Many factors may influence the internal temperature of the refrigerator

and freezer compartments.

■The temperature and humidity of the surrounding environment.

■The opening frequency of the doors and the amount of warm food placed in

the refrigerator.

■The combination of food and containers stored in the refrigerator.

For these reasons, you may want to adjust the control to suit the season and

your needs.

■Turn the temperature control in the refrigerator and freezer compartments

toward WINTER for colder temperature and toward MIN for warmer

temperature.

■Allow approximately 12 hours or overnight for the temperature to stabilize.

Then check to see if further adjustments are necessary.

To turn off the refrigerator

Disconnect the power supply cord. Remove icing case and food. Leave

doors ajar for ventilation and dehumidification of both compartments.

2. DEFROSTING THE REFRIGERATOR

You will never have to defrost your refrigerator as it is designed to

defrost itself completely and automatically.

3. RADIANT HEAT

With the Refrigerating System in operation, it is likely that the cabinet will feel

warm at the front edges and sides. This does not indicate trouble.

It is due to the hot-line used in this type of Refrigerating System which consists of

piping hot gas from the (motor-driven) compressor along the front edges, the

sides of the cabinet and the center partition to prevent dewing. This has nothing

to do with the storage temperature inside.

During spells of hot, humid weather and in rainy season,

moisture may develop on the cabinet, just as water

condenses around a cold glass of water. It is not an

abnormal condition; wipe off the moisture with a dry cloth.

This can also happen when the refrigerator is not installed

in an appropriate place.

To avoid the risk of electric shock or death, unplug the power cord

before replacing a burned out light bulb or cleaning the inner

parts.

WHAT TO DO...

When not operating for a long time

■Remove the power supply cord.

■Dry your refrigerator by opening the door for 2-3 days.

When you get ready to move

■Securely fasten movable interior parts (or remove and pack them separately)

■DO NOT lay down your refrigerator horizontally, or the compressor may be

damaged.

Before you call for service, please check the following points first.

If the refrigerator is not operating:

■Is the power supply cord unplugged?

■Is the home fuse or circuit out of order?

If the refrigerator is warmer than usual:

■Has the door been opened frequently or for a long period?

■Are there any hot food or anything that has been stored without cooling?

■Is the clearance between the refrigerator and the wall given sufficiently?

If there are unusual sounds:

■Is the refrigerator placed on a levelled floor?

■Are there any foreign objects behind the refrigerator?

■Are dishes on refrigerator shelves vibrating?

Improper use of the grounding plug can result in electric shock. If a

grounding adapter is used, make sure the receptacle box is fully

grounded.

If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a simmilary qualified person

in order to avoid a hazard.

Table des matières

Autres manuels Daewoo Réfrigérateur

Daewoo

Daewoo NEO-V RCP33 Series Manuel utilisateur

Daewoo

Daewoo FR-521 Manuel utilisateur

Daewoo

Daewoo FN-063R Manuel utilisateur

Daewoo

Daewoo FLN390EWR0ES Manuel utilisateur

Daewoo

Daewoo SR - 386PW14 Manuel utilisateur

Daewoo

Daewoo ERF-366A Manuel utilisateur

Daewoo

Daewoo FR-860NA Manuel utilisateur

Daewoo

Daewoo FRX-623B Series Manuel utilisateur

Daewoo

Daewoo FR-331 Manuel utilisateur

Daewoo

Daewoo FR-510T Manuel utilisateur

Daewoo

Daewoo FR-061A Manuel utilisateur

Daewoo

Daewoo FRAH52WDS3 Instructions d'installation

Daewoo

Daewoo FR-2701 Manuel utilisateur

Daewoo

Daewoo FRS-T30H series Manuel utilisateur

Daewoo

Daewoo FTL213FWT0RS Manuel utilisateur

Daewoo

Daewoo FR-530KT Manuel utilisateur

Daewoo

Daewoo FRU-5711-FRS-U20DA Series Manuel utilisateur

Daewoo

Daewoo FR-260 Manuel utilisateur

Daewoo

Daewoo BDS115FWT0RU Manuel utilisateur

Daewoo

Daewoo FR-280 Manuel utilisateur

Daewoo

Daewoo FR-143RV Manuel utilisateur

Daewoo

Daewoo FR-650NT Series Manuel utilisateur

Daewoo

Daewoo FR-063R Manuel utilisateur

Daewoo

Daewoo FR-063(SLK) Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
